MEMORY INSTALLATION GUIDE:
CompactFlash™ Memory Card
This guide will cover the installation and care of Viking's CompactFlash Memory and
optional adapter.
Description
CompactFlash Adapter
4MB CompactFlash
8MB CompactFlash
12MB CompactFlash
16MB CompactFlash
24MB CompactFlash
32MB CompactFlash
48MB CompactFlash
64MB CompactFlash
80MB CompactFlash
Caution:
Electro Static Discharge (ESD) can damage electronic components. Before touching
the memory module, ensure that you are discharged of static electricity by touch-
ing a grounded metal object.
BASIC HANDLING INSTRUCTIONS:
• Do not bend or flex the card or the adapter.
• Do not drop the card or the adapter.
• Keep the card and adapter away from moisture.
• Keep the card and adapter out of direct sun light.
DIGITAL CAMERA INSTALLATION INSTRUCTIONS:
1. The CompactFlash memory card can be inserted into numerous digital cameras to
store pictures. The card can then be used to transfer the pictures into a laptop or a hand-
held PC. The installation of a CompactFlash card into a laptop or a handheld PC may
require an optional CompactFlash adapter. Please refer to the section "CompactFlash
Adapter Installation Instructions" for more information.
To install a memory card into a digital camera, align the notches on the card with those
of the CompactFlash socket in the camera. Then firmly insert the card into the socket
until it is completely seated.
Viking P/N
CF-ADAPT, RCF-ADAPT
CF4M, RCF4M
CF8M, RCF8M
CF12M, RCF12M
CF16M, RCF16M
CF24M, RCF24M
CF32M, RCF32M
CF48M, RCF48M
CF64M, RCF64M
CF80M, RCF80M
MP3 PLAYER INSTALLATION INSTRUCTIONS:
1.The CompactFlash memory card can be inserted into numerous MP3 Players. The card
can then be used to store music in MP3 format for play on your MP3 player. The card can
also be used to transfer MP3 music files from your MP3 player to your laptop or handheld
PC. The installation of a CompactFlash card into a laptop or a handheld PC may require
an optional CompactFlash adapter. Please refer to the section "CompactFlash Adapter
Installation Instructions" for more information.
To install a memory card into a MP3 player, align the notches on the card with those of
the CompactFlash socket in the player. Then firmly insert the card into the socket until it
is completely seated.
If you are not familiar
with the procedure of
installing and removing
a CompactFlash memory
card into your digital
camera, please refer to
the camera's "Owner's
Guide."
Note: The MP3 player
may require the latest
software from the play-
er's manufacturer to ini-
tialize or use the card.
LAPTOP/ HANDHELD PC INSTALLATION INSTRUCTIONS:
1. The CompactFlash memory card can be inserted into numerous laptops or handheld
PCs to store information. The card can then be used to transfer files from your laptop or
handheld PC to other laptops, handheld PCs, digital cameras or MP3 players. The instal-
lation of a CompactFlash card into a laptop or a handheld PC may require an optional
CompactFlash adapter. Please refer to the section "CompactFlash Adapter Installation
Instructions" for more information.
To install a memory card into a laptop or handheld PC, align the notches on the card with
those of the CompactFlash socket in the system. Then firmly insert the card into the
socket until it is completely seated.
If you are not familiar with the procedure of installing and removing a CompactFlash
memory card into your digital camera, please refer to the camera's "Owner's Guide."
If you are not familiar
with the procedure of
installing and removing
a CompactFlash memo-
ry card into your digital
camera, please refer to
the camera's "Owner's
Guide."
