- Page 2 Trademarks and Copyright RoomPro AV, RoomPro ONE and the RoomPro Technologies logo are trademarks of Projection Guys, Inc. All other product or company names mentioned are used for identification purposes only, and may be trademarks of their respective owners.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ..........................2 INTRODUCTION..............................3 About RoomPro Technologies........................3 ABOUT THIS GUIDE ............................4 RoomPro Package Components ........................4 Accessories..............................5 System Specifications and Features ......................5 INSTALLATION PLANNING ..........................6 Tools and Materials ............................6 Site Preparation .............................. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS To avoid potential equipment damage and/or serious injury, READ AND FOLLOW all safety precautions when installing the RoomPro system. WARNINGS are located throughout the procedural steps in this guide, and are repeated below for emphasis. USE A CERTIFIED ELECTRICAN FOR POWER CONNECTIONS. The RoomPro system uses standard 110VAC power. -
Page 5: Introduction
INTRODUCTION About RoomPro Technologies Thank you for choosing RoomPro Technologies. We are a Wisconsin-based manufacturer of all-in-one classroom control and microphone solutions. Founded on the idea that classroom audio-visual technology should be teacher, installer and budget-friendly, we released RoomPro AV—the industry's first projector mount with integrated speakers. -
Page 6: About This Guide
ABOUT THIS GUIDE READ THIS GUIDE COMPLETELY BEFORE BEGINNING INSTALLATION. This guide provides the procedures and instructions necessary to install and operate your RoomPro ONE AV system. Be sure to follow ALL SAFETY PRECAUTIONS during installation. RoomPro Package Components The RoomPro Package includes:... -
Page 7: Accessories
USB Powered 2-Port VGA Video Splitter Additional IR microphone(s) with lanyard and rechargeable batteries Flush-mounting kit for solid ceilings For pricing and availability, contact RoomPro Technologies or your nearest authorized reseller. System Specifications and Features Amplifier - 40 watts Stereo at 4 Ohm Speakers - Four 5-1/4"... -
Page 8: Installation Planning
Schematic/Wiring Diagram. NOTE The RoomPro Ceiling Enclosure is designed for installation in a 2’ x 2’ or 2’ x 4’ grid-type drop- in ceiling. If you do not have this type of ceiling, please contact your local authorized dealer or RoomPro Technologies for a special “flush mount”... - Page 9 The Control Panel can be installed “in-wall” (flush mounted) using a standard 4-gang electrical box (not provided), or it can be “surface mounted” using the optional Surface Mount Wall Box. The RoomPro system is supplied with 35’ Cat5 cables for connecting the Ceiling Enclosure electronics to the Control Panel.
-
Page 10: Installation
INSTALLATION 1. Ceiling Enclosure 2. Ceiling Enclosure Lid 3. Tube Adaptor 4. Projector Mount 5. Turnbuckle (4) 6. Thread Retainer (4) 7. Eye Lag Bolt (4) 8. Suspension Wire Figure 2 – Ceiling Enclosure Installation... - Page 11 1. Control Panel 2. Panel Screws, Black (4) 3. Wall Mount Panel 4. Concrete TapCon Screws (4) 5. Cat5 Cable, Port A 6. Cat5 Cable, Port B 7. Wiremold Raceway 500/700 (purchased separately) D IO B la re e l u m u r c R / D I n p...
-
Page 12: Step 1: Installing The Ceiling Enclosure
Step 1 – Installing the Ceiling Enclosure Step 2 – Mounting the Projector Step 3 – Installing the Infrared (IR) Microphone System (RoomPro ONE system only) Step 4 – Installing the Control Panel Step 5 – Final Assembly and Adjustment See Figure 2 –... - Page 13 Figure 5 – Lag Bolt Installation 3. Connect the Suspension Wire Cut a length of suspension wire to reach from one eye lag bolt to several inches below the ceiling tile. For each eye lag bolt, insert the suspension wire through the hole in the bolt, loop the end downward, and wrap at least five turns around the main suspension wire.
-
Page 14: Step 2: Mounting The Projector
Route the projector cable bundle through the tube adaptor. BE SURE to route the cables through one at a time. Begin with the VGA cable, followed by the serial cable, and finally the composite cable. -
Page 15: Step 3: Installing The Infrared (Ir) Microphone System
An optional (grey) cable is provided to support longer distances. Ensure the cable is connected securely. BE SURE to check the cable connection at the amplifier in the Ceiling Enclosure. See Figure 1 – RoomPro One Schematic/Wiring Diagram. -
Page 16: Step 4: Installing The Control Panel
Connect each Cat5 cable to its appropriate port on the rear of the control panel. Ensure the cables are connected securely. BE SURE to check the cable connections at the amplifier in the Ceiling Enclosure. See Figure 1 – RoomPro One Schematic/Wiring Diagram. 5. Install the Control Panel Position the control panel (1) in place on the wall panel, and secure in place with four black 6-32 X 1/4screws. -
Page 17: Step 5: Final Assembly And Adjustment
Re-install all ceiling tiles removed during installation. If your ceiling uses 2’ X 4’ tiles, use a sharp utility knife to trim one tile to 2’ X 2’, and install this tile next to the Ceiling Enclosure using a 2-foot ceiling grid brace to ensure proper ceiling replacement. - Page 18 Composite Video Source Comp 2/Doc Input VGA (Computer) 1* Source *Switching between the two VGA Inputs on the Panel is done within the RoomPro system resulting in only one VGA source being used at the projector. Power the system off and repeat.
