Operator's Manual / Manuel d'utilisation / Libro de Instrucciones
Models: 56105308 (100), 56105309 (100H), 56105310 (400H)
READ THIS BOOK
LEA ESTE MANUAL
LISEZ CE MANUEL
This book has important information for the use and safe operation of this machine. Failure to read this book prior to
operating or attempting any service or maintenance procedure to your Clarke American Sanders machine could result
in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have
training in the operation of this machine before using it. If your operator(s) cannot read this manual, have it explained
fully before attempting to operate this machine.
All directions given in this book are as seen from the operator's position at the rear of the machine.
Form No. 56091031 8/11
BEXT Pro
EN
ES
FR
Clarke
®
English (2, 5, 10, 12, 14, 16, 18)
Español (3, 6, 11, 13, 15, 17, 19)
Français (4, 8, 11, 13, 15, 17, 19)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clarke 56105308 (100)
Summary of Contents for Clarke 56105308 (100)
- Page 1 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it.
-
Page 2: Table Of Contents
ENGLISH INSTRUCTIONS FOR USE REVISED DATE TABLE OF CONTENTS Page Introduction ................... A-3 Parts and Service ................A-3 Nameplate ..................A-3 Uncrating the Machine ..............A-3 Cautions and Warnings ..............A-4 Grounding Instructions ..............A-5 Know Your Machine............. A-6 – A-7 Know Your Switch Plate .............. -
Page 3: Introduction
Repairs, when required, should be performed by your Authorized Clarke Service Center, who employs factory trained service personnel, and maintains an inventory of Clarke original replacement parts and accessories. Call the CLARKE DEALER named below for repairs or service. Please specify the Model and Serial Number when discussing your machine. MODIFICATIONS Modifi... -
Page 4: Important Safety Instructions
ENGLISH INSTRUCTIONS FOR USE REVISED DATE IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offi ces other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine. -
Page 5: Grounding Instructions
INSTRUCTIONS FOR USE ENGLISH REVISED DATE 120VAC GROUNDING INSTRUCTIONS This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 6: Know Your Machine
ENGLISH INSTRUCTIONS FOR USE REVISED DATE KNOW YOUR MACHINE Recovery Tank Lid Vacuum Hose Barb Recovery Tank Drain (gate valve) Clamp Solution Hose Quick Disconnect Castor Recovery Tank Shutoff Float A - 6 BEXT Pro 100, 400 - 56091031 8/11... - Page 7 INSTRUCTIONS FOR USE ENGLISH REVISED DATE KNOW YOUR MACHINE (CONTINUED) Solution Tank Fill Opening Switch Plate 10 Filter Bag 11 Wheel 12 Pigtail Power Cord (Yellow) 13 Pressure Adjustment Knob (400H only) 14 Solution Filter 15 Pressure Gauge (400H only) 16 Cord Retainer Straps (two) 17 Hour Meter (Optional) 18 Pigtail Power Cord (Red) (100H &...
-
Page 8: Know Your Switchplate
ENGLISH INSTRUCTIONS FOR USE REVISED DATE KNOW YOUR SWITCHPLATE Model - This label identifi es the model of your machine. Vacuum Switch - This push-button switch turns on the vacuum. The switch will illuminate when it is on. Pump Switch - The pump switch will illuminate when it is activated, and it will turn on the pump. Heat Switch - The heat switch will illuminate when it is activated and will turn on the heater. -
Page 9: Preparing The Machine For Use
INSTRUCTIONS FOR USE ENGLISH REVISED DATE PREPARING THE MACHINE FOR USE Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Screw the Recovery Tank Lid (1) closed. Ensure the Recovery Tank Drain (3) is closed tightly. Pre-spray spots and heavy traffi c areas before extracting with the detergent of your choice. Mix the pre-spray according to the detergent manufacturer’s directions. -
Page 10: Operating The Machine
ENGLISH INSTRUCTIONS FOR USE REVISED DATE OPERATING THE MACHINE Follow the instructions in the Preparing the Machine for Use section of this manual. Turn off all the switches. Plug the power cords into properly grounded outlets. Do not connect both cords to the same outlet; the green, Circuit Indicator Light (E) on the switch plate should light up. - Page 11 INSTRUCTIONS FOR USE ENGLISH REVISED DATE OPERATING THE MACHINE 8/11 56091031 - BEXT Pro 100, 400 A - 11...
-
Page 12: After Using The Machine
Use a fl ushing compound (descale machine) *Check Carbon Brushes * Have a Clarke service technician check the vacuum motor carbon brushes once a year or after 300 operating hours. Check the pump motor carbon brushes every 500 hours or once a year. -
Page 13: Troubleshooting
INSTRUCTIONS FOR USE ENGLISH REVISED DATE TROUBLESHOOTING: IF THIS OCCURS CHECK THIS Solution tank is empty, or fi lter is plugged. Clogged spray tip(s). NO SPRAY Pump not running or not primed. Valve on wand not operating. Solution hose not completely connected to hose or to machine. This pump motor runs on AC voltage, so it should start running as soon as you turn on the switch.
