Accel DD-SS Digital Delay User Manual

Digital Delay
DD-SS
Effects Pedal
DESCRIPTION
Accel DD-SS Digital Delay creates rich full bodied
delay effects from short slap-back rockabilly sounds
to longer repeating delays. Two stage, separate chip
sets are used in this design, greatly improving the
delay quality and increasing the realism of delay time.
Also within the circuitry of this digital delay,
analog circuitry was also used to simulate the more
traditional, pure analog sound that many guitarists seek.
Max delay time is 1100ms (1.1seconds), and features
a two mode toggle switch: 20-600ms, 20-1100ms.
600ms allows for a little faster repeats and delay
times while the 1100ms is capable of longer, slower delays.
Measuring 2 1/4" wide and 4 1/2 " long, this pedal will fit
nicely on any pedal board offering more tone with less
space.
As with all Accel pedals, a five year limited warranty is included.
Features:
Controls: Mix, Delay, Repeat
Seal designed dust proof adjust pots
True Bypass design.
Metal Casing
Thumb screw battery access.
Power Source:
9Volt battery ( remove battery cover
on bottom to replace),
DC9V adapter or
Power Supply designed for
9V effects pedals (not included).
Such as the
Accel Power Source 8 power supply.
Read all warning and cautions before operating your Power
Accel DD-SS Digital Delay Effects Pedal
Keep these instructions – The safety and operating instructions
1.
should be retained for future reference.
2. All warnings, cautions and instructions should be adhered too for
safe operation of this device.
3. Follow all operating and use instructions for safe operation of this
unit.
4. WARNING!!! To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture. The unit should not be
exposed to liquids of any kind. Any objects or containers filled
with liquids, such as drinks or beverages shall not be placed on
top of the unit.
5. CAUTION!!! To prevent risk of overheating or damage to the
Power Source 8 power supply. Mount per Manufacturers
Mounting Instructions!
6. Clean only with a dry cloth.
7. Protect all cords from being walked on or pinched.
8. Follow all instructions and recommendations regarding
attachments/accessories specified by the manufacturer.
9. Unplug the unit during lightning storms or when unused for long
periods of time.
10. Refer all servicing to qualified personnel. Service is required
when the effects pedal has been damaged in any way – such as
plug or jack damage; if any liquid or foreign objects have gotten
inside the unit; if it has been exposed to rain or moisture; has
been dropped; or does not otherwise operate normally.
