Rev. 9-2011
DIGITAL FREE TO AIR SATELLITE

INSTALLATION MANUAL

This manual will provide you with step by step instructions on how
to setup your satellite receiver, program the receiver, and start
watching TV.
IMPORTANT NOTICE:
make sure that the receiver is NOT plugged into the power outlet
before you start attaching and/or detaching the cables & wires
coming into your receiver from the satellite dish, and going to
your TV from the receiver.
connected to your receiver, you can then plug the receiver in.
Failure to follow this step may damage your LNBF on your satellite
dish, and/or damage your new receiver.
negligence, and therefore it's not covered under your warranty.
To start out, first connect the cable coming in from your satellite
dish to the "LNB IN" port on the back of the receiver.
receiver to your TV using the RF OUT port of the receiver with RG6
or RG59 cable (Not supplied) or the supplied HDMI cable using the
HDMI ouput port, or RCA cables using the Audio/Video port.
The only cable approved to connect your satellite dish
IMPORTANT:
to your receiver is RG6 coaxial cable.
on the cable going from the satellite dish to your receiver, be
sure that the wires around the center conductor (center wire) is
not touching or making any kind of connections to the center
conductor.
If the small strands of wires, even if one is touching
the center conductor, it will short out the wire and will cause
your receiver and/or your LNBF to burn and your satellite system
will not work properly.
this will not be covered under warranty.
L E X I U M
D B S 7 0 0 0
RECEIVER
When installing your new satellite receiver,
Once you have all the wires and cables
Any damage caused to your equipment due to
Such damage is due to
When putting the connectors
Connect the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBS7000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LEXIUM DBS7000

  • Page 1: Installation Manual

    Rev. 9-2011 L E X I U M D B S 7 0 0 0 DIGITAL FREE TO AIR SATELLITE RECEIVER INSTALLATION MANUAL This manual will provide you with step by step instructions on how to setup your satellite receiver, program the receiver, and start watching TV.
  • Page 2 Rev. 9-2011 INSTRUCTIONS: 1. Attach all the cables and wires to your satellite receiver. 2. Plug your satellite receiver to a power outlet. 3. Turn on power to the receiver by flipping the power switch on the back of the satellite receiver. 4.
  • Page 3 Rev. 9-2011 Once you determine what type of LNBF you have, press the V+ button to choose either Standard or Universal. Please make sure that the LO frequency displayed matches the LO frequencies above respectively. Once you have determined that the information is correct, press the OK button on the remote to save and close the small window.
  • Page 4 Rev. 9-2011 direction at where you point your dish is different for every state, city, and zip code. To find the Azimuth, Elevation, & Polarization for Galaxy 19 satellite in your area, simply visit http://www.wsidigital.com/azel_finder.htm. Make sure that “97W Galaxy 19 (G-19)” is chosen from the list. Type in your zip code, and press press enter.
  • Page 5 Rev. 9-2011 on the bottom of the screen will turn blue & green. After verifiying signal reception, press the EXIT button once. Press the CH▼ button until you highlight “Auto Scan”. Press OK on Auto Scan to enter the Auto Scan screen. Make sure you have the following settings on this screen: 1.
