Ducted Vacuum
Owner's Manual
User instruction manual and warranty information.
Please read this before installing or using your
Premier Clean Ducted Vacuum Unit.
For replacement bags
buy online at www.premierclean.com.au
or to find your local dealer
www.premierclean.com.au
For Warranty registration go to www.premierclean.com.au
1
Advertisement
Related Manuals for Premier Clean Ducted Vacuum
Summary of Contents for Premier Clean Ducted Vacuum
- Page 1 Ducted Vacuum Owner’s Manual User instruction manual and warranty information. Please read this before installing or using your Premier Clean Ducted Vacuum Unit. For replacement bags buy online at www.premierclean.com.au or to find your local dealer www.premierclean.com.au For Warranty registration go to www.premierclean.com.au...
- Page 2 For Replacement Bags Buy Online at www.premierclean.com.au For Accessories Buy Online at www.premierclean.com.au WARNING USE ONLY GENUINE PREMIER CLEAN SYNTHETIC FILTER BAGS. FAILURE TO DO SO WILL VOID YOUR WARRANTY. DO NOT VACUUM UP WATER, PLASTER DUST, BRICK OR CONCRETE DUST.
-
Page 3: Table Of Contents
Table of Contents Installation Changing Bag/Filter Operating Instructions Operation & Care Accessories Hose Sets 10-11 Trouble Shooting Warranty Information 12-13... -
Page 4: Unit Installation
Unit Installation Using the mounting plate provided with your vacuum cleaner, secure the unit to the wall (figure 1), at the height allowing easy access to change the bag. Please note Monarch/Compact units must be a minimum 300mm off the ground. (Do not store any particles underneath the vacuum) The connections to the piping system will... -
Page 5: Low Voltage Connections
Low Voltage Connections Connect the low voltage wires to the low voltage inlet on your unit. To do so, simply strip wire overs 1/2 cm, remove the terminals from the low voltage inlet on the unit, and proceed according to the types of inlet and wire used. -
Page 6: Changing Bag/Filter
Motor There is no maintenance to be performed on the actual motor of your ducted vacuum. The most important tips for a longer vacuum life are - to keep the inside of the unit (canister) itself clean - make sure you do not vacuum up any harmful dusts or ANY liquids. Should you require a service to your unit please contact the dealer who you purchased the unit from or call us on 1300 881 608 to find a dealer near you. -
Page 7: Operation & Care
ON position. When finished turn switch off and remove hose. TIPS TO CARE FOR YOUR DUCTED VACUUM SYSTEM – Your system’s unit is warranted against defective materials and workmanship but not against misuse. There is a service charge for repairing or replacing damaged or misused components of the system and for service calls. -
Page 8: Accessories
Accessories Standard Hose & Tool Set 2 Way Brush For use on carpets and vinyl/tiles. Not recommended for floorboards, slate etc Telescopic Wand Adjustable to the height you desire, simply push the button and extend to desired length. Dusting Brush Can be used just about anywhere. -
Page 9: Hose Sets
Accessories Switch on/off Hose & Tool Set also comes with Hard Floor Brush For use on any hard surfaces. Floor boards, vinyl, slate, bricks and rugs. Hose Hanger Ideal to hang your hose on. Switch Variable Hose Control your unit from where you stand. Turn the unit on or off or select from two suction levels. -
Page 10: Troubleshooting
Troubleshooting Problem Cause Action Decrease Dirt recipient / Empty dirt recipient / change bag in suction Bag is full strength Dirt recipient Check clamps and dirt recipient is aligned is not properly attached Filters need Remove, shake cleaning / replacing Motor guard Remove filters, and check the guard screen screen is (which separates the motor from the filtration blocked... - Page 11 If none of these suggestions help start your vacuum unit, contact your authorised service center. www.premierclean.com.au USE ONLY GENUINE PREMIER CLEAN SYNTHETIC FILTER BAGS. FAILURE TO DO SO WILL VOID YOUR WARRANTY. 1300 881 608...
-
Page 12: Warranty Information
A) Labour and Parts For a period of 90 days from the date of purchase the Premier Clean dealer or agent who installed the product shall remove and repair or replace the defective part free of charge, but any cost associated with travel outside the metropolitan area is not included and shall be paid by the purchaser. - Page 13 V of the Trade Practices Act 1974 or part IV of the Goods Act 1958 (Victoria). If assistance is required in understanding the terms and conditions of the warranty please contact Premier Clean or the dealer of where the product was purchased from.
- Page 14 Notes...
- Page 15 Purchase Receipt For your future reference Dealer Name Dealer Phone Number Address Date of Purchase Please Complete and Return by Post or visit us at www.premierclean.com.au and complete online Purchase Date Model Serial No. (this is found on the top left hand side of the vacuum unit) Dealer Name Store/Address Purchaser’s Name...
- Page 16 Head Office Premier Clean Queensland Warehouse Factory 4/1 Merri Concourse, Factory 1/13 Commerce Circuit, Campbellfield, Vic 3061 Yatala, Qld 4207 PH: 1300 881 608 PH: 07 3382 6978 WEB: www.premierclean.com.au WEB: www.premierclean.com.au E-MAIL: info@premierclean.com.au E-MAIL: info@premierclean.com.au Factory 4/1 Merri Concourse, Campbellfield, Vic 3061...
