38CC CHAINSAW
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer,
birth defects, or other
reproductive harm. Wear
protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead, known
to the State of California to cause
cancer and birth defects or other
reproductive harm. Wash hands
after handling.
Important!
When using equipment, a few safety
precautions must be observed to
avoid injuries and damage. Please
read the complete operating manual
with due care. Keep this manual in a
safe place, so that the information is
available at all times. If you give the
equipment to any other person, give
them these operating instructions as
well. We accept no liability for
damage or accidents which arise due
to non-observance of these
instructions and the safety
information herein.
For Customer Service, please call 1-800-348-5004 or
email feedback@natitools.com
SPECIFICATIONS
Engine Displacement: 38 cc
Bar Length*: 14in, 16in, or 18in
*Varies by Model
Maximum Idling Speed:
3400 RPM
Fuel Mixture: 40:1
Anti-Vibration Function
Chain Brake
Auto Chain Lubrication
CAUTION:
FOR YOUR OWN SAFETY READ
INSTRUCTION MANUAL
COMPLETELY AND CAREFULLY
BEFORE OPERATING THIS
CHAINSAW.
Any failures made in following the
safety regulations and and
instructions may result in an
electric shock, fire and/or serious
injury.
1
Model: 5466,
52721
SAFETY INSTRUCTIONS
Only allow users who have read
and understand this manual
operate this chainsaw.
Wear protective gear, such as
steel-toed footwear, snugly fitting
clothing, heavy duty gloves, eye
protection (goggles or face
screen), hard hat and ear
protection (ear plugs or mufflers).
Do not wear jewelry and pull long
hair back.
Keep all body parts clear of the
chain while the engine is running.
Do not allow other people or
animals near the saw when it is
running, starting, or being
operated.
You must be mentally alert and in
good physical condition when
operating a chainsaw because the
work is strenuous
Carefully plan your sawing project
before starting. Do not begin until
you are sure the work area is
clean, you have secure footing
and if you are felling trees, that
you have a planned and clear
retreat path.
8805466
06/13
