  • Page 1 Configuration manual – v2.5...

  • Page 2: Table Of Contents

    Contents Important considerations ....................3 Introduction ........................4 Configuration ..................................4 Multitask ....................................8 Program installation ......................9 Installation ................................... 9 First steps ........................10 General vision ................................... 10 Room management ................................ 11 Device management ............................... 12 Diagram functions ................................13 Devices ..........................14 Simple light / 1 bit generic control ..........................
  • Page 3 Information, data and values of these documents can be changed without prior warning. Technical information can also be changed without notice. iTunes, App Store, iPhone, iPod and iPad are commercial brands of Apple Inc. Houseinhand® is a commercial brand of Intesis Software S.L.

  • Page 4: Important Considerations

    Important considerations Some KNX / IP Routers – Gateways only allow one simultaneous active connection, preventing that more than one iPhone/iPad is connected at the same time. Besides, in situations with low WIFI coverage, it is possible that the application does not reconnect as it should, then it appears the error of maximum number of simultaneous connections.

  • Page 5: Introduction

    Now, the application will execute in demonstration mode. You can see a sample of the interface and navigate through the menus, but not controlling your house. To allow Houseinhand® to control your house, two files must be transferred to it:  xxxxxxx.cfg: This file contains the necessary configuration information for the application to recognize your house.
  • Page 6 Send the file you want to load to the mail account configured in your device. Launch Mail app and open the mail you have sent. Click on the file you want to load and select “Open with Houseinhand” That is all. Houseinhand® will be opened with the file load automatically.
  • Page 7 Another way to transfer the files to your device is the File Sharing method. Open iTunes. Select the device you want to configure in the left side bar. Select the Applications tab.
  • Page 8 ‘File Sharing’ and select Houseinhand®. Click in the button ‘add’ and select the files. That is all. Next time you start Houseinhand® in your device, the application will recognize your house and it will be ready to control it (please see next section,...

  • Page 9: Multitask

     Press twice the Home button (physical button in the lower part of your device).  Once the multitask bar is opened, keep the finger on any of the icons until they start to tremble.  Press on the red button that appears in the Houseinhand® icon and the application will close completely.

  • Page 10: Program Installation

    Program installation Installation In order to be able to configure the house, it is necessary to download Houseinhand Designer from the download section of the web site www.houseinhand.com Once the program is downloaded, execute the installer. It will appear a window as the one below: Once selected the directory where the program will be installed, press “Install”...

  • Page 11: First Steps

    First steps General vision Now, launch the program from the desktop shortcut. The main window of the application will appear. From there, you can create a new configuration, modify an existing one, export the current configuration and consult the user’s guide. As we will see later, the structure of the configuration is carried out hierarchically, that is to say, it is necessary to create every room (that would be the top level) and, later, adding all those devices that this room should have.

  • Page 12: Room Management

    Room management The management of the different rooms of the house is carried out using the add/delete/duplicate buttons. When adding a room, there will appear the name, PIN, color (only for the iPad version) and room image options.

  • Page 13: Device Management

    Device management Same as previous case of adding a room, the Add/Delete buttons allow the devices management inside a room. To add a device click the add device button. Next, we will be asked the name, device family and the type of the device we want to control.

  • Page 14: Diagram Functions

    The up/down buttons allow the user to change the order of the devices and rooms. Houseinhand® will display the devices and rooms in the same order as they are displayed in Houseinhand® Designer.

  • Page 15: Devices

    Devices Simple light / 1 bit generic control These two types of devices correspond to the Boolean control of lights or generic on/off elements. Moreover, they include a status field that can be enabled to allow device status monitoring. The status enabling: Enable status: When active, status from the selected device is returned.

  • Page 16: Byte Generic Control

    1 Byte Generic control This type of device allows the adjustment of up to 5 values (each one from 0 to 255), in just one 1 Byte group address. Moreover, it allows personalizing the text of each segment to help the user to easily identify the functionality of each segment and activating a status flag to monitor the status of the device The status enabling: Enable status: When active, status from the selected device is returned.
  • Page 17 Third value to send (0-255): Value that will be sent when tapping this segment, through the 1 byte group direction. Text third value: Text that will appear in the corresponding segment. Fourth value to send (0-255): Value that will be sent when tapping this segment, through the 1 byte group direction.

  • Page 18: Dimmer

    Dimmer This type of device corresponds to the adjustable control of lights. The group addresses to configure are: On/Off 1bit: 1bit On/Off control communication object. Value 1Byte: 1Byte control group address. Status 1Byte: value status feedback. For the correct functioning of the device, it is important to check that the reading flag for the status 1Byte has been enabled in ETS.

  • Page 19: Rgb Light

    RGB Light This type of device corresponds to the RGB light control. The group addresses to configure are: Red Value 1Byte: red control communication object. Green Value 1Byte: green control communication object. Blue Value 1Byte: blue control communication object. Red Value Status 1Byte: red color status communication object. Green Value Status 1Byte: green color status communication object.

  • Page 20: Position Controlled Blind

    Position controlled blind This type of device corresponds to the position controlled blinds. The group addresses to configure are: Stop-movement 1bit: it allows to lift up/down the blind slightly (in some blind actuators), or in case it is moving, stop it. Up-down 1bit: it allows lifting up/down the blind continually, or in case it is moving, stopping it.

  • Page 21: Simple Blind

    Simple blind This type of device corresponds to the simple blind control. Due to the simple blind not having a status feedback, we recommend using the type of adjustable blind as long as it is possible. The group directions to configure are: Stop-movement 1bit: it allows to lift up/down the blind slightly (in some blind actuators), or in case it is moving, stop it.

  • Page 22: Gradhermetic® Blind

    Gradhermetic® blind This kind of device corresponds to the Gradhermetic® blind control. The group addresses to configure are: Lifting up blind/open slats: must match the corresponding actuator. Lifting down blind/close slats: must match the corresponding actuator. It is not required to use the central function to control the two actuator channels at the same time.

  • Page 23: Velux® Blind

    Velux® blind This kind of device corresponds to the Velux® blind control. The group addresses to configure are: Lifting up blind: must match the corresponding actuator. Lifting down blind: must match the corresponding actuator. It is not required to use the central function to control the two actuator channels at the same time.

  • Page 24: Climate Control (1 Bit)

    Climate control (1 bit) This kind of device corresponds to the climate mode control with 1 bit group addresses. The group addresses to configure are: Comfort mode 1bit: comfort mode. Standby mode 1bit: standby mode. Extremes protection 1bit: extremes protection mode. Block controller 1bit: thermostat’s controller blocking.

  • Page 25: Climate Control (1Byte)

    Climate control (1Byte) This kind of device corresponds to the climate mode: The group directions to configure are: Select KNX mode 1Byte: temperature mode selection (comfort, standby, night and protection against extremes). Controller block 1bit: thermostat’s controller blocking. Leave it blank does not limit any functionality.

  • Page 26: Cool/Heat Mode

    Cool/Heat mode This type of device corresponds to the cool/heat control mode. The group addresses to configure are: Cool/Heat: Communication object for the 1 bit cool/heat climate mode. Modification status 1Bit: Current climate mode status 1 bit. For the correct functioning of the device, it is important to check that the reading flag of the feedback in the ETS has been activated.

  • Page 27: Temperature Control

    Temperature control The group addresses to configure, in the case of the direct control of the temperature, is: Set-point Output 2Byte: set-point temperature control. Set-point Input 2Byte: set-point status. For the correct functioning of the device, it is important to check that the reading flag in the ETS has been activated.

  • Page 28: Jung® Thermostats Temperature Control

    JUNG® thermostats temperature control This type of device is used for the JUNG® thermostats control, where it is not allowed to modify the set-point temperature through the 2 bytes group address. By the means of the 1Byte group address used, we get the same behavior than the thermostat adjustment wheel.

  • Page 29: Berker® Thermostat Temperature Control

    Berker® thermostat temperature control ® The group address that needs to be configured, in case of the Berker thermostat temperature control, is: Set-point output 2Byte: set-point temperature control. Set-point input 1Bit: set-point temperature forward value (set-point status). For the correct functioning of the device, it is important to check that the reading flag of the feedback in the ETS has been activated.

  • Page 30: Viewers

    Viewers This type of device is used to monitor different variable parameters such as temperature, rain, wind, luminosity… Viewer type Variable length Units Temperature 2 bytes ºC Temperature 2 bytes ºK Temperature 2 bytes ºF Humidity 2 bytes Pressure 2 bytes Air quality 2 bytes Power...

  • Page 31: Central Functions (General Turn Off, Lower Blinds, Presence Simulator)

    Central functions (general turn off, lower blinds, presence simulator) The group addresses to configure are: Central function 1bit: programmed central function. Besides, it is necessary to configure the following parameter: Sending value 1: if this checkbox is enabled the value to send on the previously indicated group address will be 1.

  • Page 32: Knx Scenes

    KNX Scenes The group address to configure is: Scene address 1Byte: programmed KNX scene. Besides, it is necessary to configure the following parameter: Scene number 1Byte: Scene number to activate (between 1 and 256).

  • Page 33: Technical Alarms

    Technical alarms The group address to set up is: Alarm state 14Bytes: text configured in the case of alarm.

  • Page 34: Door Communication System (Jung® Dcs, Tcs®)

    Door Communication System (JUNG® DCS, TCS®) The fields to set up are: Private IP: IP address corresponding to the video-streamers private IP. Public port: Port used by the application to connect from outside without VPN (NAT). For further information about remote connections please refer to the manual “Remote setup without VPN”...

  • Page 35: Door Communication System - Knx

    Door Communication System - KNX (with Axis® and Mobotix®) The fields to set up are: Device type: Select if the image source is from Axis® or Mobotixi® IP camera. Private IP: IP address corresponding to the private IP of the IP Camera. The application adjusts the bandwidth and quality.

  • Page 36: Axis® & Mobotix® Ip Cameras

    Axis® & Mobotix® IP Cameras The fields to set up are: Device type: Select if the image source is from Axis® or Mobotix® IP camera. Private IP: IP address corresponding to the private IP of the IP Camera. Public port: Port used by the application to connect from outside without VPN (NAT).
  • Page 37 Generic IP Camera The fields to set up are: - Type of device: Select that the image source is a Generic IP camera. - Private IP destination: IP address corresponding to the private IP of the IP Camera. - Remote IP destination: Port used by the application to connect from outside without VPN (NAT).

  • Page 38: Av Control (Irtrans®)

    AV Control (IRTrans®) The fields that need to be configured are: Private IP: Private IP address of the IRTrans® module. Private port: Private port used by the application to connect to the IRTrans® module from inside. The default value is 21000. Public port: Port used by the application to connect to the IRTrans®...

  • Page 39: Full Tv Remote

    The rest of fields are about the labels assigned to the IRTrans® module to control each function. To make the process even more straight-forward, Houseinhand Designer assigns this labels as default labels. If you setup the IRTrans® following this, no more configurations will be needed. If you want to use custom labels, just edit the fields.

  • Page 40: Multipurpose Multimedia Remote

    Multipurpose multimedia remote eject on/off left mute right down chUP volUP volDOWN chDOWN stop skipR skipL pause play backward forward...

  • Page 41: Multimedia Irtrans® Macro

    Multimedia IRTrans® Macro The fields that need to be configured are: Private destination IP: IP address that corresponds to the IRTrans® module. Private destination port: Port used for the app to connect locally with IRTrans®. Port 21000 is the one used by default. Public destination port: Port used by the application to connect remotely to IRTrans®.
  • Page 42 module configuration” or check the manuals available in the manufacturers website: http://www.irtrans.de/en/download/ First function: label of the first command to be sent. First delay: Delay (in seconds) that will apply before the next command is sent. Second function: label of the second command to be sent. Second delay: delay (in seconds) that will apply before the next command is sent.

  • Page 43: Av Control (Global Cache®)

    AV Control (Global Cache®) The fields that need to be configured are: Private IP: Private IP address of the Global Cache® module. Private port: Private port used by the application to connect to the Global Cache® module from inside. The default value is 4998. Public port: Port used by the application to connect to the Global Cache®...

  • Page 44: Global Cache Macro

    ® Global Cache Macro The fields that need to be configured are: ® Private destination IP: IP address of the IP module from Global Cache Private destination port: Port used by our application to locally connect ® with Global Cache .
  • Page 45 Those commands correspond to the IR frames learned with the program iLearn (available in the manufacturer website). Example: sendir,4:1,1,36000,1,1,96,32,16,32,16,16,16,48,48,16,16,16,16,16,16,16,16,16,16,1 6,16,16,16,3024,96,32,16,32,16,16,16,16,48,48,16,16,16,32,15,16,32,16,16,16,720 For more information on how to learn the IR commands, please check the manuals from Global ®.

  • Page 46: Finishing Configuration

    Finishing configuration Web site and integrator image Houseinhand® allows personalizing the application in order that a link shows up (and takes you to the web site of the integrator), as well as an image or logotype. To introduce the image, it is necessary to attach to the application (by means of the...
  • Page 47 For the link with the web site to appear, it is necessary to introduce it in the field “Integrator’s web site”, in the upper right corner of the application.

  • Page 48: Export Configuration File

    Export configuration file Once finished the configuration, the last step consists of exporting the file in order to introduce it in the final device. For that purpose, it will be necessary to select the button “Export Config”, appearing a window as the one below: Once the name and destination are introduced (it can be any name, as long as it has the extension .cfg), you will press the button ‘save’.

  • Page 49: Obtaining A License

    Though the captures that appear later are that of the iPhone, the procedure in case of being an iPad is the same. 1. From the Houseinhand start window, Access the info window. 2. Once in the info window please press the UDID button:...
  • Page 50 Houseinhand Sales Partner sales@ houseinhand.com, indicating the reference of the order in the concept and the type of license to assign to each device. The references for each license are the following: LICENSE TYPE / DEVICE REFERENCE iPhone / iPod...
