- Page 1 WD-1 NETWORK AV ADAPTER ADAPTATEUR AV RÉSEAU ADAPTADOR AV CON CONEXIÓN DE RED NETZWERK-AV-ADAPTER СЕТЕВОЙ AV-АДАПТЕР OPERATING INSTRUCTIONS GUIDE D’UTILISATION INSTRUCCIONES DE FUNCIONAMIENTO BEDIENUNGSANLEITUNG ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ...
-
Page 2: Safety Information
Safety Information READ THIS BEFORE OPERATING YOUR UNIT CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, CAUTION DO NOT REMOVE FRONT OR BACK COVER. RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE. DO NOT OPEN REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 3: Important Safety Instructions
Important Safety Instructions Product Name: Network AV ADAPTER Model Number: WD-1 Read these instructions. Responsible Party Name: Keep these instructions. ETRON CORPORATION Heed all warnings. -
Page 4: Table Of Contents
Turning on Your Unit Setting the Network Standby Control Setting the Network Setup Listening to Internet Radio Listening to Music from the Media Server Using the Sherwood Remote Application Updating the Firmware 23 TROUBLESHOOTING 24 ADDITIONAL INFORMATION Specifications Trademarks and Licenses... -
Page 5: Getting Started
Getting Started What's Included Main unit Remote control (1 ea) Battery “AAA” size, 1.5V (2 ea) WD-1 NETWORK AV ADAPTER OPERATING INSTRUCTIONS Power adapter (1 ea) User manual (1 ea) • The items supplied with your unit are subject to change without prior notice. -
Page 6: Installing The Remote Control Battery
WD-1 NETWORK AV ADAPTER Installing the Remote Operating the Range Control Battery of the Remote Control Use the remote control within a range of about Remove the battery cover. 7 meters (23 feet) and angles of up to 30 degrees aiming at the remote control sensor. -
Page 7: Parts Description
Parts Description Front and Rear Panel Status LED HDMI Connector Power Connector USB Connector (For Upgrade only) OPTICAL OUT Connector IR Sensor LAN/ETHERNET Connector... -
Page 8: Remote Control
WD-1 NETWORK AV ADAPTER Remote Control POWER ON Turns on the main unit. MODE Adjusts the screen resolution. (Original/Full) DISPLAY • When playing audio or video files, turns on or off the progress bar. • When viewing photos, turns on or off the slideshow transition time display. -
Page 9: Making Connections
Making Connections About HDMI Connecting HDMI HDMI (High Definition Multimedia Interface) Components supports both audio and video on a single digital connection for use with DVD players, With HDMI, you can easily enjoy high quality DTV, set-top boxes, and other AV devices. sounds and images. -
Page 10: Connecting Digital Audio Components
WD-1 NETWORK AV ADAPTER Connecting Digital Connecting to a Audio Components Network You can connect components equipped with an If you have an internet connection, you can optical input jack. Then, the main unit transmits connect the main unit to the internet as well as the digital audio signal to the connected using a wired LAN connection. -
Page 11: Connecting Power
Making Connections Connecting Power • After making a broadband internet Make sure to plug in after you have connected connection, you should set the all your components to the main unit. Plug the communication settings. For details, see supplied AC input cord into the AC inlet and “Setting the Network Setup”... -
Page 12: Operating Your Device
Operating Your Device Turning on Your Unit Setting the Network Setup Turn on the main unit by pressing To listen to Internet radio stations or music files POWER ON. stored on your computer via a wired network, Turn off the standby mode by pressing you should configure network settings first. - Page 13 Operating Your Device Network Settings Overview Setting the Wired Network Connection Go to Main Menu Sub Menu Page Before you setup the connection, check Soft AP that the LAN cable is connected to the LAN/ Direct hotspot ETHERNET connector properly and securely. AV Set For details, see “Connecting to a Network”...
-
Page 14: Listening To Internet Radio
WD-1 NETWORK AV ADAPTER Setting Other Network Options Listening to Internet Radio Menu item Description Views and changes the name of the AP Name You can listen to Internet radio broadcasts unit displayed on the network. provided by vTuner. You can control the... -
Page 15: Listening To Music From The Media Server
Refer to "Setting the Network Setup" on page 12 Music file and click on "Play to". Then, for details. select WD-1 Media Renderer and press • The service may be discontinued without PLAY. notice. • You may not be able to receive some internet radio stations. -
Page 16: Using The Sherwood Remote Application
PC in the MEDIA Wi-Fi direct. PLAYER. Right click on the Music Folder or File and click on Play to. Then select WD-1 Media Renderer and click PLAY. • You can install applications that support DLNA or UPnP from iTunes or Playstore. - Page 17 Open the Sherwood Remote application. Or visit App Store on your iPhone. Search for Sherwood Remote. Select and tap WD-1 on the smartphone Wifi setting menu to connect. Then, you Download and install the application on can use your smartphone as a remote your phone.
- Page 18 WD-1 NETWORK AV ADAPTER Using Direct AV • iOS On Direct AV, you can listen to songs, watch videos, and view photos stored on your Android phone or iPhone. Tap Direct AV. • For iOS phones, you should synchronize contents in iTunes to use this function.
- Page 19 Operating Your Device Listening to Songs on Your Watching Videos on Your Smartphone Smartphone You can select a video on the video file list and You can select a song on the song list and play enjoy it on the main unit. it over the main unit.
- Page 20 WD-1 NETWORK AV ADAPTER Viewing Photos on Your Smartphone Using Internet Radio and Media Server You can view photos as a slideshow and set You can use your smartphone as a remote the slideshow transition time at 5s, 10s, 20s, controller for Internet Radio and Media Server.
-
Page 21: Updating The Firmware
Operating Your Device Overview of the Main Screen Updating the Firmware New firmware that provides additional features or product improvements will be released as needed. Updates can be downloaded from our website: www.sherwoodamerica.com. After downloading the firmware to a USB device, you can update the main unit by connecting the USB device with a USB OTG cable(faster than USB 2.0) and doing the... - Page 22 WD-1 NETWORK AV ADAPTER Connect the USB connector of the main unit to the device which stores the firmware. Press the buttons in the following order. MODE ENTER • When the main unit does not turn on automatically after updating, you should turn on the unit manually.
-
Page 23: Troubleshooting
Troubleshooting If you experience any of the following difficulties while using the main unit, use this troubleshooting guide to help remedy the problem before requesting servicing. Should any problem persist, consult your nearest authorized dealer or authorized independent company. If the unit does not operate normally due to external influence such as static electricity, disconnect the power plug from the outlet and insert again to return to normal operating conditions. -
Page 24: Additional Information
Additional Information Specifications Input/Output HDMI Output 1 Audio Output Optical x1 (Digital) Supported Codecs Sampling rate Bitrate Codec Type Channel Container (KHz) (max in Kbps) CBR/VBR up to 48 KHz from 8 kbps mono, stereo *.mp3 to 320 kbps up to 192 *.wma, Audio WMA, WMV... -
Page 25: Dolby Digital
Trademarks and Licenses HDMI HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Dolby Digital Dolby and the double-D symbol are trademarks of Dolby Laboratories. Wi-Fi The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. - Page 27 WD-1 NETWORK AV ADAPTER ADAPTATEUR AV RÉSEAU ADAPTADOR AV CON CONEXIÓN DE RED NETZWERK-AV-ADAPTER СЕТЕВОЙ AV-АДАПТЕР Printed in china Imprimé en Chine Impreso en China Gedruckt in China 5707-00000-803-1S Отпечатано в Китае...
