Summary of Contents for Intraphex TD-cadicue2013-V2
- Page 1 TD-cadicue2013-V2 INST ALLATION MANUAL NAVIGATION/VIDEO/camera INTEGRATION MODULE APPLICATIONS: 2013 Srx, xts, ats With Cue system...
- Page 2 Cont acts www.INTRAPHEX.com SUPPORT@INTRAPHEX.COM SUPPORT: 810.355.2266 EXT 4 Fax: 866.431.0676 FACETIME VIDEO TECH SUPPORT: VSUPPORT@INTRAPHEX.COM...
- Page 3 Contents What’s In The Box RGB/VIDEO INTERFACE POWER INTERFACE HARNESS T-HARNESS GPS ANTENNA INSTALL/USERS 8GB SD CARD WITH GUIDES NAVIGATION SOFTWARE RCA HARNESS EXTERNAL SPEAKER CAN BOX ...
- Page 5 CAN BOX THE CANBUS INTERFACERFACE CAN SUPPLY POWER AND GROUND TO THE ADDED DEVICES SUCH AS THE REVERSE CAMERA. THE MAXIMUM OUTPUT FOR THESE IS 1 AMP. IF THE DEVICE THAT YOU PLAN TO USE DRAWS MORE CURRENT THAN THIS, IT WILL BE NECESSARY TO USE A RELAY .
- Page 6 NOT ALL HARNESSES WILL BE USED IN TYPICAL INSTALLATION, SUCH AS AUDIO RCA HARNESS AND MOMENTARY SWITCH.
- Page 7 INTERFACE DIP SWITCH SETTINGS DOWN RGB (NAVI) INPUT ON RGB (NAVI) INPUT OFF VIDEO 1 ON VIDEO 1 OFF VIDEO 2 ON VIDEO 2 OFF RGB RES 800X480 HD RGB RES 480X234 GREEN WIRE TRIGGER TO OEM DISPLAY GREEN WIRE TRIGGER TO CAMERA INPUT FACTORY CAMERA NO FUNCTION...
- Page 8 REMOVE DECORATIVE TRIM BEZEL SURROUNDING THE RADIO CONTROLS AND LCD MONITOR. THERE ARE 6 CLIPS AND TWO 7MM SCREWS THAT HOLD IT IN PLACE. ONCE 7MM SCREWS HAVE BEEN REMOVED, GENTLY PULL THE TRIM BEZEL TO RELEASE THE CLIPS. ...
- Page 9 INTERFACE BACK INTO LCD MONITOR. UNPLUG 14 PIN BLACK CONNECTOR FROM MONITOR ASSEMBLY. PLUG CAR SIDE MALE 14 PIN CONNECTOR INTO FEMALE SIDE OF INTRAPHEX PROVIDED T-HARNESS. PLUG MALE SIDE OF INTRAPHEX T-HARNESS BACK INTO MONITOR ASSEMBLY. YOU CAN NOW INSTALL YOUR BACKUP CAMERA.
- Page 10 MOUNT GPS ANTENNA. IT CAN BE MOUNTED UNDER DASH PANEL AS LONG AS IT HAS A CLEAR VIEW OF THE SKY THROUGH PLASTIC ONLY. MOUNT SPEAKER IN DESIRED LOCATION, AND CONNECT GPS ANTENNA AND SPEAKER TO INTERFACE. ONCE ALL CONNECTIONS HAVE BEEN MADE YOU CAN TURN THE IGN ON AND PRESS AND HOLD THE TOUCH SCREEN UNTIL THE INTERFACES SWITCHES TO THE NAVIGATION INPUT.
- Page 11 INTRAPHEX authorized dealer, in the original vehicle, are free from defects in materials or workmanship under normal use and conditions for a period of THREE (3) years from date of purchase. A sales receipt, showing the installation date and INTRAPHEX product details are required to verify proof of purchase.
