- Page 1 One Touch Y580 Quick Start...
-
Page 2: Table Of Contents
Safety and use ......................2 1. Overview ......................... 3 1.1 Contents in the package ................3 1.2 Application ....................3 1.3 Device overview ....................4 1.4 Turn on device ....................5 1.5 Screen display .................... -
Page 3: Safety And Use
Safety and use We recommend that you read this chapter carefully before using this device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of this device or of use contrary to the instructions contained herein. Do not switch on your device when the device use is prohibited or when the device use may cause interference or danger. -
Page 4: Overview
1. Overview One Touch Y580 is a portable wireless router, can provide a simple way to share 3G with any Wi-Fi embedded device. 1.1 Contents in the package ● One Touch Y580 ● USB cable ● Battery ● Quick start guide ●... -
Page 5: Device Overview
1.3 Device overview Fig 1.2 Number Description Micro USB interface OLED screen Power on/off button Connect button WPS/Wake up button Reset button Tab 1.1... -
Page 6: Turn On Device
The description for the four buttons as below: Button Description 3. Power On/Off Slide to turn on/off the device press and hold 2 seconds to connect/disconnect to the 3G 4. Connect network Short press to wake up or sleep the OLED screen 5. -
Page 7: Screen Display
Step 2: Slide the Power On/Off button to the position as bellow: Fig 1.4 1.5 Screen display The description for the Screen as bellow: Fig 1.5 Network Signal( Dynamic graphical symbol ) Network type (3G+/3G/2G) SMS status(Full, unread, incoming) Connection status(Connected and Disconnected ) Wi-Fi (Number of user connected/WPS connection) Battery level(Dynamic graphical symbol/In charge) Name of the network registered... -
Page 8: Connect In Wi-Fi Mode
Screen description: Category Icon Display Signal Strength From 1 signal to excellent signal Network type : Edge/GPRS : UMTS/HSDPA/HSUPA : HSPA+ :SMS is available SMS status :Unread SMS :SMS is full Connection Status connected : Wi-Fi is active :Number of Wi-Fi user Wi-Fi status :WPS is active... -
Page 9: Quick Setup
From a Mac computer: Select System Preferences -> Network->Airport. Click “Advanced” to choose Y580*_XXXX from the list of available networks. From an iOS device: Settings->Wi-Fi. Choose from the available Y580*_XXXX Networks. From an android device: Settings->Wireless controls->Wi-Fi settings. Choose from the available Networks. Y580*_XXXX Step 2: Enter the Wi-Fi key when prompted for a security key. - Page 10 Fig 2.2 Wi-Fi Settings: SSID: Set the network name of this device. l Security: Configure the security mode for Wi-Fi connection. l...
-
Page 11: Battery Charging
Fig 2.3 3. Battery Charging There are two types of charging, one is via Main charger, the other is via PC USB cable. And the mains charger is recommended. Main charger: When power off, it will take a maximum of 3 hours. PC USB Cable: When power off, it will take a maximum of 4 hours.
