B&B Electronics ABDG-ET-IN5010 Quick Start Manual

Quick Start Guide

AirborneDirect™ Industrial Ethernet Adapter
ABDG-ET-IN5010
Revision v1.0
March 2010
Document Number: 100-8105-100G

Kit Contents:

Upon receiving the kit please check that you received the following:
ABDG-ET-IN5010 Unit
2dBi, 2.4Ghz 50 ohm, omni-directional antenna
Quick Start Guide
5 VDC power supply (optional, included only if ordered as an accessory)
If any of the above contents are missing or appear damaged please contact B&B Electronics Sales support.

What you will need:

To evaluate the unit you will need the following components and facilities:
ABDG-ET-IN5010 unit with included antenna attached.
Laptop or desktop system with an Ethernet port.
5-36 VDC power for terminal block attachment, or an AC power outlet for optional ABDG-ET-IN5010 power supply.
802.11b/g network for testing the unit, either AdHoc or Infrastructure (Access Points) mode. The test network configuration must be
known. Required information will include:
o
SSID (Wireless network name).
o
Security settings (WEP, WPA, WPA2, etc.).
o
Security credentials (passphrase, key or certificates).
o
Static IP address, Subnet Mask and Gateway address if static IP addresses are used on the test network.
A web browser on the laptop top or desktop (MS Explorer, Firefox, Opera and Chrome v4.0 are supported).
CAT5 Ethernet cable for connecting the unit to the laptop or desktop.
