Q-TECH™ PROGRAMMER
A COMPONENT OF THE S-ICD
SYSTEM
®
USER'S MANUAL
3200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REF3200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Boston Scientific REF3200

  • Page 1 Q-TECH™ PROGRAMMER A COMPONENT OF THE S-ICD SYSTEM ® USER’S MANUAL 3200...
  • Page 2 Limited Software License and Equipment Use. S-ICD®, SQ-RX®, and Q-TRAK® are all registered trademarks of Cameron Health, Inc. Q-GUIDE™ and Q-TECH™ are all trademarks of Cameron Health, Inc. Manuals or other written documentation may not be copied or distributed without Cameron Health, Inc.

  • Page 3: Table Of Contents

    Use of Other Medical Therapies/Diagnostic Procedures ..............4 Electromagnetic Interference (EMI) Outside the Hospital Environment ........5 Potential Adverse Events ..........................5 OpErATiON Setup of the Q-TECH programmer �������������������������������������������������������������������������������������������7 Packaging ................................7 Charging the Programmer ..........................7 Using the Q-TECH programmer������������������������������������������������������������������������������������������������8 Turning the Programmer On ...........................8 Placing the Programmer in Suspend Mode ....................9...
  • Page 4 OpErATiON (continued) Modes of Operation for the Q-TECH programmer ��������������������������������������������������������������� 21 Online Behavior ..............................21 Offline Behavior ..............................22 Modes of Operation for the SQ-rX device ��������������������������������������������������������������������������� 23 Shelf Mode ................................23 Therapy On Mode ............................23 Therapy Off Mode ............................23 Connecting and disconnecting from the SQ-rX device �����������������������������������������������������...
  • Page 5 Recommended Separation Distances ...................... 69 EMI/RFI Information ............................69 SpECiFiCATiONS Product Guidelines ............................70 Specifications ..............................70 Nominal Specifications ..........................71 dEFiNiTiON OF pACkAgE LABEL SyMBOLS Packaging Symbols: Q-TECH Programmer ....................72 Packaging Symbols: Q-TECH Programmer Wand ................. 73 WArrANTy Warranty ................................74...

  • Page 7: Description

    Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon description The Q-TECH Programmer (the “programmer”), Model 3200, is a component of the Cameron Health/ Boston Scientific S-ICD System, which is prescribed for patients when cardiac arrhythmia management is warranted. The other components of the S-ICD System include the SQ-RX Pulse Generator (the “SQ- RX device”), Q-TRAK Subcutaneous Electrode (“electrode”) and the Q-GUIDE Subcutaneous Electrode...
  • Page 8 Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon • The programmer is not waterproof or explosion-proof and it cannot be sterilized. Do not use it in the presence of flammable gas mixtures, including anesthetic mixtures containing air, oxygen, or nitrous oxide. • Confirm that the programmer is in communication with the intended implanted SQ-RX Pulse Generator.

  • Page 9: Electrostatic Discharge (Esd)

    Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon • Do not subject the programmer to temperatures outside of the -10° C to 55° C (14° F to 131° F) storage range. Exposure to high temperatures may cause the programmer to overheat or ignite, and may possibly reduce its performance and service life.

  • Page 10: Use Of Other Medical Therapies/Diagnostic Procedures

    Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon • The S-ICD System has not been evaluated for pediatric use. • The S-ICD System does not provide long-term bradycardia pacing, Cardiac Resynchronization Therapy (CRT) or Anti-Tachycardia Pacing (ATP). Use of Other Medical Therapies/diagnostic procedures •...

  • Page 11: Electromagnetic Interference (Emi) Outside The Hospital Environment

    Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon Electromagnetic interference (EMi) Outside the Hospital Environment Exposure to EMI or static magnetic fields may suspend tachycardia detection and possibly cause temporary inhibition of therapy delivery. EMI may also trigger delivery of a shock in the absence of a tachycardia.
  • Page 12 Q-TECH™ ProgrammEr: gEnEral dESCrIPTIon • Discomfort or prolonged healing of • Infection incision • Keloid formation • Electrode deformation and/or breakage • Migration or dislodgement • Electrode insulation failure • Muscle stimulation • Erosion/extrusion • Nerve damage • Failure to deliver therapy •...

  • Page 13: Setup Of The Q-Tech Programmer

    Q-TECH™ ProgrammEr: oPEraTIon Setup of the Q-TECH programmer packaging Programmer components include: • Model 3200 Programmer with pre-loaded software • Model 3203 Telemetry Wand • External power supply and AC power cord Visually inspect the packaging to ensure the contents are complete. Do not use if there is evidence of damage.

  • Page 14: Using The Q-Tech Programmer

    Figure 1: Connecting the external power supply Plug the external power supply cord into an AC power outlet. Using the Q-TECH programmer Turning the programmer On The programmer power button is located in the recess above and behind the left corner of the...

  • Page 15: Placing The Programmer In Suspend Mode

    Q-TECH™ ProgrammEr: oPEraTIon Power On/Off Figure 2: Turning the programmer On/Off Note: If the programmer cannot be turned on while it is connected to AC power via the external power supply, first unplug the external power supply cord from the programmer. Press and hold the programmer power button until the display screen is active (Figure 2).

  • Page 16: Turning The Programmer Off

    Q-TECH™ ProgrammEr: oPEraTIon Turning the programmer Off There are two ways to turn the programmer off: Press and hold the power button (Figure 2) until the System shutdown menu appears. Select Power off from the popup and confirm by pressing OK.
  • Page 17 Q-TECH™ ProgrammEr: oPEraTIon To connect the wand to the programmer, slide the wand cable connector over the communication connector port located on the rear edge of the programmer (Figure 4). To disconnect the wand, grasp the wand cable connector and gently pull it straight off the communication connector port.

  • Page 18: Navigation

    Q-TECH™ ProgrammEr: oPEraTIon Navigation The programmer’s graphic user interface (GUI) facilitates management and control of the S-ICD System. The Navigation Bar and on-screen icons at the top of the screen allow the user to navigate programming software screens. In addition, a continuous subcutaneous electrocardiogram (S-ECG) is displayed along the bottom of the screen during Online (active) communication with the SQ-RX device.
  • Page 19 Q-TECH™ ProgrammEr: oPEraTIon Table 1: Icon descriptions icon description User Application Main Menu Button Allows user to return to the main menu. Auto Setup Button Allows user to access the auto setup menu. Device Settings Button Allows user to access the SQ-RX device settings screen.

  • Page 20: Restarting The Programmer

    Q-TECH™ ProgrammEr: oPEraTIon restarting the programmer The programmer’s operating system is self-monitoring and is generally able to sense many system error conditions and automatically initiate a restart sequence in response. Follow the on-screen instructions to complete the programmer-initiated restart sequence.

  • Page 21: Configuring The Q-Tech Programmer

    Q-TECH™ ProgrammEr: oPEraTIon Configuring the Q-TECH programmer Configuring programmer Settings The programmer should be configured before communication with an SQ-RX device is attempted. This includes setting the date and time format, time zone, language and printer. Once these settings are configured during the initial setup process they become the default parameters and will not normally need to be changed with each session.
  • Page 22 Q-TECH™ ProgrammEr: oPEraTIon Figure 6: Programmer Settings screen Select the corresponding line to access each setting. The settings that can be configured include: • Date and time format • Time zone • Language • Printer...

  • Page 23: Date And Time Format

    Q-TECH™ ProgrammEr: oPEraTIon date and Time Format To set the date and time format: Select Set Date and Time Format on the Programmer Settings screen (Figure 6). The Date and Time Settings screen appears (Figure 7). Select the desired date format.

  • Page 24: Language Preference

    Q-TECH™ ProgrammEr: oPEraTIon Figure 8: Time Zone selection screen (scrollable list) Select the Save button to save the changes and return to the Programmer Settings screen, or select Cancel to return to the Programmer Settings screen without saving the changes.
  • Page 25 Q-TECH™ ProgrammEr: oPEraTIon Select Printer Setup on the Programmer Settings screen. A previously configured printer becomes the default printer and will be displayed at this time. If a default printer has not already been selected and configured, the programmer will scan the area to locate wireless printers.
  • Page 26 Q-TECH™ ProgrammEr: oPEraTIon Figure 10: Use the on-screen keyboard to enter a name for the selected printer Select the Save button to save the changes and return to the Programmer Settings screen, or select Cancel to return to the Programmer Settings screen without saving the changes.

  • Page 27: Programmer Software Version

    Continue button to return to the Programmer Settings screen. Note: The patient printed report contains the programmer software version. Modes of Operation for the Q-TECH programmer Online Behavior The programmer’s interface varies according to whether the programmer is Online (actively communicating) or Offline (not communicating) with a selected SQ-RX device.

  • Page 28: Offline Behavior

    Q-TECH™ ProgrammEr: oPEraTIon wand is moved out of the telemetry communications range or if noise or interfering objects inhibit communication. Programming commands, including Rescue Shocks, will not be available until telemetry is reestablished. Telemetry reconnection may occur automatically within one minute when the SQ-RX device and wand are within telemetry range.

  • Page 29: Modes Of Operation For The Sq-Rx Device

    Q-TECH™ ProgrammEr: oPEraTIon Modes of Operation for the SQ-rX device The SQ-RX device has three modes of operation: • Shelf • Therapy On • Therapy Off Shelf Mode The Shelf mode is a low power consumption state intended for storage only. When communication is initiated between the SQ-RX device and the programmer, a full-energy capacitor reformation is automatically performed and the SQ-RX device is prepared for set-up.

  • Page 30: Connecting And Disconnecting From The Sq-Rx Device

    Q-TECH™ ProgrammEr: oPEraTIon Connecting and disconnecting from the SQ-rX device This section provides the information necessary for selecting, connecting to, and disconnecting from the SQ-RX device. Scanning For SQ-rX devices Select the Scan For Devices button on the Startup Screen (Figure 13). The Device List screen appears after the Scan Progress Bar displayed during the scanning process.
  • Page 31 Q-TECH™ ProgrammEr: oPEraTIon When the scanning process is complete, a list of all SQ-RX devices detected (up to 16) will be displayed on the Device List (Figure 14). The SQ-RX devices that are in Shelf mode will be displayed as “Not Implanted. ” Any SQ-RX devices that were previously taken out of Shelf mode are displayed either as “Implanted”...

  • Page 32: Connecting To The Sq-Rx Device

    Q-TECH™ ProgrammEr: oPEraTIon Connecting to the SQ-rX device From the Device List screen, select the desired SQ-RX device to initiate the communication session. Note: Regardless of how many SQ-RX devices are located by a scan, the user must select an SQ-RX device from the list to begin active communication.

  • Page 33: Ending A Patient Session

    Q-TECH™ ProgrammEr: oPEraTIon Ending a patient Session To end an Online patient session and return the programmer to its Offline operation mode: Select the Main Menu button on the Navigation Bar. The Main Menu screen ap- pears. Select the End Session button (Figure 16).
  • Page 34 Q-TECH™ ProgrammEr: oPEraTIon Figure 17: Session incomplete message Note: Once the Continue button is selected, the session is stored and communication is terminated. Note: In order to confirm that Automatic Therapy is programmed On upon disconnection, always use the End Session process and review all displayed...

  • Page 35: Programming The Sq-Rx Device At Implant

    Q-TECH™ ProgrammEr: oPEraTIon programming the SQ-rX device at implant This section provides the information necessary for programming the SQ-RX device during an implant setting. Entering Electrode information The programmer maintains information on the implanted electrode. To record this information for a patient’s new or replacement electrode:...
  • Page 36 Q-TECH™ ProgrammEr: oPEraTIon Figure 19: Entering electrode information Select the Program button to save the information. A confirmation screen will appear during communication with the SQ-RX device (Figure 20). Select Cancel to cancel information storage and return to the Automatic Setup screen.

  • Page 37: Creating The Patient Chart

    Q-TECH™ ProgrammEr: oPEraTIon Creating the patient Chart This chart contains reference information for the patient. To set up the patient chart: Select the Main Menu button on the Navigation Bar. Select the Implant button (Figure 21). Figure 21: Select the Implant button to create a patient chart Select the Patient View icon to access the Patient View screen.
  • Page 38 Q-TECH™ ProgrammEr: oPEraTIon Figure 22: Patient Chart screen Note: The Notes field will automatically wrap the text with the presence of a space between any characters within the first line. Select the Save button to update the SQ-RX device with the patient information.

  • Page 39: Automatic Setup

    Q-TECH™ ProgrammEr: oPEraTIon Automatic Setup Before the SQ-RX device can be activated, it must go through an initial Automatic Setup Process at the time of the implant. The Automatic Setup Process is initiated as follows: Select the Main Menu button.
  • Page 40 Q-TECH™ ProgrammEr: oPEraTIon Figure 24: Measuring electrode impedance The progress of the Automatic Setup process is shown in the status bar. When each function is complete, the arrow next to the function moves to a down position. The Automatic Setup Sensing Optimization screen will be displayed. The programmer will display a message requesting that the patient sit up;...
  • Page 41 Q-TECH™ ProgrammEr: oPEraTIon Select the Continue button to finish the Automatic Setup process. A confirmation screen will appear when Automatic Setup is complete (Figure 26). Figure 26: Confirmation of successful Automatic Setup Following the optional optimization process, the Acquire Reference S-ECG screen is displayed (Figure 27).

  • Page 42: Programming Therapy Parameters

    Q-TECH™ ProgrammEr: oPEraTIon Once the Reference S-ECG acquisition process begins, a status screen appears. The process may take up to one minute, during which the patient should remain still. During this process, a template of the patient’s baseline QRS complex is stored in the SQ-RX device.
  • Page 43 Q-TECH™ ProgrammEr: oPEraTIon Select the On/Off Therapy switch to set the desired therapy mode (Figure 29). Figure 29: Setting the On/Off Therapy switch Select and drag the Conditional Shock Zone (yellow) and Shock Zone (red) slider bars to set the desired zone configuration.
  • Page 44 Q-TECH™ ProgrammEr: oPEraTIon Figure 30: Confirmation of programming Once programming is confirmed, select the Continue button to proceed to the next operation. Note: If any of the SQ-RX device settings are changed from the Device Settings screen and not subsequently programmed, the Pending Program Changes screen will appear.

  • Page 45: Defibrillation Testing

    Q-TECH™ ProgrammEr: oPEraTIon defibrillation Testing Once the SQ-RX device is implanted and Automatic Therapy is programmed On, defibrillation testing may be conducted. Note: Defibrillation testing is recommended at implant to confirm the ability of the S-ICD System to sense and convert VF.
  • Page 46 Q-TECH™ ProgrammEr: oPEraTIon Select either standard (STD) or reverse (REV) polarity (Figure 32). Select and drag the red marker to set the desired shock energy for the first delivered shock. The shock energy may be programmed from 10 to 80 J. A 15 J safety margin is recommended for defibrillation testing.
  • Page 47 Q-TECH™ ProgrammEr: oPEraTIon Select and hold the Hold To Induce button for the desired duration (Figure 33). Figure 33: Induction Test screen The following functions occur during the test: • The S-ICD System induces ventricular fibrillation using 200 mA alternating current (AC) at 50 Hz.

  • Page 48: Performing An Sq-Rx Follow-Up

    Q-TECH™ ProgrammEr: oPEraTIon Note: The SQ-RX device can deliver a maximum of five shocks per episode. At any time, an 80 J rescue shock can be delivered by pressing the Rescue Shock button. At any time prior to therapy delivery, the programmed energy may be aborted by selecting the red Abort button.
  • Page 49 Q-TECH™ ProgrammEr: oPEraTIon To view this information: Select the Main Menu button. Select the Follow Up button. Select the Device Status button on the Navigation Bar. The Device Status screen will appear showing an overview of all SQ-RX device activity since the last communication session (Figure 34).

  • Page 50: Viewing Stored Episodes

    Q-TECH™ ProgrammEr: oPEraTIon Viewing Stored Episodes The SQ-RX device stores up to 25 treated and 20 untreated tachycardia episodes, which can be viewed during a patient’s follow-up session. When the maximum number of episodes is exceeded, the most recent episode replaces the oldest stored episode; however, the first treated episode will not be overwritten.

  • Page 51: Printing Reports From The Programmer

    Q-TECH™ ProgrammEr: oPEraTIon Each selected Episode screen also displays the programmed parameters and the stored S-ECG data at the time of episode declaration. Select the Continue button to return to the Episodes pick list screen. The following details are available for each episode:...

  • Page 52: Summary Report

    Q-TECH™ ProgrammEr: oPEraTIon Select the desired report type. A checkmark will appear next to the selected report. Report types are described below. Select the Print button to print the selected reports. Select the Cancel button to return to the previously accessed screen.

  • Page 53: Captured S-Ecg Report

    Q-TECH™ ProgrammEr: oPEraTIon Captured S-ECg report To print a Captured S-ECG report: Select the Captured S-ECG Report button from the Print Reports pick list screen. A list of the captured S-ECG strips is displayed. Select the button next to the Cap- tured S-ECG(s) to be printed.

  • Page 54: Episodes Report

    Q-TECH™ ProgrammEr: oPEraTIon Episodes report To print an Episode Report: Select the Episodes Report button on the Print Reports pick list screen. The Episode List screen appears showing a list of the stored episodes (Figure 37). Select the button next to the episode(s) to be printed. A checkmark appears next to the selected episode(s).

  • Page 55: S-Ecg Features

    Q-TECH™ ProgrammEr: oPEraTIon S-ECg Features The programmer provides the capability to view, adjust and capture the streaming S-ECG from the SQ-RX device. S-ECg rhythm Strip Markers The system provides annotations to identify specific events on the S-ECG. These markers are shown in the S-ECG Markers on Programmer Display Screens and Printed Reports table (Table 2)and an example is shown in the Sample ECG Markers illustration (Figure 38).

  • Page 56: S-Ecg Scale Settings

    Q-TECH™ ProgrammEr: oPEraTIon S-ECg Scale Settings To adjust the real-time S-ECG amplitude and display speed scale settings: Select the S-ECG Display Settings icon located to the right of the Live S-ECG win- dow. The S-ECG Settings screen is displayed. Select and drag the Gain or Sweep Speed Scale bars as desired (Figure 39). The S-ECG scale will change according to the selected setting.

  • Page 57: Capture And View S-Ecg Strips

    Q-TECH™ ProgrammEr: oPEraTIon Capture and View S-ECg Strips The programmer can display, capture and store real-time S-ECG rhythm strips. The programmer saves a maximum of fifteen, 12-second, Captured S-ECG recordings comprised of: • 8.5 seconds before activation of the Capture S-ECG button •...

  • Page 58: Utilities Menu

    Q-TECH™ ProgrammEr: oPEraTIon Select and move the calipers across the S-ECG strip to measure intervals as desired. Select the Continue button to return to the previously accessed screen. To view a previously Captured S-ECG: Select the Main Menu button. Select the Follow Up button.

  • Page 59: Acquire Reference S-Ecg

    Q-TECH™ ProgrammEr: oPEraTIon Acquire reference S-ECg To acquire a manual Reference S-ECG: Select the Acquire Reference S-ECG button on the Utilities menu to access the Acquire Reference S-ECG screen. Select Continue to acquire a Reference S-ECG. The programmer will begin acquiring the Reference S-ECG.
  • Page 60 Q-TECH™ ProgrammEr: oPEraTIon Once an alert condition is triggered, audible tones beep for 16 seconds every nine hours until the alert condition is resolved. Beeper Control is automatically enabled when the SQ-RX device is taken out of Shelf mode. To reset the Beeper Control:...

  • Page 61: Manual Setup

    Q-TECH™ ProgrammEr: oPEraTIon Manual Setup Manual Setup enables the user to perform the electrode integrity test and select the electrode sensing configuration and gain setting in the SQ-RX device. From the Utilities Menu, select the Manual Setup button. The Impedance Test screen appears (Figure 45).
  • Page 62 Q-TECH™ ProgrammEr: oPEraTIon The gain setting adjusts the sensed S-ECG signal sensitivity. It may be manually selected via the Select Gain slider switch (Figure 46). Figure 46: Gain adjustment • 1x Gain (± 4 mV): 1x Gain should be selected when the signal amplitude is large enough to cause clipping when the 2x gain is selected.

  • Page 63: Smart Charge

    Q-TECH™ ProgrammEr: oPEraTIon To program the manually selected sense configuration: Select the Program button to save the sense vector and gain settings. The Acquire Reference S-ECG process is automatically enabled during the Manual Setup Process. Select the Continue button to acquire a reference S-ECG. A confirmation screen will appear when the captured reference S-ECG is acquired (Figure 47).
  • Page 64 Q-TECH™ ProgrammEr: oPEraTIon Figure 48: Reset Smart Charge screen Select the Reset button to reset the Smart Charge to zero or press Cancel to return to the Utilities Menu without resetting the Smart Charge. A confirmation window will appear with the message: “Smart Charge successfully reset.

  • Page 65: Additional Programmer Functions

    Q-TECH™ ProgrammEr: oPEraTIon Additional programmer Functions rescue Shock The Rescue Shock button is available on the programmer display when the SQ-RX device Setup Process is complete and an SQ-RX device is actively communicating with the programmer. During active communication, a maximum (80 J) rescue shock can be delivered upon programmer command.
  • Page 66 Q-TECH™ ProgrammEr: oPEraTIon Figure 50: Abort Rescue Shock A confirmation screen will appear with notification that the shock was delivered successfully along with the corresponding shock impedance (Figure 51). Figure 51: Confirmation of Rescue Shock delivery...

  • Page 67: Manual Shock

    Q-TECH™ ProgrammEr: maInTEnanCE If for any reason the shock could not be delivered, a red background screen will appear with a message stating “The Shock could not be delivered. ” Note: In the event telemetry is lost, SQ-RX device commands, including Rescue Shocks, will not be available until telemetry is reestablished.

  • Page 68: Charging The Programmer

    Q-TECH™ ProgrammEr: maInTEnanCE Other behaviors of magnet application: • Inhibit shock therapy delivery • Terminate post-shock pacing therapy • Prohibit arrhythmia induction testing • Activate the SQ-RX device’s beeper with each detected QRS complex for 60 seconds Note: A programmer commanded Rescue Shock can override the use of the magnet as long as the magnet was in place prior to the initiation of the programming command.

  • Page 69: Service

    Q-TECH™ ProgrammEr: maInTEnanCE Service There are no user-accessible or user-serviceable parts or components in the programmer. If any service, repair, or replacement of internal compontents is needed, the programmer must be returned to Cameron Health/Boston Scientific. Contact your Cameron Health/Boston Scientific Representative or the customer service department for instructions and return packaging.

  • Page 70: Troubleshooting

    Q-TECH™ ProgrammEr: TroUblESHooTIng TrOUBLESHOOTiNg This section presents potential programmer issues and the possible solutions. Of note, restarting the programmer can often resolve many of the issues listed below. The programmer can be restarted by pressing and holding the power button until the system shutdown menu appears and then choosing the “Restart”...

  • Page 71: Loss Of Communication With Printer

    Q-TECH™ ProgrammEr: TroUblESHooTIng Loss of Communication with printer When communication between the programmer and the printer fails, a Printing Error screen will appear with a message stating “Error while printing reports. Press “Continue” to try printing any remaining reports, or “Cancel” to cancel the current print job. ”...

  • Page 72: Compliance Statements

    Q-TECH™ ProgrammEr: ComPlIanCE STaTEmEnTS COMpLiANCE STATEMENTS Federal Communications Commission (FCC) US This transmitter is authorized by rule under the Medical Device Radiocommunication Service (in part 95 of the FCC Rules) and must not cause harmful interference to stations operating in the 400.150 - 406.00 MHz band in the Meteorological Aids (i.e., transmitters and receivers used to communicate...

  • Page 73: Declaration Electromagnetic Emission

    Table 4: Declaration Electromagnetic Immunity Part 1 The Q-TECH Model 3200 programmer is intended for use in the electromagnetic environment specified below. The customer or the user of the Q-TECH Model 3200 should assure that it is used in such an environment.

  • Page 74: Declaration Electromagnetic Immunity Part 2

    Table 5: Declaration Electromagnetic Immunity Part 2 The Q-TECH Model 3200 programmer is intended for use in the electromagnetic environment specified below. The customer or the user of the Q-TECH Model 3200 should assure that it is used in such an environment.

  • Page 75: Recommended Separation Distances

    Model 3200 programmer The Q-TECH Model 3200 programmer is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Q-TECH Model 3200 programmer can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Q-TECH Model 3200 programmer as recommended below, according to the maximum output power of the communications equipment.

  • Page 76: Specifications

    Q-TECH™ ProgrammEr: SPECIfICaTIonS Table 8: Product Guidelines Component requirement dC power Battery pack type 4000 mAh 3.7 volt lithium-ion battery pack Charge time Approximately 4 hours power Supply Input 100 – 240 VAC, 50 - 60 Hz, 0.5A Output 5.5 VDC, 3.64A...

  • Page 77: Nominal Specifications

    Q-TECH™ ProgrammEr: SPECIfICaTIonS Table 10: Nominal Specifications Characteristic Nominal Electrical Safety Testing – iEC 60601-1:2005 / ANSi/AAMi ES60601-1:2005 allowed values Earth resistance 100 mΩ Earth leakage current 5 mA Normal Condition (NC) 10 mA Single Fault Condition (SFC) Patient leakage current 100 μA Normal Condition (NC)

  • Page 78: Packaging Symbols: Q-Tech Programmer

    Q-TECH™ ProgrammEr: dEfInITIon of PaCkagE labEl SymbolS Table 11: Packaging Symbols: Q-TECH Programmer Symbol Specification Symbol Specification Type BF Applied Part Symbol – Indicates Manufacturer – Name and address of the connection of Type BF applied part manufacturer European Community Representative Storage Temperature –...

  • Page 79: Packaging Symbols: Q-Tech Programmer Wand

    Q-TECH™ ProgrammEr: dEfInITIon of PaCkagE labEl SymbolS Table 12: Packaging Symbols: Q-TECH Programmer Wand Symbol Specification Symbol Specification Non-Sterile Used to indicate the product is – Lot number – Batch code not sterile...

  • Page 80: Warranty

    Please contact your Cameron Health/Boston Scientific office or local representative for details. The warranty on the Q-TECH Programmer does not extend to any product that has been tampered with, altered, or repaired by any person other than an employee of Cameron Health/...
  • Page 82 Cameron Health, inc. Cameron Health BV 905 Calle Amanecer World Trade Center Suite 300 Nieuwe Stationsstraat 10 San Clemente, CA 92673 6811 KS Arnhem The Netherlands 1 800 CARDIAC (227 3422) 1 800 CARDIAC (227 3422) +1 651 582 4000 +1 651 582 4000 www.cameronhealth.com www.cameronhealth.com...
