microphone user guide
f o r a l l P h o n i c E a r m i c r o p h o n e s
AT0655 behind-the-neck boom mic
AT0655M behind-the-neck boom mic with mute
AT0655R behind-the-neck boom mic for Radium
AT0814 earhook mic
AT0814M earhook mic with mute
AT0816 FM collar mic
AT0817 infrared collar mic
AT0164-L omni-directional lapel mic
AT0667-L omni-directional lapel mic
AT0291-L directional lapel mic
AT0668-L directional lapel mic
Advertisement
Table of Contents
Summary of Contents for Phonic Ear AT0655
- Page 1 P h o n i c E a r m i c r o p h o n e s AT0655 behind-the-neck boom mic AT0655M behind-the-neck boom mic with mute AT0655R behind-the-neck boom mic for Radium...
- Page 2 AT0655 /AT0655M/AT0655R behind-the-neck boom mic The AT0655 boom microphone is a lightweight, noise-canceling microphone worn on the head. It is used in very noisy environ- ments or with a sound field system. Clip Flexible Gooseneck Small Clip Bend headband to suit head size...
- Page 3 AT0513 over-the-head boom mic The AT0513 boom microphone is a lightweight, noise-canceling microphone worn on the head. It is used in very noisy environments or with a sound field system. Headpad Earpad Microphone Adjust earphone and headpad to fit comfortably over head RIGHT EAR 2.5cm –...
- Page 4 AT0795-L infrared lapel mic The AT0795-L infrared lapel microphone is a lightweight, noise- canceling microphone worn around the neck. It is used with the sound field system. OCALIGHT Mic plug Microphone Slide metal clip on back of lapel mic through holes on plastic lavalier holder Plastic lavalier...
- Page 5 AT0814/AT0814M earhook mic The AT0814 boom microphone is a lightweight, noise-canceling microphone worn over the ear. It can be used with S OLARIS PRITE or E transmitters. ISTENER Microphone Ear piece Mute Switch (AT0814M only) Clip plug Pull earpiece forward and place earhook over ear Use clip to secure cord to clothing Insert plug into...
- Page 6 AT0816/AT0817 collar mic (check for availability) The collar microphone is a lightweight, noise-canceling microphone worn around the neck. It is used in very noisy environments or with a sound field system. FM mic Infrared mic (AT0816) (AT0817) Microphone Microphone Mute Switch Infrared Emitter...
- Page 7 AT0720 conference mic The conference microphone is a small, unobtrusive omni-directional condenser microphone. It is designed for communication in meetings, round table discussions, or split-table communications. For range greater than 3m/10ft, use the PE 300T, 571T, 471T AT0721 y-cord to use two conference mics or 481FST PE 300T, 571T, 471T Connect...
- Page 8 * No windscreen with AT0164-L omni-directional mic u.s.: 800.227.0735, then press 5 • canada: 800.263.8700 outside u.s./canada: Call your local Phonic Ear dealer • website: www.phonicear.com © 2003 Phonic Ear Inc. Phonic Ear and the names of Phonic Ear products are 821-7325-101/Rev. E/3710 0703...
