I N S T A L L A T I O N
D I A G R A M P A R A L L E L
If caller ID or ringing issues arise with the IN-LINE setup then change to a PARALLEL
connection.
Connect the additional line cable
from the splitter to the LINE 2 port
Additional
Line Cable
Telephone
F O R O U T S I D E T H E U K
Line Cable
Main Wall
Socket
Splitter
4
