Summary of Contents for Saphir MEDIA PAD
- Page 1 MEDIA PAD This user manual has been specially designed to guide you through the functions and MANUAL features of your device.
- Page 2 PC communication and entertainment, based on exceptional technology and high standards. This user manual has been specially designed to guide you through the functions and features of your device. Saphir Media Technologies GmbH Management Office Schönemoorer Strasse 154 E 27777 Ganderkesee - Heide II...
-
Page 3: Read Me First
Read me first This user manual includes important safety precautions and operation guide. To avoid accidents, please read this manual carefully before operating your tablet. • Keep your tablet away from high temperature, high humidity and dusty environments. • Do not leave your tablet in car with windows closed in hot summer. •... -
Page 4: Table Of Contents
CONTENTS Part 1 QUICK GUIDE INTERFACE INTRODUCTION INDICATOR ICON PREPARATION TURN ON/OFF THE TABLET PC CHARGE THE BATTERY INSERT A MEMORY CARD REMOVE THE MEMORY CARD TO INSTALL SIM SPECIFICATION Part 2 INSTRUCTION ANDROID 4.1 BRIEF LOCKING/UNLOCKING SCREEN GET TO KNOW THE MAIN SCREEN ACCESS APPLICATIONS CUSTOMIZING HOME SCREEN ITEMS... - Page 5 SETTINGS SYSTEM SETTINGS WIRELESS & NETWORK DEVICE PERSONAL SYSTEM QUICK ACTION ENTERTAINMENT CAMERA CAPTURE A PHOTO RECORD A VIDEO MUSIC VIDEO GAME HUB TROUBLE SHOOT POWER OFF SAFETY PRECAUTIONS...
-
Page 6: Part 1 Quick Guide
Part 1 QUICK GUIDE INTERFACE INTRODUCTION 1. Earphone Jack (3,5mm): The built-in speaker will shut down automatically when plugging in the earphone. 2. Reset: Press the Reset Button with a Staighten Paperclip in the hole to reset the Tablet PC. 3. -
Page 7: Indicator Icon
INDICATOR ICON Icons shown on the display may vary depending on your region or service provider. ICON FUNCTION Return Go to the opening HOME-Screen Check the running applications WLAN connected Auto-rotate screen Adjust screen brightness Notification SETTINGS Bluetooth activated New text or multimedia message Alarm activated Error occurred or caution required Battery power level... -
Page 8: Preparation
PREPARATION TURN ON/OFF THE Tablet PC Press the “power button” for 3 seconds, you will see the loading screen and then the opening screen. Press the “power button” for 3 seconds, you will see a power-off option notice. Tap “OK” to turn off your tablet. Notes: Follow all warnings and directions from official personal when in areas where the use of wireless devices is restricted, such as airplanes and hospitals. -
Page 9: Insert A Memory Card
INSERT A MEMORY CARD To store additional multimedia files, you can insert a memory card. Your device accept microSDHC memory card with maximum capacities of 32GB (depending on memory card manufacturer and type). REMOVE THE MEMORY CARD Before removing a memory card, use following instruction: 1. -
Page 10: To Install Sim
TO INSTALL SIM Card When you subscribe to cellular service, you will receive a SIM Card, with subscription details, such as your personal identification optional services, to use network data services. Notes: Do not remove or Plug-In a SIM card while the device’s itself and the modem power (3G) is not turned off. -
Page 11: Part 2 Instruction
On this Tablet PC is Android 4.0.4 pre-installed. You can enjoy more Apps with ICS than with Jelly Bean, if you want to upgrade go to our Website www.saphir-media.de and download the Jelly Bean Firmware on the device. Android 4.1 (Jelly Bean) is the latest version of the android platform for tablets, it builds on the things people love most about Android easy multitasking, rich notification, customizable home screen, resizable widgets, and deep interactivity and adds powerfull new ways of communication and sharing. -
Page 12: Get To Know The Main Screen
Besides, through sliding the locking screen, you can jump to the camera for a picture or pull down the notifications window to check for messages, when listening to music, you can even manage music tracks and see the gallery. GET TO KNOW THE MAIN SCREEN When the device is in idle mode, you will see the idle screen. -
Page 13: Access Applications
ACCESS APPLICATIONS How to access your device’s applications. 1. In idle mode, select “ ” upper right corner of the Display to access the application list. 2. Scroll left or right to another application screen. You can also select a dot at the bottom of the screen to move the corresponding main menu screen directly. -
Page 14: Customizing Home Screen Items
CUSTOMIZING HOME SCREEN ITEMS On smaller screen devices, the home screen now includes a customizable favorites tray visible from all home screens. You can drag apps, shortcuts, folders, and other priority items in or out the favorites tray for instant access from any home screen. -
Page 15: Settings
SETTINGS SYSTEM SETTINGS Tap the settings icon to enter system settings. WIRELESS & NETWORKS Wi-Fi It is for setting up the wireless device and turning it on/off. Bluetooth It is for setting bluetooth device and turn it on /off. Data usage Measured by your tablet, your carrier’s data usage accounting may differ. -
Page 16: Device
DEVICE Sound It is for setting volume, notice ring, default notification etc. Display It is for setting brightness, wallpaper, auto-rotate screen, sleep and front size. Storage Is for checking the memory capacity and memory usage status. Battery It is for checking battery Status. Apps Is for management the applications. -
Page 17: System
SYSTEM Date & time It is for setting date and time. Accessibility It is for setting touch & hold delay etc. Developer options It is for setting USB debugging, stay awake etc. About tablet It is for showing the information about tablet. -
Page 18: Quick Action
QUICK ACTION Tap “ ”to enter primary menu, you can access: battery power indicator, turn on/off Wi- Fi setting, Auto-rotate screen, screen brightness, enter main menu. -
Page 19: Entertainment
ENTERTAINMENT CAMERA Learn how to capture and view photos and videos. Notes: 1. The camera automatically turns off when you do not use it for a specified period. 2. The memory capacity may differ depending on the shooting scene or shooting conditions. CAPTURE A PHOTO 1. -
Page 20: Record A Video
RECORD A VIDEO 1. In idle mode, open the application list and select Camera“ ”to turn on the camera. 2. Aim the lens at the subject and make any necessary adjustments. 3. Select “ ”to record a video. The video is saved automatically. Notes: The camcorder may not be able to properly record videos to memory card with a slow transfer speed. -
Page 21: Music
MUSIC Listen to your favorite music with the music player. The music player supports various formats. Add music files to your device 1. Download from the web. 2. Receive via Bluetooth. 3. Copy from your memory card. Play music 1. In idle mode, open the application list and select Music. -
Page 22: Video
VIDEO With the video player you can play various kinds of videos. The video player supports various formats. GAME HUB • In idle mode, open the application list and select Game Hub. • Select and install a game. Notes: 1. Available games may vary depending on your region or service provider. 2. -
Page 23: Trouble Shoot
TROUBLE SHOOT Your device displays network or service error messages. When you are in areas with weak signals or poor reception, move to another area and try again. You cannot access some optional without a subscription, contact your service provider for more details. If touch screen is not responding properly, try the following: 1. -
Page 24: Power Off
POWER OFF When you do not use the tablet PC, you can press the power button to switch it off. -
Page 25: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to yourself and others or damage to your device, read all of the following information before using your device. Warnings: • Prevent electric shock, fire, and explosion. • Do not use damaged power cords or plugs, or loose electrical sockets. •...
