Summary of Contents for Snapfon ez-ONE C
-
Page 1: Quick Start Guide
C Quick Start Guide TECHNICAL DATA Quad band GSM 850/900/1800/1900MHz World phone • Battery: Li-Ion 3.7V / 1000mAh Dimensions: 103x49x15mm Standby-Time: 120h Weight: 79.6g (With Battery) Talk time: 120min... -
Page 2: Inserting Sim Card
***Each Step starts from the Home Screen with Time and Date showing*** Step 1 Make sure that your SIM card is active Contact your service provider to make sure your SIM card has been activated. Contact your service provider if you have problems with your SIM card. -
Page 3: Inserting And Charging The Battery
Step 3 Inserting and charging the battery Fig. 3: Insert the battery at an angle with the gold contacts to the bottom, to the gold contacts in the battery compartment and press down. Slide cover to closed position with a ‘click’ . Fig. -
Page 4: Set Up Voicemail
Step 5 Set Time and Date Scroll UP 2 times using • until you reach the Settings menu, then press Scroll DOWN 4 times • then press • Use the to select either AM/PM. Scroll DOWN 1 time • to enter time using the keypad. -
Page 5: Add A New Contact
Step 7 Add a New Contact Scroll UP 1 time • until you reach the Phonebook menu, then press Scroll DOWN 1 time until you reach New • Contact then press • Text entry screen will appear. • Enter contacts name using the keypad. Press to save. -
Page 6: Settings Menu
Step 8 Set up SOS Button Scroll UP 2 times using • until you reach Settings menu. Scroll UP 4 times using until you reach SOS • Settings menu. (This menu is for customizing how you use this feature.) Scroll to select • SOS Button - turn ON/OFF the SOS button. -
Page 7: Making A Call
Step 9 Setting up Speed Dial Contacts Scroll UP 1 time using • then press Scroll UP 2 times using 2 times. • then press • Scroll to select Speed dial location. • Press Scroll UP or DOWN using • to choose contact from phonebook •... - Page 8 High intensity LED Flashlight - Switch up: Flashlight ON - Switch down: Flashlight OFF Lanyard Connection - For use with optional Lanyard Headphone Port - Use only Snapfōn earphones, or Nokia 3.5 mm earphones. Power Port - Use only included Snapfōn Wall Charger or optional Snapfōn Car Charger.
- Page 9 Volume Control + / - Flashlight Change the handset - Switch up: Flashlight ON volume (call, ringer, or - Switch down: Flashlight OFF radio) Emergency call button (S.O.S. button) Battery door release (Press and slide down) Keypad Lock Radio - Switch up: Lock OFF - Switch up: Radio ON - Switch down: Lock ON - Switch down: Radio OFF...
- Page 11 Home Screen Status Indicators FM Radio Home Screen...
-
Page 12: Sms Messages
SMS MESSAGES SMS (Short Message Service) or “Text Messages” are written messages with a maximum of 160 characters. • Write new SMS: Press UP 3 times to Messages again to select Create and then press , Press Message. Entering a Phonebook contact or creating an SMS message using the keypad. - Page 13 Use the to delete a character. Use the scroll button to edit within the screen. • After composing your message, send the message by pressing twice, enter the number or dial from the PhoneBook by pressing , scroll through names to select, press to view number, press to send.
- Page 14 RADIO ON: Switch on the left side upwards. OFF: Switch on the left side downwards Channel List Use the Auto Search below to auto fill your channel list. To select your station use to scroll through the stations available in your area and press to select.
- Page 15 When you switch your radio off and on again, you are on the last heard station again. Change volume: (does not function when in Auto Search) with + / - on the left side of the telephone. Headphones: You can use the radio with and without headphones.
- Page 16 Using the SOS Button Press and Hold for 5seconds to activate. (NOTE: The SOS Button is not activated by default on a new Snapfōn. To activate the SOS Button, Please follow Steps #7 and #8) Press and hold the orange SOS button, located on the back of the phone, for 5 seconds A siren will sound alerting the emergency.
- Page 17 Next the phone will begin dialing in stored sequence the Emergency Number(s). If the first call is not connected it will call the second number and so on... When the call is connected the Speakerphone is activated. Very Important: This phone does not know the difference between a person, an answering machine or a voicemail answering the phone.
-
Page 18: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS • What service providers will work with Snapfōn? This is a quad band GSM phone, that uses these frequencies GSM 850/900/1800/1900. You must use an unlocked SIM card from a service provider that operates with these frequencies. Snapfōn will not work with CDMA service providers. • Screen shows “No SIM card!“: Check the direction (Gold contact facing downwards) of the SIM card... - Page 19 SIM card with the new service. • What are the size of the keys on the Snapfon? The number keys are 5/8 inch square. • What do I do if my phone shows a missed call? Press...
-
Page 20: Warranty And Returns
The battery is guaranteed to be functioning at time of purchase only. The phone warranty is void if batteries other than Snapfon authorized or recommended batteries have been used. If a problem develops due to a third party battery, or charging adapter please contact the manufacturer of that accessory for redress or compensation. - Page 21 If we choose to refund your purchase it may be prorated based on use and condition of the returned merchandise. The shipping charges for returning a working phone to you are covered by the warranty. The product should be returned with all the accessories, with clear return shipping instructions that include your address, phone number, and a detailed description of the reason for the return.
-
Page 22: Safety Instructions
The entire product may not be altered or rebuilt, nor may the housing be opened. The power adapter is designed for use in household wall outlets with public electricity grids of 100-240 VAC - 50/60 Hz. REPLACEMENT PARTS www.snapfon.com (store) OR www.snapfon.com/catalog/index.php... - Page 23 Take care of the environment by bringing it to a collection area where old devices are accepted and brought into an environmentally friendly disposal/ recycling procedure. Snapfōn 100 Cherokee Blvd. Suite 216 Chattanooga, TN 37405 423-535-9968 www.snapfon.com customerservice@seniortechllc.com...
