Summary of Contents for Amconn KVM312IC
- Page 1 KVM312IC / KVM314IC 2/4 PORT PS/2 KVM Switch User Manual...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ................P1 Equipment Requirements ............P1 Features .................P2 Package Contents ..............P2 Specifications .................P3 Overview.................P4 Display Diagrams ..............P6 Installation ................P7 Pre-Configuration ..............P7 Hardware Installation ............P8 Operation ................P11 Powering Up the Systems ..........P11 Selecting Computers Using Front-panel Selectors ..P11 Selecting Computers Using keyboard Hot Key Commands P11... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing AMCONN’s ExsorVew PS/2 KVM Switch. The ME series allows users to control 2 (KVM312IC) and up to 4 (KVM314IC) PS/2 computers from a single PS/2 console (PS/2 keyboard, PS/2 mouse and monitor). The KVM312IC / KVM314IC is both compact and portable, its small desktop footprint is ideal for on or under your desktop. -
Page 5: Features
KV M 31 2/3 1 4 I C FEATURES Allows users to control 2 (KVM312IC) or up to 4 (KVM314IC) computers from single PS/2 console (PS/2 mouse, PS/2 keyboard and monitor) Easy switching via Hotkeys or manual port selectors Easy installation - no software to install Easy access - logically designed front panel keyboard &... -
Page 6: Specifications
SPECIFICATIONS Computer connections: Keyboard/Mouse/Monitor 2/4 sets: HDDB 15 pin Female Console Connections: Keyboard 1 set: PS/2 Mini Din 6 pin Female Mouse 1 set: PS/2 Mini Din 6 pin Female Monitor 1 set: HDDB15 pin Female Port LEDs Hot Keys Resolution 1920 x 1440 @75Hz Dimensions(W x D x H) -
Page 7: Overview
- one by one, that are connected to your KVM Switch. Superior Video Resolution With a 400MHz video bandwidth, the KVM312IC / KVM314IC can support video resolutions of up to 1920 x 1440 @75Hz. (To preserve signal integrity at high resolutions, a 75-Ohm coaxial... -
Page 8: Led Display
LED Display Port LEDs allow for easy status monitoring. A lit LED indicates which computer the KVM console currently has control of. The LED will light with the corresponding active port when switching between the computers. PS/2 Interface Support The Switch supports computers with PS/2 input devices (keyboard and mouse). -
Page 9: Display Diagrams
KVM 312 /3 14 I C DISPLAY DIAGRAMS Front View KVM312IC KVM314IC 1. Console PS/2 keyboard and PS/2 mouse ports 2. Direct access port selector/s Lights RED indicating that the connected computer has the • KVM focus (SELECTED). 3. LEDs... -
Page 10: Installation
INSTALLATION Where to Place the KVM Switch: The ExsorView KVM Switch is small, portable and designed to fit right on the desktop. Before installation consider the following when deciding where to place the KVM Switch; • whether or not you intend to use the manual port selectors for port switching •... -
Page 11: Hardware Installation
KVM 312 /3 14 I C HARDWARE INSTALLATION This section provides you complete instructions for the basic hardware setup of a single KVM312IC / KVM314IC. Important Note: Before you begin, make sure that the powers to the entire your computer you will be connecting up have been powered off. - Page 12 3. Connect the male VGA connector (HDDB-15 pin) from your monitor to the console VGA port on your on the back of the KVM Switch. Monitor Powering-Up the KVM Switch (Optional) 1. Connect the barrel of 9V, 600mA power adapter to the power jack on the rear of the Switch.
-
Page 13: Connecting The Computers
KVM 312 /3 14 I C Connecting the Computers 1. Using AMCONN’s all-in-one cable set (see Cables section), connect the PS/2 keyboard and PS/2 mouse from your first computer. 2. Connect the male VGA connector to the corresponding female VGA port on the back of the computer. Take the other male VGA cable end and connect it to the rear of the Switch designated as ”PC1”. -
Page 14: Operation
KVM312IC / KVM314IC is now ready for use. Controlling your computers with the KVM312IC / KVM314IC couldn ’t be easier. The KVM312IC / KVM314IC allows you to instantly access the computers using two methods of port selection: • Manual Port Selectors •... -
Page 15: Hot Key Commands
KVM 312 /3 14 I C ” For example, if you press [SCROLL LOCK], [SCROLL LOCK], “2 the computer on port 2 will be selected. Alternatively, you can switch the KVM focus to any computer via the simple keyboard command sequence using the SCROLL LOCK key and Up and Down arrow keys. -
Page 16: Autoscan Mode
2. A flashing port LED indicates that the connected computer is under Auto Scan mode. ©2003 AMCONN Labs. All rights reserved. The ExsorView series is a trade mark of AMCONN. All trade names are registered trademarks of their respective owners. -
Page 17: Fcc Certifications
KVM 312 /3 14 I C FCC CERTIFICATIONS This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 18: Vcci Warning
VCCI Warning LIMITED WARRANTY AMCONN provides this limited warranty for its product only to the person or entity who originally purchased the product from AMCONN or its authorized reseller or distributor. Limited Hardware Warranty: AMCONN warrants that the hardware portion of the AMCONN products... -
Page 19: What You Must Do For Warranty Service
The Warranty Period shall extend for an additional ninety (90) days after any repaired or replaced Hardware is delivered. If a material defect is incapable of correction, or if AMCONN determines in its sole discretion that it is not practical to repair or replace the defective Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by AMCONN upon return to AMCONN of the defective Hardware. -
Page 20: What Is Not Covered
Authorized AMCONN Service Office is provided in the back of this manual. ( Failure to properly complete and timely return the registration card may affect the warranty for this product.) Submitting A Claim. Any claim under this limited warranty must be submitted in writing before the end of the Warranty Period to an Authorized AMCONN Service Office. -
Page 21: Limitation Of Liability
KVM 312 /3 14 I C Limitation of Liability: To the maximum extent permitted by law, AMCONN is not liable under any contract, negligence, strict liability or other legal or equitable theory for any loss of use of the product, inconvenience or damages of any character,...
