LP-25 Logo Projector
For your own safety, please read this user manual carefully before you initially start-up.
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet
INTRODUCTION
Thank you for having chosen a EUROLITE LP-25. If you follow the instructions given in this manual, we are
sure that you will enjoy this device for a long period of time.
Unpack your LP-25.

SAFETY INSTRUCTIONS

Be careful with your operations. With a dangerous voltage you can suffer a dangerous
electric shock when touching the wires!
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning
notes written in this user manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it
on immediately. The arising condensation water might damage your device. Leave the device switched off
until it has reached room temperature.

USER MANUAL

CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
CAUTION!
12/38
00026479.DOC, Version 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP-25 and is the answer not in the manual?

Questions and answers

Related Manuals for EuroLite LP-25

Summary of Contents for EuroLite LP-25

  • Page 1: User Manual

    - download the latest version of the user manual from the Internet INTRODUCTION Thank you for having chosen a EUROLITE LP-25. If you follow the instructions given in this manual, we are sure that you will enjoy this device for a long period of time.
  • Page 2 Please make sure that there are no obvious transport damages. Should you notice any damages on the A/C connection cable or on the casing, do not take the device into operation and immediately consult your local dealer. This device falls under protection-class I. The power plug must only be plugged into a protection class I outlet.

  • Page 3: Operating Determinations

    Never leave this device running unattended. OPERATING DETERMINATIONS This device is a lighting effect for creating decorative effects. This product is only allowed to be operated with an alternating voltage of 230 V, 50 Hz and was designed for indoor use only. This device is designed for professional use, e.g.
  • Page 4 If this device will be operated in any way different to the one described in this manual, the product may suffer damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short- circuit, burns, electric shock, lamp explosion, crash etc. OVERVIEW (1) Lens (2) Focus (lens adjustment)

  • Page 5: Installation

    INSTALLATION Installing/Replacing the lamp DANGER TO LIFE! Only install the lamp with the device switched off! Unplug from mains before! CAUTION! The lamp has to be replaced when it is damaged or deformed due to the heat! Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 5 minutes). During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's notes! Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device...

  • Page 6: Overhead Rigging

    Overhead rigging DANGER TO LIFE! Please consider the EN 60598-2-17and the respective national standards during the installation! The installation must only be carried out by an authorized dealer! The installation of the device has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation.

  • Page 7: Connection With The Mains

    30 mA. Lighting effects must not be connected to dimming-packs. OPERATION After you connected the effect to the mains, the LP-25 starts running. CLEANING AND MAINTENANCE The operator has to make sure that safety-relating and machine-technical installations are inspected by an expert after every four years in the course of an acceptance test.

  • Page 8: Replacing The Fuse

    1) All screws used for installing the devices or parts of the device have to be tighly connected and must not be corroded. 2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension, trussing). 3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Power supply: 230 V AC, 50 Hz ~ Power consumption: 300 W Sharpness-range: 0.4 - 15 m Gobo-size: E-size Outside diameter of the gobos: 37.5 mm Image diameter of the gobos: 28 mm Maximum ambient temperature T 45° C Maximum housing temperature T (steady state): 115°...
