Amana ART6510 SERIES Owner's Manual

Self-cleaning electric range

Hide thumbs Also See for ART6510 SERIES:

Technical information (8 pages)

Table Of Contents

Table of Contents

Quick Links

Need help?

Do you have a question about the ART6510 SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for Amana ART6510 SERIES

Page 1 Leave this manual and other literature with consumer for Amana Appliances future use. Consumer Communications/Spanish Manual 2800 220th Trail Customer PO Box 8901 Keep these instructions for future reference. If appliance Amana, Iowa 52204-0001 changes ownership, be sure this manual accompanies range. Número de fax 1-319-522-8158...
Page 2: Table Of Contents
Child Lock Out ............16 Service Tones ............16 Asure™ Extended Service Plan Amana offers long-term service protection for this new range. Asure™ Extended Service Plan is specially designed to supplement Amana’s strong warranty. This plan covers parts, labor, and travel charges.
Page 3: Important Safety Information
Important Safety Information ALL APPLIANCES 1. Proper installation. Be sure your appliance is WARNING properly installed and grounded by a qualified technician. To reduce the risk of the appliance tipping, it 2. Never Use Your Appliance for Warming or Heating must be secured by a properly installed anti-tip the Room.
Page 4: Ovens
A film of soil-laden detergent water may penetrate the broken cooktop and create a risk of collect on rangetop. If this should happen, Amana electrical shock. Contact a qualified technician Cleaning Conditioning Cream removes this type of immediately.
Page 5: Installation
Installation Packing Material Minimum Clearances to Combustible Remove protective packing materials from range. Tape Surfaces residue can be cleaned with a soft cloth and alcohol. Using dimensions, prepare cabinet opening. (Figure 2) • Minimum clearance to rear wall is 0 inches. Range Location •...
Page 6: Irregular Cabinet And Countertop Heights
Line Voltage Requirements Irregular Cabinet and Countertop Heights Line voltage must not exceed rated voltage. See rating plate Countertops such as ceramic tile tops cause cabinet and attached to range for kilowatt rating. Line voltage less than countertop to be higher than 36 inches. Follow instructions rated voltage will result in slow heating.
Page 7: Power Cord Requirements
Power Cord Requirements Terminal block is approved for copper wire connection only, NOT aluminum wiring. If aluminum house wiring Power cord is not supplied with range. Power cord must is to be connected, the following procedure is suggested. be U.L. Listed and meet NEC and Mobile Home 1.
Page 8: Installing 4-Wire Power Cord
Installing 4-Wire Power Cord Converting 3-Wire to 4-Wire Power Cord 1. Remove rear wire cover. 2. Remove bottom strain relief screw and retain for WARNING further use. 3. Remove screw/hex nuts from terminal block and retain for further use. To avoid the risk of severe electrical shock or death, 4.
Page 9: Operation
Operation Operating Surface Elements Surface Element Settings Use to prepare food at less than boiling temperatures or to simmer. WARNING Use to maintain boiling of larger amounts of food, low To avoid risk of serious personal injury, property temperature frying and to maintain correct pressure in a damage, or fire, do not leave surface elements pressure cooker.
Page 10: Dual Radiant Element
Halogen Element (ARH6710) Dual Radiant Element Halogen element is able to provide constant non cycling Dual Element can be operated using inner element only power. LO setting allows excellent simmer and keep or both elements. warm capabilities. To use inner element 1.
Page 11: Cooking Utensils
Cooking Utensils • Use proper pan size. Do not use a pan that has a bottom smaller than element. Do not use utensils that overhang element by more than 1 inch. (Figure 11) Correct Size More than 1 inch overhang Figure 11 •...
Page 12: Electronic Oven Control
Electronic Oven Control (Figure 14) DELAY OVEN ON CLEAN STOP BAKE BROIL OVEN TIME CLEAN LOCK CANCEL TIMER STOP COOK CLOCK CLEAN BROIL BAKE ON/OFF TIME TIME SELF CLEAN OVEN DELAY OVEN OVEN ON CANCEL CLEAN STOP BAKE BROIL TIME CLEAN LOCK TIMER...
Page 13: Setting Clock
Setting Clock Oven Rack Placement Position oven rack before turning oven on. (Figure 16) 1. Press CLOCK pad. 1. Pull rack forward to stop position. • “TIME” displays. 2. Raise front edge of rack and pull until rack is out of 2.
Page 14: Baking
Delayed Baking Baking 1. Place food in oven. Open oven door to confirm nothing is stored in oven cavity 2. Press BAKE pad. and set racks to proper height before baking. Preheat • “BAKE” and “---°” displays. approximately 10 minutes before placing food inside oven. 3.
Page 15: Broiling
Prepare for Self-clean and Broiling Delayed Self-clean Cycle WARNING WARNING To avoid risk of fire, do not line the broiler grid with foil. To avoid risk of personal injury, do not touch oven vents • Foil may trap grease on top of grid close to burner or areas around vents during self-cleaning.
Page 16: Delayed Self-Clean Cycle
Delayed Self-clean Cycle Service Tones 1. Prepare oven for self-cleaning. Electronic range control is equipped with a self 2. Press CLEAN pad. diagnostic system. Self diagnostic system will alert you • “CLEAN”, “TIME”, and “— — — —” display. if there is a error or problem in the control. If electronic 3.
Page 17: Cooking Guide
Cooking Guide Baking Guide Follow these recommendations only as a guide for times and temperatures. Times, rack position, and temperatures may vary depending on conditions and food type. For best results, always check food at minimum time. Food Oven Temperature Cooking Time (°Fahrenheit) (Minutes)
Page 18: Beef And Pork Roasting Guide
Beef and Pork Roasting Guide Follow these recommendations only as a guide for times and temperatures. Times, rack position, and temperatures may vary depending on conditions and food type. For best results, always check food at minimum time. Food Oven Temperature Cooking time (°Fahrenheit) (Minutes per pound)
Page 19: Care And Cleaning
Care and Cleaning Removing Oven Door Replacing Oven Light CAUTION WARNING To avoid personal injury or property damage, handle To avoid risk of burns or electrical shock, disconnect oven door with care. electrical supply to oven before changing light bulb. •...
Page 20: Cleaning
For extra dried on soil, scrub surface with conditioner smoothtop cleaner conditioner available from an Amana Dealer. A single edge razor blade can be used to scrape off dried on soil. Do not use a harsh cleanser or steel wool pad. Metal markings should be cleaned after each use.
Page 21: Cleaning Smoothtop Rangetop
Cleaning Smoothtop Rangetop Problem Cause To Prevent To Remove Brown streaks and Cleaning with a sponge or Use smoothtop cleaner Use light application of specks cloth containing soiled conditioner with clean smoothtop cleaner detergent water. damp paper towel. conditioner with clean damp paper towel.
Page 22: Before Calling For Service
Before Calling for Service Problem Check Oven light does work. Check for loose bulb. Check for burned out bulb; replace with 40-watt appliance bulb. Oven does not heat. Confirm range is plugged in. If both oven and surface elements do not heat, check circuit breaker.
Page 23: Warranty
? @ e 3 @ ) X e S @ @ @ ( Y e ? V ' @ ( Y e W & @ 5 e @ ? Amana Appliances will repair or replace, including related labor and travel, any part (F.O.B. Amana, Iowa) which proves to be ? @ e V ' @ ) K O &...
Page 24: Quick Reference Instructions
6. Press COOK TIME pad. 7. Press pad until desired time cooking displays. To Cancel Remaining Cooking Time Press OVEN CANCEL pad. © 1997 Amana Appliances Part No. 36-31810801-0 Amana, Iowa 52204 Printed in U.S.A.
