Viking Range Quiet Cool VCFB530 User Manual

Standard Features & Accessories
All models include
• Capacity—15.9 cu. ft. (450.0 L)
o 84"H./24"D.
• ProChill™ Temperature Management
System
o Variable-speed DC Overdrive™
Compressor is one of the quietest,
most technologically advanced
compressors available
o Electronic controls maintain the
temperature selection within 1ºF
o Multi-channel airflow system and
Odor Eliminator™ Evaporator
removes odors and excess humidity
• Six adjustable half-width wire shelves
• One full-width metal shelf
• Two full-width slide-out wire baskets
with tempered glass fronts
• Factory-installed automatic ice maker
Model Options
VCFB530/VIFB530
Professional/Professional Integrated
FINISH DETAILS FOR VCFB/VIFB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door front.
Stainless steel upper grille, side trim,
and handle (with chrome-plated
brackets); black lower kickplate.
• Brass Accent Option (BR)—nameplate
and handle endcaps. Brass components
have a durable protective coating for
maintenance-free normal use.
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference ("R" for right or "L" for left), and then color code (VCFB530RSS).
If ordering optional brass accent, specify code at end (VCFB530RSSBR).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Quiet Cool™ Built-In 30"W. All Freezer
• One full-width ice storage drawer with
two separate metal ice bins
• Full-extension precision ball-bearing
glides on all baskets and drawers
• Three patented adjustable aluminum
door bins with tempered glass fronts
• Adaptive defrost
• All-metal freezer interior
• Super Clog-Resistant™ Condenser is
maintenance-free under normal use
• Tru-Flush™ design
o Allows Professional Integrated and
Custom Panel models to fit flush into
24" deep installation cutout
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
DDFB530
Designer
FINISH DETAILS FOR DDFB MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door front.
Stainless steel upper grille, side trim,
and handle; black lower kickplate.
• 1 - 8 8 8 - V I K I N G 1
REFRIGERATION
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
• For installation of two units side-by-
side, a separate grille kit accessory
must be purchased
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and
handle on right side.)
DFFB530
Custom Panel
FINISH DETAILS FOR DFFB MODEL
• Handle not included—opt for custom
handle, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for more
information and additional
specifications.
© 2 0 1 1 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
R E V I S E D 5 / 2 / 1 1
