Mono Machines SFX-6 User Manual page 101

GLOBAL SETTINGS
PAT+KIT - Only the patterns and their associated kits, as selected in the RANGE tab,
•
will be sent.
SONG+PAT+KITS - The songs specified in the RANGE tab, together with their associ-
•
ated patterns and kits, will be sent.
RANGE (range) is where the range for the KIT, PAT+KIT and SONG+PAT+KIT transfer
methods is set.
To perform a sysex send, follow the instructions below
Connect the Monomachine to the device you are sending the data to. See the figure
1.
below for an example of what the connections could look like when sending sysex data
to a computer.
USB CORD
Select FILE in the GLOBAL menu. Then select SYSEX SEND using the [ARROW] keys
2.
and press [ENTER/YES].
Select the preferred data send method using the [UP] and [DOWN] arrow keys.
3.
If the selected send method has the option to select a range or a specific number, you
4.
can now move the focus to the right. After that, you use [UP] and [DOWN] or the LEVEL
knob to select the lower and upper limit of the range. For pattern selection [BANK A-H]
together with [TRIG] buttons can also be used.
Make sure that the device you are sending the data to is ready and waiting.
5.
MIDI INTERFACE IN
MIDI OUT
93
