Summary of Contents for InPlay Xstreamer
- Page 1 ANDROID TV BOX Instruction Manual IP – 2020 Thank you for your purchase of this product. Please read this manual carefully before using this product to ensure proper use.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTION PRODUCT FEATURES PACKAGE CONTENTS OVERVIEW CONNECTIONS REMOTE CONTROL QUICK GUIDE DETAILS OF OPERATION Connect to TV Connect to internet via cable Wi-Fi connection PPPoE configuration Bluetooth Portable hotspot Browser Applications File management Video player Picture viewer Settings Using TF card &USB device Other... -
Page 3: Safety Precaution
Thank you for choosing our X- Streamer. Before you begin to use this device, please read this manual thoroughly and keep it available for future reference. This manual will present you with the exciting features provided by our Entertainment System, which allow you to enjoy an unbelievably amazing visual experience. SAFETY PRECAUTION •... - Page 4 All operating and use instructions should be followed. 5. CLEANING Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning the exterior cabinet only. 6. ATTACHMENTS The manufacturer of this unit does not recommend any attachments, as they may cause hazards.
- Page 5 14. SERVICING Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 15. DAMAGE REQUIRING SERVICE Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: A.
-
Page 6: Product Features
PRODUCT FEATURES X- Streamer is an internet connected television platform, combining TV, PC, internet, and applications. Furthermore, it comes with a karaoke function where the user can sing at home streaming music directly from the device. X- Streamer brings a new experience into your life. ... -
Page 7: Overview
OVERVIEW 1. Power Button: To power on, hold down the button for 5 seconds. In sleep mode, a short (quick) click will start the system. 2. Remote Control Signal Sensor: Do not block IR receiver, to ensure proper use of the remote control. -
Page 8: Connections
CONNECTIONS Before connecting 1. Ensure that the device and other external equipment connected are switched off before commencing connection. 2. Read the instructions carefully before connecting external equipment. 3. Ensure that you observe the color coding when connecting audio cables. ... -
Page 9: Remote Control
REMOTE CONTROL 1.【POWER】Short press will put the system in standby mode, long press (hold), will shut the system down. 2.【Keypad for Numbers &Letters】 】Play or pause the video, music, or photo files. 3.【 4.【 】access web browser 5.【 】Stop the video, music, or photo files \ 】up, down, left, right 6.【... - Page 10 download more karaoke applications by the authorized channel and install them in your X- Streamer Home Smart Entertainment System via the App “Play” Store. 1. Connect your X- Streamer to your TV and start the system. 2. Connect your X- Streamer to your 2.1 or 5.1 channel speakers or amplifier through the AUX port.
-
Page 11: Details Of Operation
Hide toolbar again: click the on the toolbar. DETAILS OF OPERATION 1. CONNECT TO TV Use HDMI cable to connect X- Streamer to TV. To adjust HDMI output, enter the settings menu and select HDMI mode. Choose the desired resolution and save. 2. -
Page 12: Wi-Fi Connection
3. WI-FI CONNECTION If there is Wi-Fi signal available, enter the settings menu to configure Wi-Fi connection. Signal strength will show on menu bar when the Wi-Fi links successfully. Here you can enter your password for Wi-Fi if necessary: 4. Bluetooth This function allows the user to connect Bluetooth enabled speakers to the device. -
Page 13: Portable Hotspot
If connection is successful, there will be an icon on the bottom right of the menu bar. Notice: Be sure to obtain the correct user name and password from your Broadband supplier. 6. PORTABLE HOTSPOT When the device is directly connected by RJ45 cable (LAN) to the internet, you can also use it as a Hotspot via Wi-Fi. -
Page 14: Browser
7.BROWSER 1) Website When connected to the internet, Click Internet on homepage to surf the web. You can use a wireless keyboard, mouse or remote control for operation. Similar to a computer, you will need to input the website using the virtual keyboard (you can hide the virtual keyboard by clicking the right key of the mouse) ... -
Page 15: Applications
Choose settings, and it will show the regular menu, here you can set up your search engine and browsing preferences. When finished press confirm as seen below: 8. Application This X- Streamer comes with a customized User Interface (UI), and the end users can classify all of their applications and put them in the right category. -
Page 16: File Management
To shut down the application, press the button in the lower left-hand corner, and all of the running applications will show up. Click the left button on the mouse and “remove” it to shut down the application. 9. FILE MANAGEMENT Click EXPLORER >... -
Page 17: Video Player
10. VIDEO PLAYER Click the icon on the home screen, and the following video album screen appears. 1. Decrease the volume 2. Add bookmark 3. Previous 4. Play or pause 5. Next 6. Display choice 7. Exit 8. More info 9.Increase the volume 11.MUSIC PLAYER Click the... -
Page 18: Picture Viewer
Press for pause Press to resume playback. Press to skip to the next track in the album, playlist, or shuffle. Press to skip to the previous track in the album, playlist, or shuffle. Press to start balance gear menu ... -
Page 19: Using Tf Card &Usb Device
【Language & input】: set the language and keyboard or input method. 【Backup & reset】: setting allows you to back up data, automatic restore and factory reset 【Accounts】: setting lets you sync background data or auto-sync and manage accounts 【Date & time】: set the date and time 【Accessibility】: related accessibility option (suggested not to use) 【Developer options】: data for developer (Highly recommended that you DO NOT change) 【About device】: view the device information. -
Page 20: Troubleshooting
TROUBLESHOOTING 1. No signal on the HDTV Screen Check if the HDMI cable is correctly connected. Check if you have selected the correct HDMI input on your HDTV. 2. Cannot turn on your X- Streamer Check if the power connector is completely plugged into the DC socket of your X- Streamer ... -
Page 21: Specifications
SPECIFICATIONS System Product type Computer and TV combined Main chipset CORTEX-A9 Processor Main Frequency 1.6 GHz DDR3-1024MB Memory NAND 4GB Expandable memory Insert TF card or connect USB hard drive Android 4.1.1 Main features and functions Android applications A great variety of Android applications and games Internet browser Browse the web... -
Page 22: Installation Chart
- 22 -...
