Operation of New conception projector D8H/D8HD

D8H

D8HD

Model NO.:

D8H

(AV,TV,S-video,Audio-out,VGA,Scart,YPbPr,HDMI)

D8HD

D8H + DVB-T+ USB+ card reader

Table of Contents

Need help?

Do you have a question about the D8H and is the answer not in the manual?

Questions and answers

Summary of Contents for Hixley Electronics D8H

Page 1 Operation of New conception projector D8H/D8HD D8HD Model NO.: (AV,TV,S-video,Audio-out,VGA,Scart,YPbPr,HDMI) D8HD D8H + DVB-T+ USB+ card reader...
Page 2 Operation of New conception projector D8H/D8HD Catalogue 1. Production brief 2. Safeguards (1) Important information (2) Other information 3. Appearance introduction (1) Top view (2) Bottom view (3) Front view (4) Back view (5) Left side view 4. Operation introduction...
Page 3: Product Brief
The aspect ratio of 16:9 super wide screen makes you feel watching films at home, so you can enjoy the real home theater. D8H/D8HD is the best AV product designed for commercial, teaching, entertainment and household using.
Page 4 Operation of New conception projector D8H/D8HD 1. The D8 series(D8/D8H/D8HD) uses special light source of discharging gas. Please do not turn on or off D8 series frequently. Every turn on/off interval should be more than 30 minutes. Otherwise, it may damage the bulb easily and make it unworkable.
Page 5 Operation of New conception projector D8H/D8HD 13. The lens of D8 series is high precision optical apparatus, please do not touch with a hand and avoid other things touching it. When the D8 series leaves unused for a long time, please cover the lens with its lid, so as to avoid hurting the lens(lens lid is equipped with the D8 series) 14.
Page 6: Appearance Introduction
Operation of New conception projector D8H/D8HD Appearance introduction Top view 1. Channel + 6. input signal switch(AV/TV/VGA etc. input signal switch) 2. Volume — 7. ON/OFF button 3. Volume + 8. Lamp indicator 4. Channel — 9. Power indicator 5. System function menu...
Page 7: Front View
Operation of New conception projector D8H/D8HD hoisting hole should not exceed 10mm, to avoid an electric shock when the plastic enclosure is broken and the rod touched the high-tension electricity inside the machine. (Picture 2) Front View 1. Keystone correction knob 2.
Page 8: Left Side View
Operation of New conception projector D8H/D8HD Left Side View 1. Exhaust vent 9. Right audio output (Red) 2. Right audio input (Red) 10. S-Video input 3. Left audio input (White) 11. Left audio output (White) 4. Video input (Yellow) 12. Scart input 5.
Page 9: Button Operation
Operation of New conception projector D8H/D8HD never use too much effort, or else unwanted damage should occur.) (3) Focusing The focus length will change with the change of the distance between D8 SERIES and the screen, so that the image will blur. Now you can turn the lens gently with your hand, to correct the focal length so as to obtain distinct images.
Page 10 Operation of New conception projector D8H/D8HD ON/OFF Power： OSD menu/ switch menus Menu: Channel browse key; select functions in OSD CH+－: Volume adjusting button; it can also adjust the chosen function in OSD V+－： Channel selection from 0-9 0—9: Channel bit setting...
Page 11 Operation of New conception projector D8H/D8HD Signal Line connection diagram HDMI DVD (Picture 7) System function operation After the correct connection as above picture shows, enter OSD to make the setting. Press the button “ Menu” , picture as follow will show. Use “ CH+/－” to select the sub-menu and use “V+/－” to adjust.
Page 12 Operation of New conception projector D8H/D8HD 7. TV-CHANNEL sub-menu (Only for TV source) 8. DVB-T,USB,card reader menu (D8H without this function) Games (D8H without this function) See below picture “◄” / “►” key: to move the cursor left or right to select sub-menu “▲”/”▼”...
Page 13 Operation of New conception projector D8H/D8HD Press “▲”/”▼” to move cursor. Press “◄”/”►” to select item. Press”MENU” to return or exit menu. 1. PICTURE MODE: There are 4 picture modes: STANDARD/DYNAMIC/SOFT/PERSONAL. STANDARD: middle brightness and contrast; DYNAMIC: high brightness and contrast;...
Page 14 Operation of New conception projector D8H/D8HD Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu. 4. HUE : (Only at NTSC mode) As below: Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu.
Page 15 Operation of New conception projector D8H/D8HD Press “▲”/”▼” to move cursor. Press “◄”/”►” to select item. Press”MENU” to return or exit menu. 1. SOUND MODE: can support STANDATD/NEWS/MUSIC/PERSONAL 4 sound modes. STANDARD: suit for TV program; NEWS: suit for language program;...
Page 16 Operation of New conception projector D8H/D8HD Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu. NOTE: when user define the TREBLE value, the sound mode will auto change to PERSONAL. Operations for ADVANCE sub menu: (NOT for PC) ADVANCE sub menu can adjust NR, TTX language and Scart mode.
Page 17 Operation of New conception projector D8H/D8HD There are 5 language can be seleted : WEST/EAST/RUSSIAN/ARABIC/FARSI. 3. SCART MODE: (ONLY for SCART source) There are 3 sources for SCART mode: AUTO/RGB/CVBS: AUTO: can auto detect scart source; RGB: switch to SCART RGB source manually;...
Page 18 Operation of New conception projector D8H/D8HD Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu. 1. DURATION: Adjust OSD duration. As below: Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu.
Page 19 Operation of New conception projector D8H/D8HD Press “▲”/”▼” to move cursor. Press “◄”/”►” to select item. Press ”MENU” to return or exit menu. 1. H-POSITION: Adjust image horizontal position. As below: Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu.
Page 20 Operation of New conception projector D8H/D8HD Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu. 4. PAHSE: Adjust image phase. As below: Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu.
Page 21 Operation of New conception projector D8H/D8HD Press “▲”/”▼” to move cursor. Press “◄”/”►” to select item. Press ”MENU” to return or exit menu. 1. PIP: Switch PIP function on or off: OFF/PIP: OFF: switch off PIP function; PIP: switch on PIP function.
Page 22 Operation of New conception projector D8H/D8HD 5. V-POSITION: Adjust the PIP window vertical position. As below: Press “◄” to decrease value, Press “►” to increase value. Press “MENU” to return or exit menu. 6. BOARD COLOR: Select PIP window board color: BLACK/BLUE:...
Page 23 Operation of New conception projector D8H/D8HD Select TV sound system. There are 6 sound system can be selected: AUTO/BG/DK/I/L/L’. Such as: PAL-I: China,UK PAL-BG: Australia,Germany SECAM-I: France Attention: You should switch to TV signal source first ,and then select TV sound system,and then select”Auto search”,if you don’t select correct TV sound system,will appear noise or no picture no sound.
Page 24 Operation of New conception projector D8H/D8HD DISPLAY Function Press “DISPLAY” to enter image info menu as below: Press “DISPLAY” or “MENU to exit menu. Input source choice Menu: Press “TV/AV” key to enter Input source choice Menu. It can change to different input source.
Page 25 Operation of New conception projector D8H/D8HD Press “POWER” to power off. Press “MENU” to return (still power on). In this mode, if the machine will return to “working” mode after 10 seconds. Volume Adjustment Menu: Without enter to “Main Menu”, press the “Vol+” / “Vol-“ button directly to enter the “Volume Adjustment Menu”...
Page 26: Installation
Operation of New conception projector D8H/D8HD 8. DVB-T,USB,card reader menu 1 Digital TV In the main menu of the system, under Digital TV, there are such as options as auto TV search or broadcast programs, program management, system setup, software update and software version information view etc.
Page 27 Operation of New conception projector D8H/D8HD Figure 1.3 Installation menu 1.1.1 Area Search Area search is a kind of intelligent and convenient mode of programs searching, which covers programs of all frenquent points of target countries or regions. At present, this system covers many targets countrier and regions including: Germany/ England/ Italy/ France/ Spain/ Holland/ Taiwan/ China/Norway/Swead/Finland;...
Page 28 Operation of New conception projector D8H/D8HD Figure 1.5 1.1.2 Manual Search If you understand much about digital TV and know the frequency of the program or if you want to scan the program at any frequency required, you can select manual scaning, which can save your much time.
Page 29: Channel Manager
Operation of New conception projector D8H/D8HD Figure1.7 auto search menu 2. Prior to auto searching, you need to configure relevant parameters including: (1).Start Freq (KHz): the default frequency is 474000 KHz. You can input relevant digitals to modify it; (2).End Freq (KHz): the default frequency is 474000 KHz. You can input relevant digitals to modify it;...
Page 30 Operation of New conception projector D8H/D8HD 1.2.1 Channel Organizer Channel organizer page includes favorite channels, channel deleting, moving, locking and rename. 1. You can enter the page as shown in the figure below via “MENU->Digital TV-> Channel Manager -> Channel Organizer”...
Page 31 Operation of New conception projector D8H/D8HD 5. Press RETURN key to exit Channel Organizer page. 1.2.2 Channel Sorting The channels shall be listed according to certain sequence so that the user can easily find them. 1. you can enter the page As shown in the figure below via “MENU->Digita TV-> Channel Manager -> Channel Sorting”:...
Page 32 Operation of New conception projector D8H/D8HD 1.2.3 Channel Grouping Group channels according to Movies, Sport,Music, Kids, Fashion etc. 1. You can enter the page As shown in the figure below via “MENU->Digita TV-> Channel Manager -> Channel Grouping”: Figure 1.13 Channel Grouping page 2.
Page 33 Operation of New conception projector D8H/D8HD Figure 1.15 Add Channel page Under Add Channel menu, there are 6 parameters for adding one channel as follows: (1).Area Name: For Area Name, press the RIGHT key of the remote controller to enter the Area Name list on the right, then press UP/DOWN key to choose area name, press ENTER key to confirm;...
Page 34 Operation of New conception projector D8H/D8HD password via the 0－9number key of the remote controller, then enter Delete All menu as shown in Figure 1.17: Figure 1.17 Delete All Page 2. To delete all TV channels, press UP/DOWN key to move the cursor to ALL TV Channels option, press ENTER key, then the system will hint with ”Delete all TV Channels?”dialogue box as shown in Figure 1.18:...
Page 35 Operation of New conception projector D8H/D8HD Figure 1.19 Configuration page 1.3.1 OSD Via OSD option setup, you can set the user interface display mode according to your own demand.Via the menu ( MENU->Digita TV->Configuration -> OSD), you can enter OSD menu, as shown in Figure 1.20: Figure 1.20 OSD Setting Page...
Page 36: Software Upgrade
Operation of New conception projector D8H/D8HD OSD Language option: (1)Move the cursor onto OSD Language option , Press RIGHT key to enter OSD Language List as shown in Figure 1.21: Figure1.21 (2)Press LEFT/DOWN key choose language; (3).Press ENTER key to confirm system interface language selection, then the setting is effective, and then the interface language turns into the currently chosen language, the cursor can move onto OSD Language option on the left;...
Page 37: Usb Media Play
Operation of New conception projector D8H/D8HD Figure 1.36 Software Upgrade menu 2 USB Media Play This mainboard of this projector integrates powerful function to support USB and you can connect Ex-equipmentsvia the USB. At present, system can support usual USB media players and upgrade to system software.
Page 38: Usb Music
Operation of New conception projector D8H/D8HD Figure 2.2 Press RETURN key to return previous directory ; 3. Press ＵP/DOWN key to choose movie file name; 4. Press ENTER key to play movies; 5. Press FF key to play movie quickly( ×2, ×4, ×8, ×20, ×1);...
Page 39: Usb Photo
Operation of New conception projector D8H/D8HD Figure 2.3 Press RETURN key to return to the previous directory ; 3. ＵP/DOWN key to choose music file name; Press ENTER key to play music file, its interface is as shown in Figure 2.4: Figure 2.4 playing music...
Page 40: User's Maintenance
Operation of New conception projector D8H/D8HD Figure 2.5 Press RETURN key to return to the previous directory ; 3. ＵP/DOWN key to choose photo file name; 4. Press ENTER key to play Photo file ; 5.Press PREV key to play previous Photo, NEXT key to play next Photo;...
Page 41 Operation of New conception projector D8H/D8HD (3) Clean the dust and spot on the external lens gently with dry cotton cloth. Conventional diagram for cleaning screen filter (Picture65)
Page 42 Operation of New conception projector D8H/D8HD Illustration of light bulb replacement (Picture 66)
Page 43 Operation of New conception projector D8H/D8HD Simple repair and solution The D8 SERIES is a high-tech product integrating optical, mechanical, and electronic components, with CPU and several protection circuits installed. In case of violating the operation procedure or improper setting, the protection circuit of the D8 SERIES will start to work. Then some abnormal symptoms will occur to the D8 SERIES.
Page 44 Operation of New conception projector D8H/D8HD Parameter and Function Technical specifications D8H/D8HD Model No. TV System D8H/D8HD PAL/NTSC/SECAM Display Technology 3.5 inch LCD support: 800*600,1024*768,1280*1024 (physical resolution 640*480) Brightness 2000ansi(MAX) Contrast ratio 500:1 Image enhance ACM(Adaptive Color Management) &ACC(Adaptive Contrast Technology &...
Page 45: Supplied Accessories
Operation of New conception projector D8H/D8HD （ Ω ） (1) Signal compatibility:TV AV,S-video,Audio-out,VGA,Scart,YPbPr,SD card,HDMI,USB,DVB-T (D8H without DVB-T,USB,card reader) (2) Keystone correction and picture rotation, the picture aspect ratio can switch from 16:9 to 4:3. (3) OSD screen display function (4) The fans continue to work after the D8 SERIES is turned off (lasting for 10 minutes so as to prolong the lamp life．)
