REME HALO™ by RGF®
A Guardian Air Purification System
New Advanced Environmental Air Treatment System
Thank you for purchasing the REME HALO
by
TM
RGF® Environmental Group, Inc.
We are confident this system will provide you with years of
Fresh, Clean and Odor-Free Air!!!
NOTE: Please take time to read the attached assembly instructions.
All instructions and precautions should be adhered to while
operating this system.
RGF® Environmental Group, Inc.
Copyright 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RGF REME HALO
Summary of Contents for RGF REME HALO
- Page 1 REME HALO™ by RGF® A Guardian Air Purification System New Advanced Environmental Air Treatment System Thank you for purchasing the REME HALO RGF® Environmental Group, Inc. We are confident this system will provide you with years of Fresh, Clean and Odor-Free Air!!! NOTE: Please take time to read the attached assembly instructions.
- Page 2 All are friendly oxidizers. By friendly oxidizers, we mean oxidizers that revert back to oxygen and hydrogen after the oxidation of the pollutant. The REME HALO™ now has surface treatment. additional zinc ions for improved...
-
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS: 1. Determine the Mounting Location: To maximize the effectiveness of the Guardian Air REME HALO™, it is recommended (whenever possible) to install the Guardian Air™ unit in the air plenum just after the air handling unit (supply side). Refer to Figure 1 for clarification. - Page 4 Figure 3 Using a 3” hole saw (or other suitable means), cut a 3” hole into the plenum / duct box AFTER the fan. Cutting into fiberboard is usually easier than metal, and can be done with a utility knife (Figure 3).
- Page 5 Arrow Indicator Figure 5 Insert probe into opening with the arrow indicator going in the same direction as the airflow of the HVAC unit. Once attached to duct, press firmly all around flange to ensure a proper seal. Refer to Figure In some installations, it may be preferred to secure the unit with the provided screws via the three mounting holes located on the REME...
-
Page 6: Unit View
3. Electrical Connection: RGF® recommends for optimal performance and maximum cell life that the Guardian Air™ product line operates continuously. For wiring assistance, see installation instructions in this manual. The Guardian Air™ may be connected to any suitable 120, 208 or 240 VAC source with the supplied 40VA transformer. -
Page 7: Output Adjustment
The REME HALO™ has a unique feature which allows the adjustment of the AOP output by way of an adjustable shroud built into the REME Cell. By sliding the shroud apertures open or closed, the REME HALO™ can be custom adjusted to the needs of a specific area. - Page 8 Replacing REME HALO™ Cell: DANGER RISK OF ELECTRIC SHOCK BEFORE CHANGING PHI CELL, COMPLETELY DISCONNECT FROM POWER Remove housing from unit by turning counterclockwise and pulling straight out of mounting plate. Once housing and cell are free from mounting plate, grasp cell and turn...
- Page 9 Replacing REME HALO™ Cell: Pull cell away from housing until lamp connector is visible. Firmly grip lamp connector and with a gentle rocking motion remove connector from cell pins. Replace with new REME HALO™ Cell and reassemble unit.
-
Page 10: Faq
However, it does not indicate the relative output of the unit. The output of the unit reduces with time, and after two years of operation, it is recommended to change out the replaceable REME HALO™ cell insert to maintain optimum effectiveness of the unit. - Page 11 (sixty months) from the original date of purchase (excludes PHI or REME HALO™ cell). The PHI or REME HALO™ cell included with the original unit is warranted to be free from defects in material and workmanship for a period of two years (24 months) from original purchase date.
- Page 12 How do I contact the Manufacturer about my warranty, a question or complaint? Contact your local HVAC contractor. If they cannot answer the warranty question or complaint, you can contact the RGF Warranty Department. Are there any parts not covered by this warranty (that the manufacturer will not repair or replace)? Yes.
- Page 13 What service can I expect from my HVAC contractor? Your contractor will assist you with any problems or questions you may have. Sell you optional parts or equipment as needed. Assist you with any warranty claims. Warranty Registration Fill out enclosed warranty registration card and return to RGF.
- Page 14 The Guardian Air QR+ by RGF® is designed to eliminate sick building syndrome risks by reducing odors, air pollutants, VOCs (chemical odors), smoke, mold, bacteria and viruses.
- Page 15 Process consisting of: Hydro-peroxides, ozonide ions, super oxide ions and hydroxide ions. All are friendly oxidizers. The Light Commercial HVAC PHI Cell by RGF® is designed to eliminate sick building syndrome risks by reducing odors, air pollutants, VOCs (chemical odors), smoke, mold bacteria and viruses*.
- Page 16 RGF’S SEVEN ACRE ENVIRO-COMPOUND LOCATED IN RIVIERA BEACH (PORT OF PALM BEACH ENTERPRISE ZONE) THIS MANUAL PRINTED IN U.S.A. REME HALO 24VAC 5-2014...
