IP Camera user guide

Thank you for choosing Sting

Please read this manual before using this product.

whole or in part without permission is prohibited

Need help?

Do you have a question about the IP Camera and is the answer not in the manual?

Questions and answers

Summary of Contents for Sting IP Camera

Page 1 IP Camera user guide IP Camera user guide Thank you for choosing Sting Please read this manual before using this product. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 2 This is what the zoomed image of a IP Fisheye camera normally looks like. This view is what you would normally see after installation of the camera, and upon initial DVR startup. IP Figure 1. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 3 In the below image, the name is “Camera 4,” this will show the options for the currently selected camera. IP Figure 2 Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 4 We will start with the PIP (Picture In Picture) function. This feature allows us to zoom in on a specified area of the image and keep an overview shot in a floating window. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 5 PIP View: The PIP (Picture In Picture) function allows us to focus on a portion of the currently viewed IP camera and maintains a small shot overview in a floating window in the frame. To select the PIP function, click on the PIP View option. To return to the normal image, Right click on the image anywhere, point to the camera name, then click PIP View again to remove the check mark.
Page 6 IP Camera user guide Enabling the PIP function will bring us to the following image. IP Figure 5. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 7 Clicking the mouse button and dragging the corner will resize the zoom ration and the focus area. IP Figure 7. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 8 Overview image, outside of the Focus area, and drag the Overview image to a better location on the screen. IP Figure 8. This concludes our section on PIP View. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 9 The PAP feature allows us to select multiple Picture In Picture focus areas simultaneously without using multiple cameras. To select the PAP feature, right click anywhere on the IP camera image, point to the camera name (In this example, we are using Camera 4) and...
Page 10 IP Figure 10. While in the PAP mode, the Mega Pixel Setting becomes available to us. Let’s explore that option now. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 11 This option allows us to change the outline of the Focus area to something that may better suit the background of the shot overview. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 12 Focus Area of PAP Mode, then click Delete IP Figure 12. This concludes our section on the Picture And Picture feature. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 13 This view shows us a single enhanced view. In order to provide depth to the image, the PTZ function is more limited than the other views in this view. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 14 (In this example, we are using “Camera 4,”) Then click Geo Fisheye. The default function is the Quad feature, and the software will display the quad image. IP Figure 13. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 16 This opens a dialog to adjust the cameras’ Frame Rate, Screen Ratio (for Widescreen Monitors), Wall Mount 180 View (also for Widescreen Monitors) and Show Original Video in Low Resolution. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 17 This option switches between the 4 Camera modes of the Fisheye These modes include: Quad View, 360 Degree, Dual 180 Degree, and Single View. IP Figure 15. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 18 Fisheye shot automatically in a circular pattern. The options include High Speed, Medium Speed, and Low Speed. IP Figure 17. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 19 Show Source Video at Top-Right Channel This option, when selected will show the Fisheye shot overview in the upper right corner of the quad. IP Figure 18. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 20 This opens a dialog to adjust the cameras’ Frame Rate, Screen Ratio (for Widescreen Monitors), Wall Mount 180 View (also for Widescreen Monitors) and Show Original Video in Low Resolution. IP Figure 19. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 21 To access the 360 Degree function, Right click the Fisheye image, point to Fisheye Option, then Camera Mode, Click on Geo Fisheye: 360 degree IP Figure 20 Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 22 Fisheye camera. The live view will follow the object, or person until it leaves the range of the camera. IP Figure 21. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 23 (Masking Region), the size of the object to be tracked (Object Size), and a schedule to adhere when tracking (Schedule). IP Figure 22. IP Figure 23. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 24 This view shows us two 180 degree views stacked in our viewing window. To rotate the camera, click in one of the images, and drag your mouse left or right. IP Figure 24. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 25 This view shows us a single enhanced view. In order to provide depth to the image, the PTZ function is more limited than the other views in this view. IP Figure 25. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
Page 26 PIP View: The PIP (Picture In Picture) function allows us to focus on a portion of the currently viewed IP camera and maintains a small shot overview in a floating window in the frame. PAP Function (Picture And Picture) The PAP feature allows us to select multiple Picture In Picture focus areas simultaneously without using multiple cameras.
Page 27 This view shows us a single enhanced view. In order to provide depth to the image, the PTZ function is more limited than the other views in this view. Fifure 26. Copyright ©2012 Sting Alarm, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited...
