Installation Manual
IMPORTANT -
PLEASE READ AND SAVE THIS
MANUAL BEFORE INSTALLING UNIT
CAUTION
- Before installation, careful consideration must be given to how
this system will operate if connected to any other piece of mechanical equip-
ment, i.e. a forced air furnace or air handler, operating at a higher static. After
installation, the compatibility of the two pieces of equipment must be con-
firmed by measuring the airflow's of the Heat Recovery Ventilators.
It is always important to assess how the operation of any HRV may interact
with vented combustion equipment (i.e. Gas Furnaces, Oil Furnaces, Wood
Stoves, etc.).
NEVER
- install a ventilator in a situation where its normal operation, lack of
operation or partial failure may result in the backdrafting or improper func-
tioning of vented combustion equipment!!!
Your ventilation system should be installed in conformance with the appropriate provincial or state require-
ments or in the absence of such requirements with local building codes.
Pool and Spa Ventilation Models
SHR 8005R • SHR 14105R
Heat Recovery
Ventilators
C C
R
C
US
Advertisement
Table of Contents
Summary of Contents for Fantech SHR 8005R
- Page 1 Your ventilation system should be installed in conformance with the appropriate provincial or state require- ments or in the absence of such requirements with local building codes. Pool and Spa Ventilation Models SHR 8005R • SHR 14105R...
- Page 3 • Weight 80.3 Kg (177 Lbs) rocker switch that will offer continuous ventilation. Compatible • Shipping Weight 98 Kg (217 Lbs) with all Fantech HRV controls. • Blowers (x2) 115V, 60 Hz, 2.7 Amps • Phase Single FROST CONTROL During the defrost sequence, a motorized...
- Page 4 SHR 8005R Light Commercial HRV Dimensions ELECTRIC BOX (can be relocated in the field 63mm(2.5") HIGH VOLTAGE LOW VOLTAGE to either the front or the back of the cabinet) ENTRY CONTROL PANEL 508mm(20") 559mm(22") 818mm(32.2") 653mm(25.7") 924mm(36.4") 914mm(36") PORT CONFIGURATION The unit has access doors on the front and back.
- Page 5 116 Kg (255 Lbs) 1100 rocker switch that will offer continuous ventilation. Compatible 1150 • Shipping Weight 134 Kg (295 Lbs) 1200 with all Fantech HRV/ERV controls. 1250 • Blowers (x4) 115V, 60 Hz, 2.7 Amps 1300 1350 • Phase...
- Page 6 SHR 14105R Light Commercial HRV Dimensions HIGH VOLTAGE ELECTRIC BOX (can be relocated in the field ENTRY to either the front or the back of the cabinet) LOW VOLTAGE 63mm(2.5") CONTROL PANEL 610mm(24") 559mm(22") 1199mm(47.2") 653mm(25.7") 1305mm(51.4") 914mm(36") PORT CONFIGURATION The unit has access doors on the front and back.
-
Page 7: Modes Of Operation
MODES OF OPERATION 1. Continuous / Ventilation Mode In this mode of operation, both fans are operating and exchanging air with the outside. The heat recovery ventilator (HRV) constantly exchanges the air at the rate you select, either at low or medium speed, and switches to high speed when activated by an optional remote control. -
Page 8: Installation
These appliance may cause lint, dust or grease to collect in the HRV , damaging the unit. NOTE: Connecting any of these type of appliances to the HRV will invalidate your warranty Model SHR 8005R 23.8Kg (52.5lbs) 22.5Kg (49.6lbs) 390mm (15.4") - Page 9 INSTALLING DUCTS GOING TO / FROM OUTSIDE INSTALLING THE DUCTING TO THE WEATHERHOODS OUTSIDE WEATHERHOODS – The weatherhoods must have built-in "bird" screens with 6.35 mm (1/4 inch) minimum mesh to prevent birds and rodents from entering into the ductwork. Do not use smaller mesh as it will be very susceptible to plugging up. The preferred location of the weatherhoods is: •...
-
Page 10: Air Flow Balancing
Note: A professional air balancer should be contacted to commission the system properly. A skilled HVAC Tech may complete the balance of air providing they possess the proper equipment. Call Fantech Technical support for assistance. INSTALLING BYPASS MODULE (BPM) REFER TO BPM INSTALLATION, OPERATION AND MAINTENANCE... -
Page 11: Maintenance
INSTALLATION EXAMPLES CON'T EXTERIOR WALL RECIRCULATION EXTERIOR WALL POOL HRV HVAC AIR HANDLER MECHANICAL ROOM INTERIOR WALL MDH1 Control EDF1R Control BACKDRAFT DAMPER EXTERIOR WALL MAINTENANCE CAUTION MAKE SURE UNIT IS UNPLUGGED BEFORE ATTEMPTING ANY MAINTENANCE WORK The following components should also be inspected regularly and well maintained. FILTERS The motor - The motors are factory balanced and lubri-... - Page 12 WIRING DIAGRAM SHR 8005R AND SHR 14105R United States Canada Fantech, reserves the right to modify, at any time and without notice, any or all of its products’ features, designs, components and specifi- 1712 Northgate Blvd., 50 Kanalflakt Way, cations to maintain their technological leadership position.
