Nilox MOD-ADSL-USBLK User Manual

External adsl usb modem
Hide thumbs

Advertisement

Quick Links

Download this manual
External
ADSL USB Modem
USER GUIDE
MOD-ADSL-USBLK

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOD-ADSL-USBLK and is the answer not in the manual?

Questions and answers

Summary of Contents for Nilox MOD-ADSL-USBLK

  • Page 1 External ADSL USB Modem USER GUIDE MOD-ADSL-USBLK...

  • Page 2: Table Of Contents

    ADSL Modem Installation Guide 1 Panel Illustration ................1 1.1 LED Descriptions ..................1 1.2 Front Panel ....................1 1.3 Rear Panel..................... 1 2 Package Contains ..............1 3 Hardware Installation..............1 4 Driver Installation...............2 4.1 Installing ADSL USB Modem ..............2 4.1.1 For Windows 98SE and ME ..............2 4.1.2 For Windows 2000 and XP ..............12 4.2 TCP/IP Configuration .................21...

  • Page 3: Hardware Installation

    1. Panel Illustration 1.1 LED Descriptions When modem is establishing the connection, the LED will be blinking. When modem is connected, the LED will be on steadily. 1.2 Front Panel Connect this connector with Type-B end of USB cable. 1.3 Rear Panel Connect this connector with RJ-11 cable.

  • Page 4: Driver Installation

    4. Driver Installation 4.1 Installing ADSL USB Modem 4.1.1 For Windows 98SE and ME: When detect new hardware window appears, click “Cancel”: Insert “Easy Setup Software Kit”, front page of Easy Setup window will appear,...
  • Page 5 Install Driver: Click here to install ADSL USB modem driver. User Manual “Conexant AccessRunner USB ADSL”: Click here to read user’s manual. Acrobat: Click here to install Acrobat Reader 6.0. Panda: Click here to start Anti Virus program. Click “Install Driver”, and then select the country you are at, PS.
  • Page 6 4) After finish country selecting, the window below will appear. Select the ISP, and then click “}}” to next page.
  • Page 7 5) Enter your account “User Name, Password and Password Confirm” then click “}}” to next page, 6) Confirm modem settings and click “}}” to next page,...
  • Page 8 7) Software kit searches available USB modem, After software kit find the device, operating system starts to load USB driver,...
  • Page 9 For Widows 98SE, system will ask you to insert Windows 98SE installation CD, please insert the CD and click “OK” 10) Enter correct file path and click “OK”,...
  • Page 10 11) System finishes installation and click “r” to close installation window, 12) If your country is not on the list, please click “ ” to next page and select “Other”,...
  • Page 11 a) After you select ”other”, the window below will appear. Before you select the connection type, please refer to the following table and then select the connection type, Connection Type Encapsulation and Multiplexing method Network Information PPP over ATM VCMUX (RFC 2364) Internet Account information: PPP over ATM LLC (RFC 2364) User name...
  • Page 12 13) If you want to change ISP connection settings, please go through the follow steps, Step1: Double click “AccessRunner Control Panel”:...
  • Page 13 Step2: Once control panel window appears, press “Alt and C” then following window will appear. Click “Protocol Setup” then enter correct VPI, VCI and Encapsulation Mode for your ISP. Then Click “OK”, Step3: Connect your ISP with WAN connections, click ”AccessRunner DSL” icon,...
  • Page 14 Enter correct “User name and Password” then click “Connect” to connect to your ISP: 4.1.2 For Windows 2000 and XP: When detect new hardware window appears, click “Cancel”:...
  • Page 15 Insert “Easy Setup Software Kit”, front page of Easy Setup window will appear, Install Driver: Click here to install ADSL USB Modem driver. User Manual “Conexant AccessRunner USB ADSL” Click here to read user’s manual. Acrobat: Click here to install Acrobat Reader 6.0. Panda: Click here to start Anti Virus program.
  • Page 16 PS. If your country is not on the list, please click “ ” to next page and select “Other”, and then go to 10) to set your modem. 4) After finish country selecting, the window below will appear. Select the ISP, and then click “}}”...
  • Page 17 5) Enter your account “User Name, Password and Password Confirm” then click “}}” to next page, 6) Confirm modem settings and click “}}” to next page,...
  • Page 18 7) Software kit searches available USB modem, 8) After software kit find the device, operating system start to load USB driver,...
  • Page 19 9) System finishes installation and click “r” to close installation window, 10) If your country is not on the list, please click “ ” to next page and select “other”,...
  • Page 20 a) After you select ”other”, the window below will appear. Before you select the connection type, please check the following table and then select the connection type, Connection Type Encapsulation and Multiplexing method Network Information PPP over ATM VCMUX (RFC 2364) Internet Account information: PPP over ATM LLC (RFC 2364) User name...
  • Page 21 11) If you want to change ISP connection settings, please go through the follow steps, Step1: Double click AccessRunner Control Panel:...
  • Page 22 Step2: Once control panel window appears, press “Alt and C” then following window will appear. Click “Protocol Setup” then enter correct VPI, VCI and Encapsulation Mode for your ISP. Click “OK”: Step3: Connect your ISP with WAN connections, click “AccessRunner DSL” icon:...
  • Page 23 Enter correct “User name and Password”, and then click “Connect” to connect to your ISP, 4.2 TCP / IP Configuration If your ISP provides connection service as following table, you can follow the steps to set your IP manually. Otherwise, you can get your IP automatically. TCP/IP information: Bridged IP over ATM LLCSNAP (RFC 1483) IP address...
  • Page 24 Option1: Get an IP Automatically 1) Choose Obtain an IP address automatically option in the next window,...
  • Page 25 2) Select Gateway tab and click OK, 3) Select DNS Configuration tab and select Disable DNS then click OK,...
  • Page 26 Option2: Configure IP Manually On the IP Address field, enable specify an IP address option. Enter the IP address (e.g. 10.0.0.4) and Subnet Mask (e.g. 255.0.0.0) that provided by your ISP, 1) Select Gateway tab and add IP Address in the New gateway field and click Add,...
  • Page 27 2) Under DNS Configuration tab, select Enable DNS and add DNS values which provided by your local ISP in DNS Server Search Order field then click Add, For Windows 2000 Step 1: Right click My Network Places and select Properties in the main window screen,...
  • Page 28 Step 2: Right click Local Area Connection (local network your ADSL hooked up with) and select Properties, Step 3: Select Internet Protocol (TCP/IP) then click Properties,...
  • Page 29 Configure IP Automatically: Step 4: Select Obtain an IP address automatically and Obtain DNS server address automatically then click OK to complete IP configuring process, Configure IP Manually: On the IP Address field, enable specify an IP address option. Enter the IP address (e.g. 10.0.0.4), Subnet Mask (e.g.
  • Page 30 For Windows XP Step 1: Click Start then select Control Panel in the main window screen,...
  • Page 31 Step 2: Double click Network Connections icon, Step 3: Right click Local Area Connection (local network your ADSL hooked up with) then select Properties,...
  • Page 32 Step 4: Select Internet Protocol (TCP/IP) then click Properties, Configure IP address Automatically: Step 5: Select Obtain an IP address automatically and Obtain DNS server address automatically,...
  • Page 33 Configure IP Address Manually: On the IP Address field, enable specify an IP address option. Enter the IP address (e.g. 10.0.0.4), Subnet Mask (e.g. 255.0.0.0) and Default gateway that provided by your ISP. If necessary, enter the DNS server address that provided by your ISP. If you have any troubles to configure or setup this ADSL USB Modem, please contact us.
  • Page 34 Smaltimento del prodotto. Questo prodotto è stato progettato e realizzato con materiali e componenti di alta qualità che possono essere riciclati e riutilizzati, ed in conformità a quanto previsto dalle direttive 2002/95/CE, 2002/96/CE e 2003/108/CE, ed è stato immesso sul mercato dopo il 13 agosto 2005. Ogni prodotto che presenta sulla propria confezione il simbolo del bidone con le ruote segnato è...
  • Page 35 Esprinet S.p.A. Via Saragat 4 20054 Nova Milanese (Mi) Italy www.nilox.com...
