Summary of Contents for Rockville RVD13-FD
- Page 1 RVD13-FD RVD15-FD RVD17-FD FLIP DOWN ROOF MOUNT TFT LCD MONITOR WITH DVD PLAYER USER’S MANUAL...
- Page 2 Thank you for purchasing this Rockville Flip Down Roof Mounted DVD TFT LCD Monitor. We are very proud to bring you what we consider to be the absolute best value in mobile audio products. This project has been a culmination of years of devel- opment involving a team of dreamers, engineers, designers and marketing gurus.
-
Page 3: Table Of Contents
• Rockville does not recommend connecting hanging wires or cables to auxiliary connectors while the vehicle is in motion. • This product must not obstruct the driver’s rear view when installed or used. -
Page 4: Powering The Unit
Powering the Unit • Turn the engine key to the “ACC” or “ON” position • Press and hold the power button for 3 seconds • The unit will turn on. • When the engine key is turned to the “OFF” position, the unit will turn off. -
Page 5: Control Panel
Control Panel RVD13-FD RVD15-FD RVD17-FD Press and hold for power. Press once to play and pause Power/Play/Pause content. Press and hold to switch to AV IN. Press once to stop AV IN/Stop content. Menu Access and adjust the unit settings. -
Page 6: Remote
Remote RVD13-FD RVD15-FD RVD17-FD Tip: Remote buttons glow in the dark. Tip: Remote buttons glow in the dark. -
Page 7: Dvd
Remote RVD13-FD RVD15-FD RVD17-FD Power Turn unit on and off. TFT Menu Access unit settings menu. PBC Menu Setup playback settings. Title Return to the title screen. Up Arrow Navigate up when available. Mute Mute audio. Program Adjust unit functionality. - Page 8 Getting Started 1. Insert the DVD into the disc drive. 2. Wait for the DVD to load. 3. Navigate the DVD menu for options. Control • Play/pause and navigate through the DVD menu options using the designated buttons found on both the control panel and the remote. Playable discs •...
-
Page 9: Installation Guide
5. Connect the wire harness in the following order: Ground wire (Black), Battery wire (Yellow), +ACC wire (Red) 6. Attach the Rockville unit to the metal mounting plate using the screws. Car Interior Roof (Mounting Plate) -
Page 10: Wiring
• To connect 12 volt constant power. Note: When output to more than 1 external displays is desired the use of a video amplifier is recommended to preserve picture quality. (Refer to diagram below) (Output) (Output) *Video Amplifier NOT INCLUDED (Rockville Flip Down Unit) - Page 11 Visit us at: Rockvilleaudio.com Due to constant improvements, these specifications are subject to change without notice. Copyright 2014...
