MHSC 7THPDVS Installation And Operating Manual

Dv power vent system for use with approved mhsc fireplace signature command models

Advertisement

Quick Links

WARNING!
IF THE INFORMATION IN THIS MANUAL IS
NOT FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE,PERSONAL INJURY
OR LOSS OF LIFE.

FOR YOUR SAFETY

WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electric switch; do not use
any phone in your building.
Extinguish all flames.
Immediately call your gas supplier from
your neighbours phone. Follow the gas
suppliers instructions.
If you cannot reach your gas supplier call
the fire department.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR
OTHER FLAMMABLE VAPOURS AND
LIQUIDS IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE.
Installation and service must be performed
by a qualified installer, service agency or
your gas supplier.
Electrical connections should be per-
formed by a qualified electrician,
The main power supply must be turned
off before connecting power vent to main
power supply or before performing any
service.
DV Power Vent System
Model 7THPDVS
For use with Approved MHSC
Fireplace Signature Command
Models
Homeowner's Installation and
2353
power vent cover
Operating Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
C E RT I F I E D
20302353 2/11 Rev. 3
