Summary of Contents for Crunch CRS4.0cx
- Page 1 SPEAKERS CRS4.0cx / crS5.25cx crS6.5cXs / crS6.53 crS693...
- Page 2 CRUNCH SERIES FULL RANGE CAR AUDIO SPEAKERS Congratulations on your purchase of the new Crunch Series speaker system. The Crunch speaker series offer superior sonic accuracy, intense high power sound quality with exotic build materials and outstanding good looks. Impact Resistant Tweeter Elements...
- Page 3 SPEAKER LOCATION AND MOUNTING TIPS THE FIRST STEP IS THOROUGH PLANNING BEFORE THE INSTALLATION BEGINS. THE SPEAKER SCREW HOLE CONFIGURATION WILL WORK WITH MOST DOMESTIC AND FOREIGN VEHICLES. FOLLOW THESE INSTRUCTIONS CAREFULLY TO ENSURE PROPER IMAGING AND MAXXIMUM PERFORMANCE. Factory Speaker Replacement Location and Installation 1.
- Page 4 COAX & 3-WAY MOUNTING & WIRING PROCEDURES Rear Deck Mount Speaker Grill Mounting Screws Spacer Ring Speaker Inner Metal Door Panel Door Mount Interior Door Panel Speaker Speaker Grill Speaker Screws Factory Grommet Wire Routing Speaker Wires Inner Metal Door Panel Wire Connections Amplifier Black...
- Page 5 SPEAKER DIMENSIONS CRS4.0CX CRS5.25CX 3.69” 4.48” CRS6.53 CRS6.5CXS 5.59” 5.59” CRS693 CRS693 8.7” 6”...
- Page 7 Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, Autotek, MB Quart, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
- Page 8 PART#: U0310...
