Instructions for Assembly, Testing, Operation, Servicing, and Storage.
Semi-Trash Pump: Outdoor agricultural product used for general
purpose water pumping and field irrigation and some trash applications
depending on model. **
** This water pump is designed and recommended for use in spraying NON-flammable
liquids such as water only. Solids capacity will depend on model, see specifications.
Irwindale
Industrial
Water Pump
Owner's Manual
For Outdoor Use Only!
TPS30M Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS30M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Irwindale TPS30M

  • Page 1 ** For Outdoor Use Only! ** This water pump is designed and recommended for use in spraying NON-flammable liquids such as water only. Solids capacity will depend on model, see specifications. Irwindale TPS30M Owner’s Manual Industrial Water Pump...

  • Page 2: Welcome

    Welcome Thank you for your purchase of this quality Irwindale Industrial product. We wish you years of success using your new water pump. This manual contains general warnings about the inherent risks of operating water pumps and specific warnings about the operation and maintenance of this particular water pump.

  • Page 3: Retain For Your Records

    Retain this information for your records. You’ll need to refer to this information when ordering parts and contacting customer service about maintaining your water pump and its warranty. Model number: _________________________________________ Serial number: __________________________________________ Date purchased: ________Month _____________Day _____________Year TPS30M Nameplate...

  • Page 4: Table Of Contents

    Contents Welcome ................................... 1 Customer service ................................1 Retain for your records ..............................2 Important safety precautions ............................. 5 Pump Safety .................................. 6 Safety Label Locations ..............................8 Safety warnings................................. 9 Carbon Monoxide WARNINGS ............................9 Burn and fire WARNINGS............................10 About your water pump ..............................
  • Page 5 Maintenance safety precautions ..........................24 Pump Maintenance schedule ............................25 Engine Maintenance ..............................26 Inspect & Clean Spark Arrestor (If equipped) ......................27 Keep Water Pump Clean ............................27 Storing and transporting your water pump ........................28 Storage procedures: ..............................28 Troubleshooting ................................

  • Page 6: Important Safety Precautions

    Important safety precautions This manual contains critical safety information. Please read the entire manual closely. Because safety is paramount and using a water pump carries significant responsibilities, we have outlined warnings and the general hazards of operating water pumps. In addition, we have summarized the recommended procedures for operating, repairing, maintaining, and storing your specific water pump to keep you and others safe.

  • Page 7: Pump Safety

    * Detailed safety information about these hazards appears throughout this manual. Important Safety Information Irwindale Industrial pumps are designed to pump only water that is NOT intended for human consumption, and other uses can result in injury to the operator or damage to the pump and other property.
  • Page 8 You must also provide personal instruction on how to safely set-up and operate the water pump and remain available to answer any questions a renter/borrower might have. Owner’s manuals are available from Irwindale Industrial Customer Support at 1-888-980-4938 or Support@IrwindaleIND.com...

  • Page 9: Safety Label Locations

    Safety Label Locations NUMBER DESCRIPTION PART NUMBERS DO NOT OPEN PRIMING PORT PLUG 20132 PUMP OPERATION 20134 FIRE AND CARBON WARNING 20141 FIRE AND OVERHEATING HAZARD 20142 E15 WARNING PRODUCT INFORMATION REFER TO ENGINE MANUAL AND ENGINE LABELS FOR ADDITIONAL SAFETY WARNINGS AND INSTRUCTIONS!

  • Page 10: Safety Warnings

    Safety warnings Carbon Monoxide WARNINGS The exhaust from your water pump contains carbon monoxide. Breathing this poisonous gas, which is odorless and colorless, can cause unconsciousness and could even kill you. Only operate your water pump outdoors. Operating a water pump carries serious responsibility. There are precautions that you need to take when operating a water pump: ...

  • Page 11: Burn And Fire Warnings

    Burn and fire WARNINGS Your water pump’s exhaust system becomes hot enough that it could ignite some materials and cause severe burns. Gasoline is highly flammable and can be explosive, so use extreme caution when refueling and operating your water pump. Operating a water pump carries serious responsibility.

  • Page 12: About Your Water Pump

    The information contained in this manual as well as the specifications outlined in it were in effect upon approval for publishing this manual. Irwindale Industrial reserves the right to change the specifications and instructions. Irwindale Industrial also reserves the right to discontinue and modify the design of the water pump at any point without incurring any obligation and without providing notice.

  • Page 13: Major Components And Controls (Pump)

    Major Components and Controls (PUMP) Below are diagrams of your water pump’s major components: Number Part name Quantity PRIME PORT:FILL THE PRIMING PORT TO PRIME THE PUMP DISCHARGE FITTING:CONNECT THE DISCHARGE HOSE TO THE DISCHARGE FITTING SUCTION FITTING:CONNECT THE DISCHARGE HOSE TO THE SUCTION FITTING DRAIN PORT:DRAIN THE LIQUID IN THE PUMP THROUGH THE DRAIN PORT...

  • Page 14: Major Components And Controls (Engine)

    Major Components and Controls (ENGINE)

  • Page 15: Controls And Features

    Controls and Features Fuel Shut Off The fuel shut off valve opens and closes the connection between the fuel tank and the carburetor. The fuel shut off valve lever must be in the ON position for the engine to run. When the engine is not in use, leave the fuel valve lever in the OFF position to prevent flooding and to reduce the possibility of fuel leaks.

  • Page 16: Pre-Operation Check

    Pre-operation check Are you ready to get started? Your safety is your responsibility. A little time spent in preparation will significantly reduce your risk of injury. Knowledge Read and understand this manual. Know what the controls do and how to operate them. WARNING: READ and UNDERSTAND this owner’s manual completely before using the water pump.

  • Page 17: Is Your Pump Read To Go

    Is your pump read to go? For your safety, and to maximize the service life of your equipment, it is very important to take a few moments before you operate the pump to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it, before you operate the pump.

  • Page 18: Fuel Requirements

    Fuel Requirements Use only unleaded gasoline to help minimize combustion chamber deposits. Use only clean gasoline and oil. Never use gasoline or oil that is stale, contaminated, or poor quality. This could damage your air compressor’s engine. Keep your fuel tank and oil cup clear of impurities (e.g. dirt, dust, water). Refer to the engine owner’s manual for fuel specifications.

  • Page 19: Monitoring The Fuel Level

    Monitoring the fuel level DO NOT OVERFILL FUEL TANK When adding fuel, turn the water pump engine off and let it cool at least 2 minutes before removing the gas cap. Make sure the engine is cool before proceeding. After the engine is cool, remove the fuel tank cap and check the fuel level.

  • Page 20: Using Caution When Refueling The Tank

    Using caution when refueling the tank Fuel Outdoors: Fill fuel tank outdoors – never indoors. Fuel vapor is highly flammable and could ignite after your water pump is started. Use approved container: Never fuel the water pump directly into engine fuel tank at a gas station.

  • Page 21: Operation

    Operation Pump Placement For best pump performance, place the pump near the water level, and use hoses that are no longer than necessary. That will enable the pump to produce the greatest output with the least self-priming. As head (pumping height) increases, pump output decreases. The length, type, and size of the suction and discharge hoses can also significantly affect pump output.

  • Page 22: Discharge Hose Installation

    Use a hose clamp to securely fasten the hose connector to the suction hose in order to prevent air leakage and loss of suction. Verify that the hose connector sealing washer is in good condition. Install the strainer on the other end of the suction hose, and secure it with a hose clamp. The strainer will help prevent the pump from becoming clogged or damaged by debris.

  • Page 23: Starting The Engine

    Starting the Engine DANGER: Carbon Monoxide Hazard Exhaust fumes from the engine contain carbon monoxide (CO), a poisonous gas you cannot see, smell, or taste. The CO generated by the engine can rapidly accumulate, even in areas that appear to be well ventilated, resulting in dangerous and fatal concentrations within minutes. NEVER run air inside any enclosed or semi-enclosed spaces, including homes, garages, basements, sheds, boxes, pick-up truck beds, RV’s, or boats.

  • Page 24: Setting Engine Speed

    a) Check the refuel on a regular basis. See engine owner’s manual for more details. b) Check engine oil level each time you refuel. See engine owner’s manual for more details. Safety reminders:  For safety, do not operate your water pump indoors or in partially enclosed areas. ...

  • Page 25: Maintenance

    Note: Your Authorized Service Dealer is knowledgeable about your water pump, and is best equipped to maintain and repair it. To ensure smooth, economical, and trouble-free operations, use only new, genuine Irwindale Industrial water pump parts or their equivalents when repairing your water pump and replacing its parts. Maintenance safety precautions Critical safety precautions are summarized below.

  • Page 26: Pump Maintenance Schedule

    Gasoline is flammable: Use extreme care when working with gasoline to avoid the possibility of fires and explosions. Use only nonflammable solvents when cleaning parts. DO NOT use gasoline to clean your water pump’s parts. Keep sparks, cigarettes, and flames away from all fuel, your water pump, and any fuel-related components. Guards and Shields: Make sure all guards and shields are replaced after servicing the water pump.

  • Page 27: Engine Maintenance

    Impeller clearance Check Pump inlet valve Check Fuel line* Serviced NOTE: PLEASE REFER TO ENGINE MANUAL FOR MAINTENANCE SCHEDULE FOR ALL ENGINE MAINTENANCE. * Emission-related items Information about refueling can be found in the “Fuel Requirements” section. Important maintenance considerations: (1) When used for commercial or heavier use, maintenance may be required at more frequent intervals.

  • Page 28: Inspect & Clean Spark Arrestor (If Equipped)

    Major service, including installation or replacement of parts, should be made by a qualified service technician. Contact Irwindale Industrial customer support at 1-888-980-4938 for any questions, problems, or parts orders.

  • Page 29: Storing And Transporting Your Water Pump

    Storing and transporting your water pump Keep your water pump upright at all times. Never lay your water pump on its side while moving, storing, or using it. Oil could leak and damage your water pump’s engine and surrounding areas. Allow to cool: Your water pump can get very hot when in use.
  • Page 30 Important Safety Instruction:  Always drain fuel from tank in outdoor, well ventilated area.  Stay away from sources of heat, flame, or sparks while handling fuel.  Clean up fuel spills/splashes immediately 4. Water pump Store the water pump in a location away from corrosive storage material, sources of heat, open flames, sparks or pilot lights.

  • Page 31: Troubleshooting

    Troubleshooting Problem Cause Solution Engine will not start Fuel tank is empty. Refill gasoline to proper level. Fuel shut-off valve is in OFF/closed Move fuel shut-off valve lever to ON/Open position. position. Choke is in the OFF position. Place the choke in the ON position unless the engine is warm.
  • Page 32 No pump output Pump not primed. Prime pump. Suction hose collapsed, cut or Replace suction hose. punctured. Strainer not completely underwater. Sink the strainer and the end of the suction hose completely underwater. Air leak at connector. Replace sealing washer if missing or damaged. Tighten hose connector and clamp.

  • Page 33: Water Pump Specifications

    Water pump specifications Model TPS30M Type Semi-Trash Water Pump Suction port diameter 3.0 inch / 80 mm Discharge port diameter 3.0 inch / 80 mm Maximum total head lift 95 feet / 28 m Maximum suction head lift 26 feet / 8 m...

  • Page 34: Pump Assembly And Parts List

    Pump assembly and parts list Number Part name Part # Number Part name Part # Outlet Locking nut 30M01 Inlet Flange 30M18 Outlet Nozzle 30M02 Inlet Check Valve 30M19 Drain/Prime Plug (3/4”） Outlet Gasket 30M03 30M20 Drain/Prime Plug (1") 30M04 Plug O-ring 30M21 Plug O-ring...

  • Page 35: Engine Assembly And Parts List

    (Please refer to the engine manual for the parts list and assembly diagram.) Contact information for Technical and Customer Assistance Locate an Authorized Service Dealer For assistance in finding an Authorized Service Dealer, contact Irwindale Industrial Customer Service at 1-888-980-4938 or Support@IrwindaleIND.com. Visit our web site at www.IrwindaleIND.com. Registration Card Please fill out the registration card, and return back to us within 30 days of the purchase date.

  • Page 36: Limited Warranty

    Transportation costs to and from service center is the responsibility of the buyer/customer. IES can supply you with the service center location in your area by contacting Irwindale Industrial customer support at the number below.
  • Page 37 Please fill in the following information and have it on hand when you call in a warranty claim. Customer Number: ______________________________________________________________ Date of Purchase: _______________________________________________________________ Serial Number: _________________________________________________________ Model Number: __________________________________________________________________ © 20131 Innovative Energy Solutions, Irwindale, CA USA IRWINDALE INDUSTRIAL is a registered trademark of IES.
