Summary of Contents for LaView HD-SDI Bullet Camera
- Page 1 HDS IR Bullet Camera Camera User Manual...
-
Page 2: Regulatory Information
HD-SDI IR Bullet Camera·User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. - Page 3 HD-SDI IR Bullet Camera·User Manual interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the users will be required to correct the interference at their own expense. FCC Conditions This device complies with part 15 of the FCC Rules.
-
Page 4: Safety Instruction
HD-SDI IR Bullet Camera·User Manual See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. - Page 5 HD-SDI IR Bullet Camera·User Manual Warnings In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with AC 24V or DC 12V according to the IEC60950-1 standard.
- Page 6 HD-SDI IR Bullet Camera·User Manual Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch senor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.
-
Page 7: Table Of Contents
1.2.1 Overview of Type I HD-SDI Bullet Camera ..... 8 1.2.2 Overview of Type II HD-SDI Bullet Camera .... 9 1.2.3 Overview of the Type III HD-SDI Bullet Camera .. 10 2 Installation ................. 11 2.1 Installation of Type I&II HD-SDI IR Bullet Camera ..11... -
Page 8: Introduction
HD-SDI IR Bullet Camera·User Manual 1 Introduction 1.1 Product Features This series of camera adopts high-sensitive sensor and advanced circuit board design technology. It features high resolution, low distortion, and low noise features, etc., which make it extremely suitable for surveillance system and image process system. The main features of HD-SDI IR Bullet cameras are as follows: ... -
Page 9: Overview
HD-SDI IR Bullet Camera·User Manual 1.2 Overview 1.2.1 Overview of Type I HD-SDI Bullet Camera Figure 1-1 Overview of Type I HD-SDI IR Bullet Camera Table 1-1 Description Description Description Sun Shield Power Cable Lens HD-SDI Cable IR LED CVBS Cable... -
Page 10: Overview Of Type Ii Hd-Sdi Bullet Camera
HD-SDI IR Bullet Camera·User Manual 1.2.2 Overview of Type II HD-SDI Bullet Camera Figure 1-2 Overview of Type II HD-SDI IR Bullet Camera Table 1-2 Description Description Description Sun Shield Power Cable Lens HD-SDI Cable IR LED CVBS Cable Adjustable Screw... -
Page 11: Overview Of The Type Iii Hd-Sdi Bullet Camera
HD-SDI IR Bullet Camera·User Manual 1.2.3 Overview of the Type III HD-SDI Bullet Camera Figure 1-3 Overview of Type III HD-SDI IR Bullet Camera Table 1-3 Description Description Description Mounting Base IR LED Adjustable Nut HD-SDI Cable Sun Shield Power Cable... -
Page 12: Installation
HD-SDI IR Bullet Camera·User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. - Page 13 HD-SDI IR Bullet Camera·User Manual Both wall mounting and ceiling mounting are suitable for type I and type II HD-SDI IR bullet camera. Wall mounting will be taken as an example in the section. And you can take steps of wall mounting as a reference if ceiling mounting is adopted.
-
Page 14: Installation Of Type Iii Hd-Sdi Ir Bullet Camera
HD-SDI IR Bullet Camera·User Manual 4. Connect the corresponding power/HD-SDI/CVBS cables. 5. Adjust the Lens. 1). Loosen screw 1 to adjust the pan direction [0°~360°]. Tighten the screw after completing the adjustment. 2). Loosen screw 2 to adjust the tilt direction [0°~100°]. Tighten the screw after completing the adjustment. - Page 15 HD-SDI IR Bullet Camera·User Manual Steps: Drill the screw holes in the ceiling according to the drill template. Figure 2-4 Drill Template Route the corresponding cables. Secure the camera to the ceiling with the supplied PA4 Screws. Figure 2-5 Secure the Camera to the Ceiling Connect the corresponding power/HD-SDI/CVBS cables.
- Page 16 HD-SDI IR Bullet Camera·User Manual Adjust the pan direction [0°~360°]. Adjust the tilt direction [0°~90°]. Rotate the camera [0~360°] to adjust the lens to the surveillance angle. Tighten the adjustable nut to complete the installation. Figure 2-6 3-axis Adjustment...
