Summary of Contents for Topex MobiLink GSM i

  • Page 1 MobiLink GSM i Interface to PBX trunk over GSM 900/ 1800MHz User’s MANUAL 2009...
  • Page 2 (GSM/GPRS, CDMA/EVDO, HSDPA), including 3G technologies. TOPEX is represented all over Romania by a wide network of local distributors through which the promotion, administration and product maintenance are running. Due to our innovation power, authentic flexibility, real respect for our partners and secure solutions that we provide TOPEX extended its business worldwide.
  • Page 3 USER`S MANUAL DEAR CLIENT! TOPEX thanks for your choice; with MobiLink GSMi equipment you have made an excellent choice. By purchasing the MobiLink GSMi you have: Flexible analog interface between a PBX or a single phone and a mobile network...
  • Page 4 ! Please do not dispose your TOPEX product as unsorted waste (household waste), recycle it to protect the environment. Separate the packages according to waste disposal options and WEEE Directive sort it for recycling.
  • Page 5: Table Of Contents

    USER`S MANUAL CONTENT About MobiLink GSM..................6 PACKAGE CONTENT..................7 MobiLink GSM i - INSTALLATION ................ 8 Configuring and installing the SIM card ............. 8 3.1.1 Configuring SIM card 3.1.2 Inserting the SIM card Mounting MobiLink GSMi ................11 Connecting the equipment ................12 3.3.1 Labels and identifiers...
  • Page 6: About Mobilink Gsm

    USER`S MANUAL About MobiLink GSM MobiLink GSMi is the smallest member of the analog range of Topex mobile gateways. MobiLink is a voice and data interface between the subscribers of a PBX exchange and the mobile network of 2G/3G, which can be GSM/GPRS/UMTS. MobiLink GSMi assures the wireless connection for voice and data and decreases the cost of fixed–to-mobile and mobile–to-fixed calls, while...
  • Page 7: Package Content

    USER`S MANUAL PACKAGE CONTENT When opening the package, please check the contents against the following: Component Image Component Description MobiLink GSMi unit in its plastic case. It is a mobile gateway with two interfaces, type FXS and GSM. Power supply: switching mains adapter Input: 100-240V A.C Output:...
  • Page 8: Mobilink Gsm I - Installation

    PIN or PUK code, if is required performing other settings, via OAM or phone Configuring and installing the SIM card In order to work, MobiLink GSM i needs and adequate SIM card for the GSM/GPRS/GSM/GPRS/UMTS operators to which you want to connect. Configuring SIM card 3.1.1...
  • Page 9: Inserting The Sim Card

    USER`S MANUAL Inserting the SIM card 3.1.2 The SIM card must be inserted into the special slot (holder) of MobiLink GSM. The slot of SIM card is located on top right side, under the status LED`s. For inserting or extracting the SIM card use the mobile holder for SIM.
  • Page 10 When the MobiLink GSMi equipment is powered and includes a SIM card that has the „PIN CODE REQUEST” option enabled, MobiLink GSM I will send to SIM the code that was stored. If this code is different from the SIM code, MobiLink GSMi switches into the mode of “waiting for PIN code”...
  • Page 11: Mounting Mobilink Gsmi

    For mounting MobiLink on a wall, use the mounting kit (plastic dowels, woodscrews, etc) provided by Topex. On the back of equipmnet there is a pair of mounting holes, 55 mm apart. The pair is located near the top of the plastic case, to secure the MobiLink GSMi to the wall with indicators up and connector’s panel downwards.
  • Page 12: Connecting The Equipment

    USER`S MANUAL 3.3 Connecting the equipment Labels and identifiers 3.3.1 On the bottom of the case of the MobiLink GSM i equipment there are glued several labels or tags that show the characteristics and compliance. Significance of Labels 3.3.2 These adhesive labels contain information about the manufacturer, type, model, certification, approval, compliance to international and UE directives.
  • Page 13: Identifying The Connectors

    USER`S MANUAL 3.3.3 Identifying the connectors The panel with connections is placed on the bottom of the MobiLink GSM case. Figure 2.: Identifying the connectors The connectors are, from left to right: DC – Power, round JACK- used for connecting the power supply adapter (delivery in package). USB –...
  • Page 14: Connecting The Cables

    USER`S MANUAL Connecting the cables 3.3.4 Figure 3.: Connecting the cables Connecting the telephone cable for FxS interface MobiLink GSMi is shipped with a piece of flat telephone cable, wired on both side with RJ11 connectors. Depending upon the actual condition of installation, you may need a second piece of cable, or a greater length of telephone cable.
  • Page 15 GSM, and the other end of cable to the USB-A port of a PC, see the figure 3. Figure 5.: Achieving USB connection Note: The same USB connection has a double function: for data transfer (connecting to Internet) and for MobiLink GSM I configuration by means the OAM application. IM-REVA-EN_2009 Page 15/ 51...
  • Page 16 USER`S MANUAL Connecting the antenna MobiLink GSMi package includes a multiband antenna for GSM/GPRS/UMTS mobile network. The antenna has a cable of 2,50 m length and a magnetic base, so it can be installed on any ferromagnetic surface. ! You should fasten the antenna on a safe (with great stability) and flat area, even one that is not magnetic.
  • Page 17 USER`S MANUAL Antenna features 890-960 MHz PCN 1710-1880 MHz Frequency bands 1850-1990 MHz UMTS/HDSPA 1920-2170 MHz Gain 2 dBi Polarization Vertical Total 73 mm Height Active stick 43 mm Base Magnetic, diameter 2,8cm Cable Type RG174, length 2,5 m End Connector Nipple, male Note: The MobiLink GSMi unit and its antenna should be placed as far as possible from...
  • Page 18 USER`S MANUAL Connecting the power-supply adapter Connect the JACK connector to DC connector, then plug-in the power supply adapter to the wall outlet (230V Figure 7. Connecting power supply For powering of MobiLink GSMi you must use only the adapter delivered by the manufacturer.
  • Page 19: Achieving A Voice Link

    USER`S MANUAL 4 ACHIEVING A VOICE LINK 4.1 Installing the equipment on the PBX exchange MobiLink GSMi can be connected in two ways: With its FXS interface to an analogue trunk of a PBX exchange With its FXS interface directly to an analogue phone. To this purpose MobiLink GSMi has a RJ11 connector, where you attach the PBX or phone cable, as shown below.
  • Page 20: Achieving An Outgoing Call

    A voice link can be initiated in the moment when MobiLink GSMi generates dial tone (by default continuously tone, frequency 440 Hz). But the Topex equipment allows you to u customize the dial and busy tones, as well as the ringing sound.
  • Page 21: Achieving Test Calls

    USER`S MANUAL 5 ACHIEVING TEST CALLS It is recommended to make first some test call, for verifying if MobiLink GSMi equipment is operating correctly. For MobiLink GSMi connected to PBX trunk Incoming call Ring, from a mobile phone, to the number of SIM card used by MobiLink GSMi. The Interface diverts the call and sends the ringing signal to trunk of PBX exchange.
  • Page 22 Normally, after you enter the PUK code you, must insert the new PIN code (defined by you). But when the option “Change PIN code” is enabled in the OAM progran, the TOPEX equipment will generate automatically a new PIN code, so you don’t have to do anything. This prevents the SIM to be used on another terminal.
  • Page 23: Configuring The Pc Connection

    USER`S MANUAL CONFIGURING THE CONNECTION To configure an Internet connection using MobiLink you have to follow these steps: - First, achieve the installation of the USB driver on your PC. The driver is required so than the computer can “see” the MobiLink device connected to it, which is required not only for the data transfer, but also for connection to the OAM program - Configure an access connection to the Internet on the PC - Specify the initialization AT commands (for dial-up)
  • Page 24: The Installation Of Usb Driver

    CD-ROM unit and brow the folder called „Driver_usb” Double click on „PL-2303 Driver Installer.exe” application (delivered by TOPEX on CD) in order to install the USB driver Connect the USB data cable and the message “Found new hardware” must...
  • Page 25: The Installation Of Mobilink Gsm On Usb Port

    USER`S MANUAL 7.2 The installation of MobiLink GSM on USB port Enter “Control Panel” > select “Phone and Modem Options” > press on the “Modems” tab > Select “Add” IM-REVA-EN_2009 Page 25/ 51...
  • Page 26 USER`S MANUAL Check “Don’t detect my modem; I will select it from a list” > IM-REVA-EN_2009 Page 26/ 51...
  • Page 27 USER`S MANUAL Click “Next” to continue … Select from “Standard Modem Types” a Standard 33600 bps Modem: The wizard asks you for the port number where it will connect the modem: IM-REVA-EN_2009 Page 27/ 51...
  • Page 28 USER`S MANUAL Select the installed port of the USB driver, such as COM10 in the example (To get this information go to Device Manager and press on the “+” symbol at “Port (COM & LPT)” > Next Wait on “please wait” message … The installation of the MobiLink GSMi mobile modem has successfully ended and to finish this wizard press Finish.
  • Page 29 USER`S MANUAL Identifying the COM port To see the number of the COM port where MobiLink GSMi is attached, go to Control panel>System Properties>Hardware>Device manager>Ports: Among the COM ports, you will see also the one (COM 10 in the example below) where MobiLink is connected.
  • Page 30 USER`S MANUAL Set the communication parameters – speed 115200 bps, data bits 8, parity none, stop bits 1, flow control None. IM-REVA-EN_2009 Page 30/ 51...
  • Page 31: Accessing The Topex Modem

    USER`S MANUAL 7.3 Accessing the Topex modem To be able to access directly the modem of MobiLink, you must first send it the command string „AT”. This can be done by means of an console emulator program, such as HyperTerminal in Windows.
  • Page 32: Setting Up An Internet Connection

    USER`S MANUAL Then the HyperTerminal screen opens up: Pick up the phone (“call”) to connect. The status bar at the bottom of the screen will show the successful connection to MobiLink; Type the command “AT” to place the modem in data transfer mode. Be careful to use capital letters, and no spacing between AT and the three zeroes! Alternate command –...
  • Page 33 USER`S MANUAL From the list with the modems attached to your computer, select “Modem – Standard 19200 bps Modem) (COM 10)” and check if the COM port is the right one > Next > Insert the name of your Internet connection, such as “MobiLink FXS” in our example. Next> In the “Phone Number”...
  • Page 34 USER`S MANUAL In this moment you have created an Internet connection, and to finish this wizard press the “Finish” button. Also, the GSM/GPRS/UMTS modem must be configured with some initialization commands (an additional AT command), depending on the mobile phone carrier that you use. From “Control Panel”...
  • Page 35 USER`S MANUAL In the “Extra initialization commands:” window insert the following command: then confirm all by pressing “OK”. This command is strictly required to place the modem in the DATA mode, you will see that the middle LED, orange color, blinks three times to indicate data operation. Some mobile data providers may require extra initialization commands, such as the APN, which includes the name of the...
  • Page 36: Connecting To Internet

    USER`S MANUAL 7.5 Connecting to Internet Use the connection you just created. Enter “Network Connections” (Start > Programs > Accessories > Communications > Network Connections) , select your connection, in the example below called “Mlink” and double click on it: The “Connect Mlink”...
  • Page 37 USER`S MANUAL Then a window named "Connecting Mlink" must appear on your screen, which informs you that the equipment is connecting to Internet and the remote server verifies the username and password. In the right corner of the status bar, he network icon for Mlink connection begins to blink.
  • Page 38: Monitoring The Function Status

    MobiLink GSM. Out of these, the LED indicators are the most important, since they are always available to give you useful information about the state of the Topex box! The LED’s significance The equipment has three status LED’s.
  • Page 39 USER`S MANUAL 7.2. Tonalities MobiLink GSMi also signals the function status and the errors by means of some audible tones, which can be heard in the handset of the connected phone. If the control module of the equipment does not communicate with the mobile modem or if the mobile phone module has no network signal, MobiLink GSMi generates a warning tone.
  • Page 40: Configuring

    USER`S MANUAL 9 CONFIGURING OAM configuration MobiLink GSMi should be configured with the OAM program, which is supplied on the CD or floppy disk. The OAM program allows you to configure the GSM module and FxS phone interfaces (parameter setting), to perform the ring and tones adjustments, to send and receive SMS. Some of the most important settings are: IN, input: if the module has activated this option, the calls to the mobile module will be sent through the FxS interface, if disabled, the calls will be rejected by the...
  • Page 41: Programming Mobilink Gsm Through Its Line Interface

    10 PROGRAMMING MobiLink GSM THROUGH ITS LINE INTERFACE What it is? You can set up the parameters of the Topex equipment without the OAM program, by simply using an ordinary telephone, connected to the subscriber port (FXS) of MobiLink FXS.
  • Page 42 USER`S MANUAL Programming of action upon incoming calls form GSM: - should you want the calls coming in from the mobile network to be REJECTED: you dial - if you want the calls coming in from the mobile network to be sent to the analog telephone interface (the default setting) : you dial 221.
  • Page 43 USER`S MANUAL Programming of CLIP generation If Caller ID is enabled, you can select the mode of sending out ID (by FSK or with DTMF) and its timing – before the ringing signal or after it. - for CLIP generated after the ringing signal, in mode ETSI FSK, you dial 510 - for CLIP generated before the ringing signal, in mode ETSI FSK, you dial 511 - for CLIP generated after the ringing signal, in mode ETSI DTMF, you dial 512 - for CLIP after the ringing signal, in mode ETSI DTMF you dial 513.
  • Page 44 USER`S MANUAL Programming of hotline service: - to enable : you dial 321 - to disable (the default state) : you dial 320 Programming of timer for hotline: - you dial 81x, where x is the value in seconds for “enable hotline” Programming the number for hotline: - you dial 82dig1dig2...dign# Programming of audio level towards the telephone interfaces:...
  • Page 45: Technical Specifications

    USER`S MANUAL 11 TECHNICAL SPECIFICATIONS Depending upon the type of mobile module used, as specified on the label on the back of the case, such as: Mobile phone networks Dual band - GSM/GPRS: 850/1900 MHz Quad band -GSM/GPRS: 800/850/1800/1900 UMTS: 2100 MHz Voice, data, SMS GPRS data: class GPRS 10, type B Network services...
  • Page 46: Environmental And Operating Conditions

    USER`S MANUAL ENVIRONMENTAL AND OPERATING CONDITIONS MobiLink GSMi equipment must be installed only indoor, in closed rooms, which follow these environment conditions: Operating temperature 5 to 50 Humidity 10 to 90%, without condense The equipment must not be installed outside! Also MobiLink GSMi will not be installed in flammable or explosive environments.
  • Page 47: Applications

    USER`S MANUAL APPLICATIONS a. Voice/Data interface between a PBX, a PC and the GSM/GPRS/GSM/GPRS/UMTS network MobiLink GSMi achieves a direct voice connection between a private exchange and the GSM/GPRS/UMTS mobile phone network. It may be connected on an analog trunk of the exchange or to a local subscriber line and provides the possibility to call directly in the mobile network from all the local extension, thus avoiding the national fixed telephone operator.
  • Page 48 USER`S MANUAL Voice/Data interface between fixed telephone, mobile GSM/GPRS/GSM/GPRS/UMTS network Working without PBX, MobiLink GSMi creates a directly voice connection between an analog (standard) phone and the S mobile network. In this case the Topes interface has connected its FXS interface to your fixed phone, and the FXO interface to the PSTN network, if available.
  • Page 49: Glossary

    USER`S MANUAL 14 . GLOSSARY DTMF – Acronym for Dual Tone Multi Frequency, also known as "touch tone". Advanced method for dialling a number, instead of the older PULSE mode. When you press a key on the keypad a combination of two audio frequencies is sent on the line. DTMF capability is important because it allows access to a wide range of interactive voice applications.
  • Page 50 USER`S MANUAL IM-REVA-EN_2009 Page 50/ 51...
  • Page 51 No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of the company TOPEX S.A. We certify hereby that the MobiLink GSMi unit is manufactured in concordance with the legal provisions concerning responsibility towards the quality of delivered products, fulfills the quality parameters specified in its “User’s manual”...
