  • Page 1 FIR151B/300B/302B/303B Wireless Router User Manual...

  • Page 2: Table Of Contents

    4.2.10 Application 4.2.11 Dynamic DNS 4.2.12 Routing settings 4.2.13 Bandwidth control 4.2.14 IP und MAC binding 4.2.15 Logout Troubleshooting Technical support – contact us Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 1 of 49...
  • Page 3 Customers shall bear the risk for any and all effects including incompatibility between the software and this product, which result from installing software or uploading or downloading the third-party works. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 2 of 49...
  • Page 4 The louder the volume, the less time is required before your hearing could be affected. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 3 of 49...
  • Page 5 These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as dust or metal powders. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 4 of 49...
  • Page 6 Avoiding contact with the antenna area when the device is in use optimizes the antenna performance. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 5 of 49...
  • Page 7 PHICOMM is entitled to use new or reconditioned replacements parts or boards for repairs under warranty, provided they have the same functionality as the parts to be replaced.
  • Page 8 If you need detailed information about other active implantable medical devices, please consult your doctor to ensure the magnetic interference of such active implantable medical devices. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 7 of 49...

  • Page 9: Package Contents

    An unofficial operating system can cause security risks. Please install only official • updates provided by Phicomm, if not you will void the warranty and a repair is chargeable. SW-Update During the update process all user data will be erased. Please backup your data •...
  • Page 10 Summary of changes Issue Issue date Remarks September 2014 Initial release Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 9 of 49...

  • Page 11: About The User Manual

    1.2 Used symbols and fonts The following symbols are used in the user manual: DANGER! WARNING! May result in personal injury Note Useful additional information Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 10 of 49...
  • Page 12 Example: Click <Ctrl> + <Alt> + <Delete> to open the task manager. > Used for menu sequence Example: Click File > Print to print. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 11 of 49...
  • Page 13 R&TTE Directive 1999/5/EC EMC Directive 2004/108/EC Low Voltage Directive 2006/95/EC Date: July 8, 2014 Jie Hu Manager for Product Certification Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 12 of 49...
  • Page 14 • Contact dealer or manufacturer • Any use not expressly approved by PHICOMM changes to the device will invalidate the guarantee. This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This router and its antenna / antennas must not be operated in the immediate vicinity of other radio wave emitting devices / antennas.
  • Page 15 The routers of the FIR series are all-in-one router for home and SOHO users to share broadband internet connection over a wired or a wireless network. The speed of up to 300 Mbps (FIR151B up to 150 Mbps) provides users with extraordinary smooth internet surfing, internet phone calling and online gaming.
  • Page 16 If you use an Ethernet cable, please connect RJ with the WAN port directly (steps 1-2 to 4) Note The connections might vary by models. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 15 of 49...

  • Page 17: Tcp/Ip Settings

    Network and Sharing Center and select Change adapter settings on the upper left of the screen. 2. Select network connection type and open the Properties. In the Properties window please double click Internet Protocol Version 4 (TCP/IPv4). Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 16 of 49...
  • Page 18 3. Select both Obtain an IP address automatically and Obtain DNS server address automatically. Click OK to confirm the configuration. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 17 of 49...
  • Page 19 To confirm the settings on all pages please click Save. By clicking Cancel you always will return to the former page. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 18 of 49...

  • Page 20: Setup Wizard

    Type in those information and click the Save button. Wireless Security Wireless network name Define SSID to any other name you prefer or keep it (SSID) unchanged. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 19 of 49...

  • Page 21: Network Settings

    The router connects wired or wireless with the network / internet. The router acts as a central connection point, which wireless clients can connect to. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 20 of 49...
  • Page 22 If the WAN port network segment is 192.168.2.X, go to LAN Settings page to modify LAN IP port to other network segments (for example 192.168.2.1) to avoid conflicts. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 21 of 49...
  • Page 23 MAC Clone Some internet service providers require the registration of your computer’s MAC address. If you want to clone the MAC address select Enabled. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 22 of 49...

  • Page 24: Wireless Settings

    If the devices use different transmission modes, select 11b/g/n Mode. SSID Broadcast If you choose Enabled, the wireless router will broadcast the SSID name. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 23 of 49...
  • Page 25 1. Select Enabled under Wireless MAC Filtering. 2. Select Blocked or Allowed under Filter Options. 3. Fill 00:0A:EB:00:07:5F in Add MAC Address. 4. Click Add/Save button. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 24 of 49...

  • Page 26: Health And Power Saving

    It will impact the performance and the coverage of the wireless. 3. Set time in Time Settings (day, week) and Time Settings (hour) separately. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 25 of 49...

  • Page 27: Running Status

    There are IP addresses, subnet masks, default gateways, SSID, hardware- and software-versions etc. Press Refresh button to refresh the Device Information list. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 26 of 49...
  • Page 28 Last address in the IP address pool DHCP Clients List Refresh Click the button to refresh the DHCP clients list Wireless Clients Click Refresh button to check the wireless clients. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 27 of 49...
  • Page 29 Traffic Statistics Check the traffic statistic results and the packet intervals. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 28 of 49...

  • Page 30: System Tools

    Software Upgrade Update software Configuration File Backup and restore the configuration Management Note All user settings will be deleted when factory reset is enabled. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 29 of 49...
  • Page 31 If the web management port conflicts with the ports of virtual server and DMZ entry, when you start the remote management, the virtual server and DMZ entry will not work. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 30 of 49...
  • Page 32 • Enter Number of Ping Packages, Ping Packet Size and Tracert Hops. • Click Start. • You will see the results in Diagnostic Results. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 31 of 49...
  • Page 33 System Log If you want to set more detailed settings, select Advanced beside the Basic button at the top of the screen. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 32 of 49...

  • Page 34: Wireless Advanced Settings

    MAC address of the connected device into the routers AP MAC address table. The connected client should be in Lazy, Repeater or Bridge Mode. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 33 of 49...
  • Page 35 Establish easy and quick a connection between router Settings) and client device through encrypted contents. The users only enter the PIN code to configure. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 34 of 49...
  • Page 36 RTS to the destination station to start a negotiation (default = 2347). Fragment Threshold Sets the fragment threshold. Packets larger than the size Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 35 of 49...
  • Page 37 End IP Address Last address in your IP address pool Lease Time This is the time interval, after the server uses a different DHCP address. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 36 of 49...
  • Page 38 Rules (supports up to 16) IP address IP address, reserved for routers MAC address MAC address of the PC for which you want to reserve an IP address Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 37 of 49...

  • Page 39: Security Settings

    If the number of ICMP data packets exceeds the Threshold threshold, the defense measures act immediately. Open the UDP-Flood Attack Select to protect against UDP-FLOOD attacks. Filtering Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 38 of 49...

  • Page 40: Parental Control

    You must set at least one filtering condition. You may also set multiple conditions or all conditions. Note Please synchronize the router’s time first, if selecting the timing function. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 39 of 49...
  • Page 41 URL Filtering Enter the URL address you want to filter in the URL box. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 40 of 49...

  • Page 42: Application

    Port range of the server you want to open. Protocol Protocol of the server. Note Please assign a static IP address to the server. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 41 of 49...
  • Page 43 DMZ priority is higher than the port forwarding. If the DMZ is open, all port forwarding rules are not effective. UPnP Select Enabled or Disabled. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 42 of 49...

  • Page 44: Dynamic Dns

    (e. g. www.no-ip.com). After registration please select your service provider and enter Username, Password and Dynamic DNS Domain Name. 4.2.12 Routing Settings Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 43 of 49...

  • Page 45: Bandwidth Control

    IP Bandwidth Settings Select Enabled or Disabled. Total Upstream Bandwidth Rate of uploading through WAN interface Total Downstream Bandwidth Rate of downloading through WAN interface Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 44 of 49...

  • Page 46: Ip Und Mac Binding

    ARP deception effectively. Menu item Explanation Static ARP Binding IP address IP address of the LAN PC MAC address MAC address of the LAN PC Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 45 of 49...

  • Page 47: Logout

    4.2.15 Logout Click Logout to exit from the router’s configuration page. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 46 of 49...

  • Page 48: Troubleshooting

    • Check whether the wireless channel conforms to the channels available in your country / area. • Retry using another Ethernet cable. • Check if all cables are connected correctly. Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 47 of 49...

  • Page 49: Technical Support - Contact Us

    For detailed product information and Downloads (software, user manuals and certificates) please visit our website: www.phicomm.com/de for Germany www.phicomm.com/eu for Europe www.phicomm.com Phicomm Global Copyright @ 2014 Phicomm Europe GmbH – print only for private use! page 48 of 49...
