- Page 1 KALED32XXXWB USER MANUAL...
-
Page 2: Table Of Contents
Contents Caution Safety Information Names of each part Front View Accessories Back View Remote Control Basic Operation OSD Menu 8-14 1. Picture menu 2. Sound menu 10-11 3. Channel menu 12-13 4. Feature menu 5. Setup menu Multimedia Operation 15-17 Recording Operation 18-20 Trouble shooting... -
Page 3: Caution
Caution The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 4: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below . Electrical safety To prevent overload, don't share the same mains supply socket with too many other items of equipment. -
Page 5: Names Of Each Part
Names of each part Front View INPUT: Display the input source menu. MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. POWER: Turn on/standby the TV set. Remote Control... -
Page 6: Back View
Names of each part Back View AC POWER IN Headphone out VIDEO HDMI3 AC POWER IN L/R in Headphone out PC-IN HDMI1/2/3 Coax VIDEO YPbPr... -
Page 7: Remote Control
Remote Control POWER POWER : Turn the TV on/standby. INPUT INPUT: Press to display the input source menu. PICTURE SOUND SLEEP ASPECT PICTURE: Select the picture mode. SOUND: Select the sound mode. SLEEP: Standby timer. ASPECT Change the screen display mode. NUMBER BUTTONS Press 0-9 to select a TV channel directly when you are watching TV. - Page 8 Remote Control POWER INPUT PICTURE SOUND SLEEP ASPECT MUTE SUBTITLE REC.LIST NICAM/A2 CH.LIST Load/eject DVD disc. Play/Pause program. Previous chapter. D.SET D.MENU D.SUB D.LAN Next chapter. Stop program. Fast reverse. Fast forward. TV/TXT TV/RADIO TV/TXT: Turn off/on the Teletext display. CANCEL REVEAL INDEX...
-
Page 9: Basic Operation
Basic Operation Power on/off 1. Connect to the power supply with the power adaptor. 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV Press POWER button on the TV or remote control. Input Source select YPBPR Press INPUT button on the TV set or remote control to display the... -
Page 10: Osd Menu
OSD Menu 1. Picture menu Description Picture Mode: Select your desired picture mode from Dynamic, Standard, Mild and User. Brightness: Adjust image black level. Contrast: Adjust image contrast. Sharpness: Adjust the sharpness (Gray and invalid in VGA/PC mode). Colour: Adjust image colour from black and white. Tint: Control the tint (available in NTSC mode only). -
Page 11: Sound Menu
OSD Menu OSD Menu 2. Sound menu Description Sound Mode: Select your desired sound mode from Standard, Movie, Music, Speech and User. Bass: Adjust the level of the lower-pitched sounds. Treble: Adjust the level of the higherpitched sounds. Balance: Adjust the audio output between left and right speakers. Surround: Turn on/off the surround sound function. -
Page 12: Channel Menu
OSD Menu 3. Channel menu (In ATV/DTV mode) Australia Description Channel Management: Enter the Channel management menu to edit the channels. Delete: Press RED button to sign the channels you want to delete, it will hint you when you exit. Lock: User must set the “Lock enable”... - Page 13 OSD Menu Country: Select your country. When the Child Lock is on, please enter the Password (Lock Password in Feature menu) to start Auto and Manual Search. Auto Search: Press OK button to enter the Auto Search menu, select search mode, and press OK button to start auto search.
-
Page 14: Feature Menu
OSD Menu 4. Feature menu Description Lock: This menu allows you to lock certain features of the television so that they can not be used or viewed. For example if you don’t want certain channels viewed by children or if the television is to be used in a hotel and you want certain channels be locked. - Page 15 OSD Menu Hotel Mode - Enter the Hotel Setting menu. Hotel Lock: Turn on/off the Hotel Lock function. Channel Lock: Disable the Channel menu in OSD. Picture Lock: Disable the Picture menu in OSD. Sound Lock: Disable the Sound menu in OSD. Feature Lock: Disable the Feature menu in OSD.
-
Page 16: Setup Menu
(available to download). This menu lets you upgrade that software onto the television. Further details of how to do this will be issued with the firmware. Contact the Kogan customer support team for further informtion via the Kogan website. -
Page 17: Multimedia Operation
Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select Media source by the buttons, and press OK button to enter the Multimedia menu as shown below. YPBPR HDMI1 HDMI2 HDMI3 Media 2). - Page 18 Multimedia Operation 1. Photo Play the photo OK button to change. Press button to select the option on the table, and press Note: You could press OK button to display the option table when it disappears. Play/Pause the photo playing. Stop and exit the full screen program.
- Page 19 Multimedia Operation 3. Movie Play the movie Press button to select the option on the table, and press OK button to change. Note: You could press OK button to display the option table when it disappears. Play/Pause the movie playing. Stop and exit the full screen program.
-
Page 20: Recording Operation
Recording Operation PVR settings Press the MENU button select Feature-PVR/Timeshift menu, press OK button to enter the menu as below. 1). Record File Format Select Record File Format mode from TS and PS for storing in the USB device. 2). Partition Select USB device informations Format: Press RED button to format the selected USB device. - Page 21 Recording Operation 5). Record List Display the Record list menu. Delete: Press RED button to delete the selected record plan. 6). Recorder Start Press OK button to start recording, same as the function of the REC button on the remote control. EPG and Timer Record Press EPG button on the remote control to display the EPG menu.
- Page 22 Recording Operation Recording Press REC button on the remote control to start recording in DTV mode, and the TV will show indication. Select “OK” item, and press OK to start recording, there will be a sign on the screen. Note: a.
-
Page 23: Trouble Shooting
Do not use other functions that are not mentioned in this user’s manual. In case a problem occurs with your TV, please take the following steps first. If you still have the problem, turn the power off and contact the Kogan customer support service center. i t c Is the power plug pulled out? Insert the power plug. -
Page 24: Specifications
Specifications Technical Specifications TVSystem PAL BG/DK/I SECAM BG/DK Screen size 32"(diagonal) Resolution 1366 x768 pixels(RGB) Aerial input (unbalanced) Power Consumption 100-240V ~ 50/60Hz 75W... - Page 25 Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
