AwoX StriimLIGHT Wi-Fi
LED light with Wi-Fi speaker
Οδηγός χρήστη
Käyttöopas
Οδηγός χρήστη
Mode d'emploi
Návod k použití
Käyttöopas
User Guide
Felhasználói útmutató
Brukerveiledning
Podręcznik
użytkownika
Guia do utilizador
SL-W10
Руководство
пользователя
Användarhandbok
Navodila za uporabo
Kullanıcı Kılavuzu
EN
FR
IT
DE
ES
CS
DK
GR
FI
HU
NO
PL
PT
RU
SE
SL
TR
Advertisement
Table of Contents
Related Manuals for Awox StriimLIGHT SL-W10
Summary of Contents for Awox StriimLIGHT SL-W10
- Page 1 AwoX StriimLIGHT Wi-Fi LED light with Wi-Fi speaker SL-W10 User Guide Οδηγός χρήστη Руководство Mode d’emploi Käyttöopas пользователя Podręcznik użytkownika Navodila za uporabo Manuale d’istruzioni Användarhandbok Benutzerhandbuch Guia do utilizador Brugervejledning Kullanıcı Kılavuzu Brukerveiledning Guía del Usuario Οδηγός χρήστη Mode d’emploi Návod k použití...
-
Page 2: Table Of Contents
www.awoxstriim.com Contents Getting started with AwoX StriimLIGHT Wi-Fi ....3 Before you begin ..............4 Starting your product ............6 AwoX Striim CONTROL setup ..........7 Using AwoX Striim CONTROL ..........9 Using AwoX StriimSERVER ..........14 Overview of the Play tab ........... 18 Playlists and queues ............ -
Page 3: Getting Started With Awox Striimlight Wi-Fi
www.awoxstriim.com Getting started with AwoX StriimLIGHT Wi-Fi Welcome Congratulations and thank you for choosing the AwoX StriimLIGHT Wi-Fi speaker light. StriimLIGHT contains both a LED light bulb and an audio speaker, giving you a great way to play music from your smartphone or tablet anywhere you can plug in a light bulb! You can even use several speakers to create zones. -
Page 4: Before You Begin
www.awoxstriim.com What else you need Internet access with a Wi-Fi connection Before you begin Start by downloading the free AwoX media app for your device: Apple Download and install AwoX Striim iPhone, CONTROL™ software from the App iPad, iPod Store. - Page 5 www.awoxstriim.com StriimLIGHT Wi-Fi overview Blue indicator: Blinking: starting Solid: ready WPS auto-configuration button (short press); reset (long press) Fits standard light bulb socket StriimLIGHT Wi-Fi remote control Light controls: Light on (), dim (-), light off ( \ ), bright (+) Volume controls: Softer (-), mute ( \ ), louder (+)
-
Page 6: Starting Your Product
www.awoxstriim.com Note: Do not use any kind of dimmer switch other than the provided remote control unit. Changing the remote control battery Starting your product Screw your StriimLIGHT Wi-Fi device into a light socket and turn on the power. Wait a few moments for the device to startup. At first, a blue light will blink slowly. -
Page 7: Awox Striim Control Setup
www.awoxstriim.com AwoX Striim CONTROL setup After downloading the application, tap on the launcher icon to run AwoX Striim CONTROL. If StriimCONTROL does not detect a StriimLIGHT device in your network, the setup wizard starts the first time you launch the application. Choose to install AwoX StriimLIGHT Wi-Fi. - Page 8 www.awoxstriim.com Sample usage Connect StriimLIGHT Wi-Fi to your home network and stream music from: Your Apple iOS or Google Android device Internet radio Your home computer AwoX StriimLIGHT Wi-Fi connected to your home Wi-Fi network Smartphone or tablet with AwoX Striim CONTROL 8 | AwoX StriimLIGHT Wi-Fi - User Guide...
-
Page 9: Using Awox Striim Control
www.awoxstriim.com Using AwoX Striim CONTROL Note: the instructions provided here are identical for devices running Apple iOS and Google Android operating systems. Application overview AwoX Striim CONTROL finds and plays music from your various media sources. Here is an overview of the application layout: Find Music Play Lights... - Page 10 www.awoxstriim.com Choosing your music Tap on the Find Music tab to see available music sources. The source bar contains Playlists, Local, StriimLIGHT, and any other media sources you may have available on your network. The contents available for play vary with each source. Playing Internet radio using your StriimLIGHT Wi-Fi 1.
- Page 11 www.awoxstriim.com Tap to play Internet Radio: - Navigate through countries, favorites, and other options to choose the music you want to hear. - When you tap directly on a station, the application switches to the Play tab and your selection begins to play. - Tap on for other options (see Playlists and queues).
- Page 12 www.awoxstriim.com Playing local media from your iOS or Android device Tap to select Local Music in the source bar Tap the available options to choose your music. Tap on Local Music Tap here to play When you tap directly on an item in the list, the window switches to the Play tab and your selection begins to play, replacing the current song queue.
- Page 13 www.awoxstriim.com Tap on for more options: Add to queue: Adds the song to be played after other songs in the queue. Info: Song details. Create new… Creates a new playlist. Playing songs from your PC/Mac or other DLNA audio server Swipe the Source Bar to Tap here for more choose the desired server or...
-
Page 14: Using Awox Striimserver
www.awoxstriim.com Using AwoX StriimSERVER With versions for Mac and Windows, AwoX StriimSERVER makes your home audio library available as a source to Striim devices in your network. StriimSERVER works exclusively with AwoX Striim products. Follow these steps to get AwoX StriimSERVER up and running on your computer: You will find the StriimSERVER setup application on the CD- ROM provided with your product. - Page 15 www.awoxstriim.com The application opens to the Settings window: Assign a name and choose the media types you want to share. Make sure the server is on (when the Stop the server button is displayed, which is the default setting). Tap on Settings: - Use the Server Name field to change the name of your server as it will be seen in your network.
- Page 16 www.awoxstriim.com Browse your hard drive to choose a folder, then Tap on Select Folder to include the folder in the library published by StriimSERVER. Click to add or remove media folders. 10. If you make changes to a media library on your computer, Tap on Settings ...
- Page 17 www.awoxstriim.com 11. Your StriimSERVER media library is now appears as a source in the Striim CONTROL source bar. Browse media published by your StriimSERVER 12. You may turn the server off by clicking on Settings Stop the server. To restart the server, simply click this same button.
-
Page 18: Overview Of The Play Tab
www.awoxstriim.com Overview of the Play tab The Play tab show the music that you have selected to play, and provides standard player controls. Play tab (tap to change views) Back Play/Pause Next Current song or radio station Shuffle Repeat Volume Control music playback using the icons at the bottom of the screen. -
Page 19: Playlists And Queues
www.awoxstriim.com Playlists and queues Creating a playlist You may create playlists of songs located on any available audio sources. A single playlist may contain songs from several different sources. Start by creating a new (empty) playlist Tap to create new Tap on the Find Music tab playlist Tap on My playlists... - Page 20 www.awoxstriim.com Adding songs to your playlist Swipe the Source Bar to select the source. Locate the music you want and then tap on , select Add to [your playlist name]. Add as many songs as you want in this manner. Managing songs in playlists Swipe the media selection bar and select My Playlists.
- Page 21 www.awoxstriim.com Managing playlists On the My Playlists screen, tap on for other playlist options: Rename Allows you to rename the playlist (not available for songs). Delete Allows you to delete the playlist or a song. Adding tracks to queues Instead of creating a playlist, you may simply select songs from one or more sources and queue them up to be played sequentially one after the other.
-
Page 22: Controlling Light Brightness
www.awoxstriim.com Controlling light brightness To adjust the brightness of the LED bulb in your StriimLIGHT, tap on the Lights tab. Dimmer sliders enable you to adjust each StriimLIGHT in your system individually. Tap on Lights and drag sliders to adjust light brightness. -
Page 23: Using Music Zones
www.awoxstriim.com Using music zones Creating a new zone You may combine multiple AwoX StriimLIGHT devices into zones to get a richer stereo sound. For example, here is how you can setup right and left channels with two StriimLIGHT speakers: Tap on Settings Zone Configuration ... - Page 24 www.awoxstriim.com StriimLIGHT speakers that are not yet assigned to a zone are listed under Ungrouped Devices. Tap to select a StriimLIGHT device, then drag it into a zone. Tap to select an ungrouped Drag device into device your zone Add other devices to the zone in the same manner. 24 | AwoX StriimLIGHT Wi-Fi - User Guide...
- Page 25 www.awoxstriim.com Assign left and right channels by clicking on these icons to the left of each device: Right channel Left channel Mixed stereo (both channels on one speaker) Tap Done and wait a moment while the display refreshes. Editing an existing zone To make changes to an existing zone: Tap on Settings ...
- Page 26 www.awoxstriim.com Playing music to a zone (multiple speakers) Once you have created a zone, simply play your music to the zone just as if it were a single device. You may set the zone as the default player under Settings Audio devices Zone is now listed like a single device...
-
Page 27: Other Configuration Options
www.awoxstriim.com Other configuration options Several additional configuration options are provided on the Settings tab. Settings tab Tap on the Settings tab Phone. Here you may set the following options: Incoming call Determines what the app should do if you receive a phone call (No action, Mute phone volume, or Pause playback). - Page 28 www.awoxstriim.com Rescan devices in the network Updates list of available StriimLIGHT Wi-Fi modules, DLNA servers and media sources. Configure a new audio device Runs the device installation Wizard so you can configure another AwoX Striim product. Reset application settings Removes current settings and restores factory configuration.
-
Page 29: Updating Awox Striim Control
www.awoxstriim.com Updating AwoX Striim CONTROL To check on-line for updates to the AwoX Striim CONTROL application: In the Settings tab, tap on Information ( If a more recent version of the software is available, tap on Update now to update your device. AwoX StriimLIGHT Wi-Fi - User Guide | 29... -
Page 30: Technical Specifications
www.awoxstriim.com Technical specifications Hardware Supported media MP3 (up to 48 kHz, CBR & VBR) AAC (up to 48 kHz, 8-320 kbps) WMA (up to 48 kHz, CBR & VBR) including lossless LPCM, WAV (up to 48 kHz, up to 1.44 Mb/s Network Wi-Fi b/g/n (WEP/WPA, WPS) Speaker... -
Page 31: Troubleshooting
www.awoxstriim.com Troubleshooting AwoX StriimLIGHT Wi-Fi is not listed as an available source or the device is grayed-out in the Zones list. Press the reset button for five seconds to erase any previous configuration settings and re-run the setup Wizard. I can connect to my StriimLIGHT, but Internet Radio doesn’t list any available stations. - Page 32 AwoX StriimLIGHT Wi-Fi LED light with Wi-Fi speaker SL-W10...
