Casio 4392 Operation Manual

MO0705-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
• The measurement functions built into this watch are not intended for use in taking
measurements that require professional or industrial precision. Values produced
by this watch should be considered as reasonably accurate representations only.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss, or any
claims by third parties that may arise through the use of this watch.
General Guide
• Press C to change from mode to mode.
• In any mode (except when a setting screen is on the display), press B to illuminate
the display.
Timekeeping Mode
Timekeeping
Use the Timekeeping Mode to set and view the current time and date.
This watch features separate digital and analog timekeeping. The procedures for
setting the digital time and analog time are different.
• In the Timekeeping Mode, press A to toggle between the thermometer screen and
the temperature tendency screen.
Thermometer Screen
Day of week – Day
Hour : Minutes
PM
indicator
• See "Thermometer" for details about the thermometer screen and temperature
tendency graph.
Setting the Digital Time and Date
This watch is preset with UTC differential values that represent each time zone around
the globe. Before setting the digital time, be sure to first set the UTC differential for
your Home Site, which is the location where you normally will be using the watch.
• Note that World Time Mode times are all displayed based on the time and date
settings you configure in the Timekeeping Mode.
To set the digital time and date
Seconds
Seconds DST
Temperature
Unit
3. When the setting you want to change is flashing, use D and B to change it as
described below.
Screen: To do this:
Reset the seconds to 00
Toggle between Daylight Saving
Time (
ON
Specify the UTC differential
Change the hour or minutes
Toggle between 12-hour (
24-hour (
Change the year
Change the month or day
Operation Guide 4392
Warning!
Press C.
Hand Setting Mode
Temperature Tendency
Screen
Thermometer
Press A.
Seconds
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
• Be sure to configure the correct UTC differential for
your Home Site before configuring any other
Timekeeping Mode settings.
• See the "UTC Differential/City Code List" for
information about the UTC differential settings that are
supported.
2. Press C to move the flashing in the sequence shown
below to select other settings.
UTC
Hour Minutes
Differential
Temperature Sensor
Day Month
Calibration
Do this:
Press D.
Press D.
) and Standard Time ( )
OF
Use D (+) and B (–).
Use D (+) and B (–).
Press D.
12H ) and
24H ) timekeeping
Use D (+) and B (–).
About This Manual
Temperature Data
Recall Mode
World Time Mode
• The UTC differential setting range is –12.0 to +14.0, in 0.5-hour units.
• When DST is turned on, the UTC differential setting range is –11.0 to +15.0,
in 0.5-hour units.
• For information about settings other than the time and date, see the following.
Temperature Sensor Calibration: "Temperature Sensor Calibration"
Temperature Unit: "To specify the temperature display unit"
4. Press A to exit the setting screen.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
Temperature
tendency
applied in all modes.
graph
• The day of the week is displayed automatically in accordance with the date (year,
month, and day) settings.
• Any time the seconds setting is changed, the analog hands are adjusted accordingly.
• See "Daylight Saving Time (DST) Setting" below for details about the DST setting.
Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode digital time between DST and Standard Time
On/Off status
DST indicator
Setting the Analog Time
Perform the procedure below when the time indicated by the analog hands does not
match the time of the digital display.
To adjust the analog time
l
12/24-Hour
Format
Year
• To lock high speed hands movement, hold down D to start it and then press B
to lock. The hands will continue to advance for one 12-hour cycle or until you
press any button to stop it.
It will also stop automatically after the time advances 12 hours or if an alarm (daily
alarm, Hourly Time Signal, or countdown beeper) starts to sound.
4. Press A to exit the setting screen.
• The minute hand will be adjusted slightly to match the seconds when you exit the
setting screen.
• To return to the Timekeeping Mode, press C.
• Depending on the model of your watch, display text
appears either as dark figures on a light background or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
• Button operations are indicated using the letters shown
in the illustration.
• For the sake of simplicity, the sample displays in this
manual do not show the analog hands of the watch.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Stopwatch Mode
Countdown Timer
Alarm Mode
1.In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C once and the DST setting screen appears.
3. Press D to toggle between Daylight Saving Time (
displayed) and Standard Time ( OF displayed).
4. Press A to exit the setting screen.
• The DST indicator appears on the Timekeeping, Alarm,
and Hand Setting Mode screens to indicate that
Daylight Saving Time is turned on.
1. In the Timekeeping Mode, press C six times to enter
the Hand Setting Mode.
2. In the Hand Setting Mode, hold down A until the
current digital time starts to flash, which indicates the
setting screen.
3. Use D to adjust the analog setting.
• Press D once to advance the hands 20 seconds.
• Hold down D to advance the hands at high speed.
Mode
ON
