Page 1: User Manual
Dual Band Wireless Surveillance Video Router WRT-750N User Manual Quality Service Group Product Name: Dual Band Wireless Surveillance Video Router Release Date: 2014/03 Manual Revision: V1.0 Web Site: www.brickcom.com support@brickcom.com Email: info@brickcom.com © 2014 Brickcom Corporation. All Rights Reserved... -
Page 2: Table Of Contents
Table of Content ....................3 ACKAGE ONTENTS PRODUCT DESCRIPTION ..................4 ....................4 ENERAL EATURES HARDWARE INTRODUCTION ................5 ..................... 5 PPEARANCE LED I ....................6 NDICATORS ..................7 YSTEM EQUIREMENT III. SOFTWARE INTRODUCTION ................8 ....................8 QUIPMENT EEDED Setup Wizard .................... -
Page 3: Package Contents
Package Contents WRT-750N Power Adapter Ethernet Cable WRT-750N User Manual... -
Page 4: Product Description
In BrickOne Solution , this router is perfect match with Brickcom cameras. For wired connection, WRT-750N is equipped with 4 Gigabit Ethernet ports for faster file transfer. When the connection goes under wireless, it can transmit streaming under 2.4GHz and 5GHz bands. -
Page 5: Hardware Introduction
II. Hardware Introduction 1. Appearance Front Back WRT-750N User Manual... -
Page 6: Led Indicators
Device Ready for New WPS Setup Amber Steady Link Detect with 1000Mbps Flashing Data Transmission Green Steady Link Detected with 10/100Mbps Flashing Data Transmission No Link Green Solid Light Device Connected to USB Port Flashing Data Transmission Light Off No Activity WRT-750N User Manual... -
Page 7: System Requirement
3. System Requirement Computer System • Windows®, Macintosh, or Linux-based Operating System • An Installed Ethernet Adapter Browser Support • Internet Explorer • Safari • Firefox WRT-750N User Manual... -
Page 8: Software Introduction
III. Software Introduction Equipment Needed Brickcom Router, Power Adapter, and Ethernet cable (included) High-speed Internet connection and access to Internet modem (Users should contact their local provider assistance if needed) Additional Ethernet cable (usually provided with the Internet modem) ... - Page 9 ISP -- or you can configure the router manually. It is recommended that, if you aren't used to setting up Internet connections, you let the Smart Setup Wizard do some of the work for you. WRT-750N User Manual...
- Page 10 PPP software on your PC to connect to the Internet. Choose ‘Yes’ to do auto detection. B. Detect the PPPoE Connection C. Set up the PPPoE Connection by Keying the Correspondent Information WRT-750N User Manual...
- Page 11 PPP software on your PC to connect to the Internet. Account Name(Also known as Host Name or System Name) For most users, type your account name or user name in this box. For example, if WRT-750N User Manual...
- Page 12 Use This MAC Address to manually type the MAC address for a different computer. The format for the MAC address is XX:XX:XX:XX:XX:XX. This value may be changed if the Use Computer MAC Address is selected once a value has already been set in the Use This MAC Address selection. WRT-750N User Manual...
-
Page 13: Running Status
Firmware Version: This is the current software the router is using. This will change if you upgrade your router. Internet Port: These are the current settings that you set in the Setup Wizard or Basic Settings screens. • MAC Address. The physical address of the router, as seen from the Internet. WRT-750N User Manual... - Page 14 • Enable Guest Network. Indicates if the clients connected to this guest network are allowed to access local LAN network. Click Show Statistics to see router performance statistics such as the number of packets sent and the number of packets received for each port. WRT-750N User Manual...
- Page 15 Click Connection Status to see information about your current connection. 2.2Client List This page shows the IP Address, Device Name and MAC (Media Access Control) Address for each computer attached to the router. WRT-750N User Manual...
-
Page 16: Network Setup
• RIP Direction: RIP (Routing Information Protocol, RFC1058 and RFC1389) allows a router to exchange routing information with other routers. The RIP Direction selection controls how the router sends and receives RIP packets. Both are the default. WRT-750N User Manual... - Page 17 When you specify a reserved IP address for a PC on the LAN, that PC will always receive the same IP address each time it accesses the DHCP server. Reserved IP addresses should be assigned to servers that require permanent IP settings. WRT-750N User Manual...
-
Page 18: Wan Setup
For most users, type your account name or user name in this box. For example, if your main mail account is JerAB@ISP.com, then put JerAB in this box. If your ISP has given you a specific Host name, then type it (for example, CCA7324-A). WRT-750N User Manual... - Page 19 Use This MAC Address to manually type the MAC address for a different computer. The format for the MAC address is XX:XX:XX:XX:XX:XX. This value may be changed if the Use Computer MAC Address is selected once a value has already been set in the Use This MAC Address selection. WRT-750N User Manual...
-
Page 20: Wireless Setting
Stations. Stations which have no SSID (or a null value) can then adopt the correct SSID for connections to this Access Point. Enable Wireless Isolation If checked, the wireless client under this SSID can only access internet and it can't access other wireless clients even under the same SSID. WRT-750N User Manual... - Page 21 Enter a value of up to 32 alphanumeric characters. The same name (SSID) must be assigned to all wireless devices in your network. The default SSID is BRICKCOM-2.4G-001, but we strongly recommend that you change your network's name (SSID) to a different value. This value is case-sensitive. For example, SSID is not the same as SSID.
- Page 22 Select which of the four keys will be used, and enter the matching WEP key information for your network in the selected key box. For 64-bit WEP - Enter ten hexadecimal digits (any combination of 0-9, A-F). For 128-bit WEP - Enter twenty-six hexadecimal digits (any combination of 0-9, A-F). WRT-750N User Manual...
- Page 23 Passphrase must be constituted of either 8 to 63 ASCII characters or exactly 64 hex digits. A hex digit is one of the following characters: 0, 1, 2, ..., 8, 9, A, B, C, D, E, and WRT-750N User Manual...
-
Page 24: Guest Network
4.2Guest Network This is to allow visitors to use internet access at your home if you don't want to let them know your wireless security key. WRT-750N User Manual... -
Page 25: Advanced Setup
WPS process at the same time, and you can fins the client's PIN on the client's utility GUI. 4.4Advanced Setup Warning: The Wireless Router is already configured with the optimum settings. Do not alter these settings unless directed by support. Incorrect settings may disable the Wireless Router unexpectedly. WRT-750N User Manual... - Page 26 PCs based on their MAC addresses. From the Wireless Settings menu, click the Setup Access List button to display the Wireless Access List menu. Note: This function does not work on wireless guest network. WRT-750N User Manual...
-
Page 27: Forwarding
4 hops, which should be fine for most home networks. If you notice that some devices are not being updated or reached correctly, then it may be necessary to increase this value a little. WRT-750N User Manual... -
Page 28: Port Forwarding
Port Triggering monitors outbound traffic. When the router detects traffic on the specified outbound port, it remembers the IP address of the computer that sent the data and triggers the incoming port. Incoming traffic on the triggered port is then forwarded to the triggering computer. WRT-750N User Manual... -
Page 29: Access Control
Start Blocking time and an End Blocking time. Note: Enter the values as 24-hour time. For example, 10:30 am would be 10 hours and 30 minutes and 10:30 pm would be 22 hours and 30 minutes. WRT-750N User Manual... - Page 30 • Blocking access to certain domains (for example, www.badstuff.com/XXX) or • Blocking sites that contain certain words (like profanity or explicit sexual material). When users try to access a blocked site, they will get a message: "Blocked by Firewall". WRT-750N User Manual...
- Page 31 Time-dependent information, like video or audio, will have a higher priority than normal traffic. For WMM to function correctly, Wireless clients must also support WMM. WRT-750N User Manual...
- Page 32 In certain heavy traffic circumstance, it may nice to privilege a special host with half of whole WAN bandwidth. I t can be done by checking option Enable Trusted IP address, and filling that host IP address. WRT-750N User Manual...
-
Page 33: Dynamic Dns
This can happen when RIP is disabled on the LAN. (See the LAN IP Setup page.) All defined static routes appear in the table. To add or delete a route, work in the area under the Static Routes table WRT-750N User Manual... -
Page 34: Email
You can always check the logs manually by viewing the Logs page. If you don't want to receive e-mails, leave the boxes blank. WRT-750N User Manual... -
Page 35: Security Options
• Click IP Address Range to allow access from a range of IP addresses on the Internet, enter a beginning and ending IP address to define the allowed range. • Click Everyone to allow access by everyone on the Internet. WRT-750N User Manual... -
Page 36: Wan Security Setup
If you want the Router to respond to a 'ping' from the Internet, click this check box. This can be used as a diagnostic tool. Like the DMZ server, this can be a security problem. You shouldn't check this box unless you have a specific reason to do so. WRT-750N User Manual... - Page 37 Enable IPv6 Pass-Through IPv6 pass-through is disabled by default. If you have IPv6 capable devices in your configuration and would like to use IPv6 instead IPv4, you can click on check box to enable "IPv6 Pass-Through. WRT-750N User Manual...
-
Page 38: Multicast Control
The IGMP Proxying function lets a LAN PC to receive the multicast traffic it is interested in from the Internet. You can click on this check box to disable the function if you do not need it. 12. Storage Setup WRT-750N User Manual... -
Page 39: Storage Setup
Of course, this requires the users who login the server have an account name and password, and have the appropriate permissions, such as upload, download and other privileges. FTP server port Set the server listening port, the default listening port is 21. WRT-750N User Manual... - Page 40 • Download - Users can download files in the USB storage device, but they cannot upload files to the storage device. Note: To open this permission before, you should also give the users the permission of browse. Note: Users can also have a combination of these rights. WRT-750N User Manual...
- Page 41 USB disk. Notice: This device supports max single file size is less then 2GB To view FTP files, please access via the route: ftp:// IP_Address By keying the username and password to get access to the FTP site. WRT-750N User Manual...
- Page 42 Netbios Name Set the device network name New Password You can modify the root user's password here Confirm Password Confirm the New Password Enable USB Whether to allow USB storage Enable Anonymous Whether to allow anonymous access. WRT-750N User Manual...
- Page 43 If you choose this, users do not need to enter a user name and password that can log into the samba server. To view Samba folder, please access via the route: \\IP_Address Default Username: root Password: 12345 WRT-750N User Manual...
-
Page 44: System Information
"Automatically synchronize with Internet time servers". First NTP time server: Please specify the first server of NTP you want to use. Second NTP time server: you can input an additional time server here, making your WRT-750N User Manual... - Page 45 You can restore the router's settings from this file. 13.4 Set Password You use the Set Password page to change the password you use to access the Settings pages -- NOT your ISP account password. WRT-750N User Manual...
-
Page 46: Reset To Factory Default
Once you click Upload do NOT interrupt the process of sending the software to the router and restarting the router. If you think the process may be interrupted in some way, click Cancel to keep the current router software. 13.7 Router Reboot This screen allows you to restart the router. WRT-750N User Manual... -
Page 47: Contacting Technical Support
Contacting Technical Support If you face any issues about the WRT-750N, please contact the technical support. Before contacting the technical support, please check the following information in advance: • Model Name (e.g. WRT-750N) • MAC address and S/N (located on the back side of the router) Technical Support support@brickcom.com...
