ML-7300 Series SERVICE Manual LASER PRINTER CONTENTS 1. Precautions 2. Reference Information 3. Product Information 4. Disassembly 5. Trouble Shooting 6. Exploded Views & Parts List 7. Electrical Parts List 8. Block Diagrams 9. PCB Diagrams 10. Port Thru (Network Printer Card) 11.
Page 2
PMO-HOLDER PAD MP PMO-BKT HOLDER MP PMO-ACTUATOR EMPTY PMO-SUB GUIDE MP PMO-GUIDE RING PMO-ACTUATOR PAPER RPR-PAD KNOCK UP MP RPR-RUBBER P/UP MP RPR-FRICTION PAD MP ELA HOU-BRKT DUPLEX SCREW-TAPTITE SCREW-TAPTITE RING-CS RING-E Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 3
SCREW-TAPTITE SCREW-TAPTITE RING-CS CABLE TIE CABLE TIE CABLE CLAMP SPRING-CLUTCH CBF-HARNESS-LSU(18P) CBF HARNESS-DUPLEX GND CBF HARNESS-BRUSH GND CBF HARNESS-JOINT+ENGINE CBF HARNESS-EMI WIRE CBF HARNESS-CASSETTE CBF HARNESS-SCF1 CBF HARNESS-VIDEO CBF HARNESS-SMPS Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 4
IPR-INSULATOR PANEL PMO-HOUSING PANEL U PMO-HOUSING-PANEL.L PMO-KEY-SEESAW PMO-WINDOW PANEL PMO-KEY ONLINE PMO-LCD LOCKER PBA SUB DISP-PANEL PBA SUB DISP-LCD PBA SUB DISP-PNL&LCD MEA UNIT-COVER FRONT SPRING-CS PMO-COVER-FRONT PMO-BUTTON-POWER MEA UNIT-COVER LEFT Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 5
MEA RACK-COV FU LOW SPRING-SAPERATION SPRING-FUSER EXIT BEARING-EXIT FU L BEARING-EXIT FU GEAR-EXIT LABEL(P)-CLEAN FELT PMO-GUIDE CLAW PMO-COVER FUSER LOW ROLLER-EXIT RCT-ROLLER EXIT FU MEA RACK-BRK GEAR FU RING-CS “GEAR-EXIT/U,ID” “GEAR-EXIT,IDLE(Z17)” PCT-SHEET H/R Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 6
LABEL(R)-TR CHANGE LABEL(R)-RATING LABEL(R)-S/N(STA) MEC-BARCODE PAA WOOD-PACKING ASS’Y TAPE-OPP MASKING TAPE-FILAMENT “CUSHION—CUSHION SET,N” CUSHION—SPACER BAG-PE SET CUSHION-DEV KME CUSHION-DEV CUSHION-CST INA-ACCESSORY(XAR) S/W APPLICATION-DRIVER CD MAN(BOOK)-7000N3/XAR MAN(BOOK)-USER MANUAL LABEL(R)-CUSTOMER “MAN(CARD)-WARR, STA” Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 7
Contents 1. Precautions 1-1 Safety precautions ______________________________1-1 1-2 Laser Safety Statement __________________________1-2 2-1 Abbreviations and Acronyms _____________________2-1 2. Reference Information 2-2. Diagnostic Control Unit_________________________2-3 2-2-1. Abstract ________________________________2-4 2-2-2. List of code description_____________________2-5 3.Product Information 3-1 General Specifications ________________________3-1 3-2 Controller Specifications _______________________3-2 3-3 Electrical Specifications _______________________3-2 3-4 Environmental Condition _______________________3-3 3-5 Image Cartridge(Developer) ____________________3-3...
Page 10
10-1. Introduction The purpose of the Network Printer Card(PortThru) is to enable the Samsung Printer to function as a network printer. The PortThru is a plug-in card that plugs into the Samsung Printer. The PortThru provides a Ethernet Local Area Network interface through which the printer can be connected to the network.
Page 11
Product Information 10-2. Board Description 10-2-1 Configuration of Network Board Service Part : JC92-01119A 10-2 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Go to Network Error Is it possible detecting Go to PHY chip Error using syncThru from PC ? Is it possible printing Go to Shared Memory Interface Error through network ? 10-4 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 14
+5V and GND in the voltage = +5V ? Network board? Go to System Error or Network Error Go to System Error or Network Error Replace the board Section Section Samsung Electronics 10-5 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 15
Check the TMODE(pin no. 63, 64) input level : Low Check the soldering status Check the EXTMREQ(pin no. 108) input level : Low If you can't repair the board Replace the board 10-6 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Clock = 25MHz ? Check the R79, R80, R112 and CN5 Check the soldering status Check the LED1 and R106 If you can't repair the board Replace the board Samsung Electronics 10-7 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 17
= 2.5MHz or 25MHz ? check the soldering status of U165 Check the RA1, RA10, R138, R144 and R145 Check the LAN Cable If you can't repair the board Replace the board 10-8 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 18
= Low ? Check the R68, R69, R70, R72, R73, R92, R127 and R128 Check the J1 connector and DRAM(U18) If you can't repair the board Replace the board Samsung Electronics 10-9 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 19
Printer card but Printer Check the Shared Memory Cotrol signals. Refer to the Shared Memory Interface does not U22-37, 38, 39 and R68, R69 and R70 Error Section. printing. 10-10 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 20
Schematic Diagrams 11. Schematic Diagrams 11-1 Main Circuit Diagram(1/12) EDIT SIGN REF NO Samsung Electronics 11-1...
Page 21
Schematic Diagrams Main Circuit Diagram(2/12) EDIT SIGN REF NO 11-2 Samsung Electronics...
Page 22
Schematic Diagrams Main Circuit Diagram(3/12) EDIT SIGN REF NO Samsung Electronics 11-3...
Page 23
Schematic Diagrams Main Circuit Diagram(4/12) EDIT SIGN REF NO 11-4 Samsung Electronics...
Page 24
Schematic Diagrams Main Circuit Diagram(5/12) EDIT SIGN REF NO Samsung Electronics 11-5...
Page 25
Schematic Diagrams Main Circuit Diagram(6/12) EDIT SIGN REF NO 11-6 Samsung Electronics...
Page 26
Schematic Diagrams Main Circuit Diagram(7/12) EDIT SIGN REF NO Samsung Electronics 11-7...
Page 27
Schematic Diagrams Main Circuit Diagram(8/12) EDIT SIGN REF NO 11-8 Samsung Electronics...
Page 28
Schematic Diagrams Main Circuit Diagram(9/12) ED EDIT SIGN REF NO Samsung Electronics 11-9...
Page 29
Schematic Diagrams Main Circuit Diagram(10/12) EDIT SIGN REF NO 11-10 Samsung Electronics...
Page 30
Schematic Diagrams Main Circuit Diagram(11/12) EDIT SIGN REF NO Samsung Electronics 11-11...
Page 31
Schematic Diagrams Main Circuit Diagram(12/12) EDIT SIGN REF NO 11-12 Samsung Electronics...
Exploded Views & Parts List 6-1 Main Ass’y Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 70
MEA-RACK FEEDER CST JC97-01023C MEA RACK-PICK UP JC97-01039A PMO-FRAME BASE PMO-COVER-RIGHT JC72-40941E MEA RACK-COVER REAR JC97-01026B 220V ELA HOU-FUSER ASS’Y JC96-02033A 110V ELA HOU-FUSER ASS’Y JC96-02034A MEA RACK-CAST SCF MEA RACK-SCF AS’Y Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 71
Exploded Views & Parts List 6-2 Cover Ass’y 1-1-1 1-1-1-7 1-1-1-1 1-1-1-3 1-1-1-6 1-1-1-2 1-1-1-5 1-2-7 1-1-1-4 1-2-6 1-2-5 1-2-1 1-2-4 1-1-3 1-2-3 1-2-2 1-1-4 1-2-8 1-2-9 1-1-2 1-2-10 1-2-11 1-2-6 2-10 2-11 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 72
MEA RACK-COVER LEFT JC97-01025B PMO-COVER LEFT PMO-AIRDUCT PMO-COVER RIGHT JC72-40941E MEA RACK-COVER FRONT JC97-01024B PMO-COVER FRONT PMO-LINK TRAY JC72-40957D PMO-BOTTOM POWER SPRING-CS PMO-STRIPE JC72-41004A SCREW-TAPTITE SCREW-TAPTITE SCREW-TAPTITE SCREW-TAPTITE SCREW-TAPTITE SCREW-TAPTITE Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 73
Exploded Views & Parts List Cover Ass’y Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 74
Location NO. Description SEC.Code Q’ty Remark MEA RACK-TRAY MP JC97-01038B PMO-TRAY-MP PMO-SIDE GUIDE TRAY ICT-SHEET SIDE GUIDE MEA UNIT-COVER TRAY JC97-01037B PMO-SUBTRAY-FIRST PMO-SUBTRAY-SECOND PMO-COVER TRAY PMO-LINK TRAY JC72-40957D PMO-COVER COLOR Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-4. Cassette Ass’y 6-12 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 80
IPR-PLATE KNOCK UP IPR-PLATE SPR LOCK IPR-PLATE SUB K/UP IPR-SPR PLATE G/SIDE SPRING-LEVER SPRING-PLATE K/UP SPRING-SUB PLATE RPR-PAD CST ICT-SHAFT SPR K/UP LABEL(R)-INSTRUCTION SPRING-LOCKER,PLATE PMO-LOCKER PLATE RING-E SCREW-MACHINE SCREW-TAPTITE SCREW-TAPTITE Samsung Electronics 6-13 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-5. MP Tray Ass’y 9 10 6-14 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 82
PMO-HOLDER PAD MP RPR-FRICTION PAD MP SPRING-F/P MP PMO-SUB GUIDE MP PMO-ACTUATOR EMPTY PMO-GUIDE RING IPR-K/UP PLATE MP RPR-PAD KNOCK UP MP PMO-BUSHING K/UP MP SPRING-KNOCK UP MP RING-E SCREW-TAPTITE SCREW-TAPTITE Samsung Electronics 6-15 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-6. Pick Up Ass’y 6-16 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 84
IPR-SHAFT FEED IDLER PMO-ROLLER FEED L PMO-ROLLER FEED S SPRING-FEED SMALL PMO-HOLDER FEED L ICT-SHAFT IDLE LARGE SPRING-FEED LARGE GEAR-P/UP DRIVE WASHER-PLAIN RING-CS ICT-SUB SHAFT P/UP IPR GROUND FEED SCREW-TAPTITE Samsung Electronics 6-17 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 85
Exploded Views & Parts List 6-7 Fuser Ass’y 6-18 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-9. Bracket Duplex Ass’y 6-22 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 90
BELT-TIMMING IPR-BRKT DUPLEX IPR-LINK DUPLEX ICT-SHAFT SWING PMO-BEARING LARGE DP “PMO-BEARING SMALL,DP” ICT-SHAFT BELT “GEAR-DP,IDLE” GEAR-DUPLEX “GEAR-EXIT/U,ID” PMO-BRKT GEAR LOWER SPRING-SOLENOID DP SOLENOID-DUPLEX ICT-SHAFT BELT2 RING-CS RING-E SCREW-TAPTITE SCREW-TAPTITE Samsung Electronics 6-23 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-10. Bracket Motor Ass’y 6-24 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 92
GEAR-IDLE 27 GEAR-FUSER DRIVE GEAR-RDCN OPC GEAR-118/23 GEAR-IDLE FU GEAR-FEED DRIVE GEAR-OPC DRV(12) GEAR-OPC DRV2 IPR-BRACKET(MOTOR 21) IPR-BRACKET MOTOR J MOTOR-STEP 3101-001226 CBF HARNESS MOTOR RING-E WASHER-PLAIN SCREW-MACHINE SCREW-MACHINE Samsung Electronics 6-25 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List 6-11. Frame SCF Ass’y 6-26 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Exploded Views & Parts List Exploded Views 6-12. Cassette SCF Ass’y Samsung Electronics 6-29 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 97
SPRING-SUB PLATE ICT-SHAFT SPR K/UP PMO-LEVER PAPER S PMO-SUB GUIDE CAST PMO-WINDOW PAPER 1001 SCREW-MACHINE 1007 SCREW-TAPTITE 1007 SCREW-TAPTITE 1007 SCREW-TAPTITE 1013 SCREW-TAPTITE 1022 RING-E 950-1 MEA-RACK FRAME PAD 6-30 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
If not improved, replace image cartridge. Partial White Image 1. OPC Drum scar or particle 1. Clean OPC Drum (not periodic) 2. Check the cartridge life 2. Replace image cartridge Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 99
1. Refer to HVPS output spec All Black Image 2. Check the terminal contact - Replace the engine board 3. Compare new video board with 2. Replace terminal present one 3. Replace video board Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
7. Select the Diagnostic mode and measure HVPS output. *Recommanded Test Equipment - DVM -High Voltage Probe CHARGER TRANSFER Transfer Roller BIAS P T L (LED-Array) SUPPLY INSERT IMAGE CARTRIDGE Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 101
1. Cover open unit defect -Refer to “4-6” Cover open 2. Cable damage and connection 2. Replace cover open switch 3. Engine board defect assembly, and connect properly. 3. Replace the engine board. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 102
1. Connect the cable correctly or Video controller. replace the cable. Internal Error 20 (Engine board CN10 Video controller - Refer to “4-4” (Engine Error) board J11.) 2. Replace Engine board. 2. Engine board defect. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 103
2. Check the Feed Sensor actuator 2. Replace Feed Sensor actuator. on feed sensor” 3. Check the paper installation in - Refer to “4-11, 6-2” cassette. 3. Reinstall paper properly. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 104
1. Replace the paper empty sensor on - Refer to DCU mode “07” S.C.F board. 2. Check the paper empty sensing actuator 2. Replace MP paper empty sensor for SCF. actuator. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Correct the setting status of printer on test page? Is it possible receving data Go to Parallel Interface Error from PC? Go to Pinting Error Input Data Printing? 5-12 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 110
5V and GND in input voltage=5V? the Video board? Refer to the No Power Replace the LCD Ass’y Repair the board sectino of engine board of display panel troubleshooting Samsung Electronics 5-13 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 111
U27 : active low Check the ADS*(pin No.66) input pulse of U10 : active low If you can’t repair the board Replace the board 5-14 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
LSYNC*(pin No.95) of U23 Check the input pulse of the VCLK* (pin No.100) and PSYNC*(pin No.102) and LSYNC*(No.103pin) of SPGP1(U27) If yoy can’t repair the board Replace the board Samsung Electronics 5-15 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 113
If you can’t repair the board. Replace the board Printing Error Printing Error Check the soldering status of DRAM (U18, U24) Check. the soldering status of SPGP1 (U27) Go to system error 5-16 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 114
*Please refer to the user’s manual. General desc- *If you can’t fix the trouble of video controller riptions of Replace the board troubleshooting board, replace the video board by the verified board. Samsung Electronics 5-17 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 115
Troubleshooting MEMO 5-18 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 116
Disassembly 4. Disassembly 4-1 Front View Control Panel Cover Open Power Switch Cover Tray Cover Front Paper Level Indicator 4-2 Rear View Cover Rear Controller Cassette Power Inlet Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 117
Please see the hook which locks the cabinet to the frame, right hand should first grab the hook and pull it out for releasing the hook from the frame. Hook Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 118
Disassembly The left hand should slide the Cover Right to the backward. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 119
Left. Pull the Hook and release it from the frame. Screw Hook Slide the Cover Left to the backward with pulling the hook out. The Cover Left can be easily removed. Pull Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 120
Open the Cover Open. Remove two screws. Cover Top Screw Screw Cover Main See the hooks. Push the hooks up and pull them upward. With holding Cover Main, remove the panel wire. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 121
Detach the stripe by pushing the stripe. There is a hook holding the stripe. Stripe Cover Rear After detaching the stripe from the Cover Rear, Release the Cover Rear from the hinge. Hinge Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 122
Unplug the panel cable and engine I/F cable with care and remove the screws from the frame. Panel Cable RAM Simm Socket Controller Board Engine I/F cable Flash SIMM or Frame ICU Postscript SiMM Socket Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 123
You can see the Frame ICU. Parallel I/F Reserved for Network Ground ICU Reserved for Serial Screw Connector for Network Hyper chip ASIC (SPGP1) Video Controller Board Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 124
Open the Cover Rear and see the screws and unscrew and remove the Cover pcb. Cover PCB for engine B’d Screw After removing the Cover pcb, unplug the Thermistor connector from the Engine Board. Thermistor connector Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 125
“Fuser ass’y” for goods => Do use the exclusive “Fuser ass’y” in the ML-7300 model (ML-7300 model is different from ML-7000 & ML-7050) 4-10 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 126
Guide Rear out like figure. In order to remove Guide Rear, opening the Guide Rear out like figure and pull out hinge of Guide Rear. Guide Rear Samsung Electronics 4-11 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 127
Bracket Motor Ass’y You can see the Bracket Motor ass’y. Motor and several gears are assembled in one gear bracket. Motor < Bracket Motor Ass’y > 4-12 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 128
Refer to SMPS & Bracket Duplex Ass’y disassembly (4-12) Detach two Connectors form the SMPS. Remove 2 screws and detach the unit from the frame. Cover Open Switch unit Samsung Electronics 4-13 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 129
Remove the screw of Bracket Support and tension spring. Pickup Ass’y Tension Spring Screw Lift Guide Front Duplex and remove the 3 mounting screws of Pickup Ass’y. Guide Front Duplex Screws 4-14 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 130
In order for LSU disassembling, disassemble the Cover Main, you should take off the left and right cover. There is wiring protection cover(Cap Wire LSU)for LSU wires. Remove Cap wire LSU. Samsung Electronics 4-15 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 131
LSU lens. => If not , no image is occurred , because laser beam does not transmit the slim film. 4-16 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 132
See the Links which hold the MP tray in the both side. Hold the Links and pull it to the arrow direction. Hold the MP tray and pull it to the arrow direction. Samsung Electronics 4-17 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 133
Disassembly Screw Hook Cover Front After detaching the Tray MP, see the screws and remove them. Remove the hook and release the Cover Front by releasing the hook. 4-18 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 134
After removing Cover Front, detach the MP ass’y by unscrewing 4 screws. Before detaching MP Ass’y, unplug the MP solenoid and MP sensor connector from the Joint Board. < MP Ass'y > Samsung Electronics 4-19 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 135
Cover Top. Control panel consists of LCD ass’y and Key&LED ass’y. Remove Key&LED ass’y and remove LCD ass’y. 4-20 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 136
After removing Key&LED ass’y, release the hook of LCD ass'y from Cover Top and see the hinge for LCD ass’y in the cabinet and release them. You should spread the hinge of LCD ass’y. But be careful not to damage the hinge. Samsung Electronics 4-21 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 137
Open the Cover Rear and remove the Cover PCB. Screw wires After removing Cover Rear, disconnect all wires from the PCU. and then remove the screw of Ground Shield SMPS, Turn over the printer. 4-22 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 138
After turning over, remove Bar cross Bottom by unscrewing them 8 screws. Next remove the CST Sensor and remove the screws in the PCU which are black colored screws. Samsung Electronics 4-23 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 139
‘Video I/F’s’. Unplug them with care. Be careful not to be hurt to your hands when you disconnect the wires because the connection is tight and you may pull the connectors strongly. Screw 4-24 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 140
Above is to show the disassembled PCU and Frame. PCU Ass'y has some sensor, some actuator, solenoid and Shield plate and HVPS circuit. Service man could ask the Ass'y or repair parts. Samsung Electronics 4-25 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 141
Remove four screws and separate SMPS from the frame. You can see the fuser AC connector and +5V, +24V connector which are connected to the microswitches. Detach the wires from the SMPS. Samsung Electronics 4-26 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 142
The Bracket Duplex Ass’y is located in the left upper side. Remove the screws and detach the ass’y from the Frame. In order to remove the connector of Solenoid, first remove Engine Controller Board. Refer to Engine Controller Board disassembly (4-11) Samsung Electronics 4-27 Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 143
Open the Cover Top, you can see colored levers at each side of Transfer Roller, push the levers which is attached in the Holder transfer Roller to release the Ass’y. 4-28 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
•Printing : Less than 50 dB Acoustic Noise •Sleep mode : Background Noise •110V : UL, CSA,FDA,FCC Part15 Certification & •220V : TUV,CE Compliance •Enable Power save mode •Enable Toner save mode Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Input voltage range 90-132 VAC 189-264 VAC Nominal frequency 50/60 MHz 50/60 MHz Frequency tolerance +3Hz +3Hz •340W Avg or less Power •Sleep mode Consumption : 30W Avg or less Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
INTA interrupt Acknowledge sync synchronous or synchronization Interrupt tach tachometer INTR Interrupt request collector supply voltage(dc) Input and Output vert vertical multiplex Vp-p peak-to-peak voltage variable resistor Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 149
Voltage Controlled Oscillator Super Twisted Nematic VESA Video Electronics Standard Association Serial Communications Video Graphics Array Controller Thin Film Transistor Very High Frequency Tri-State Crystal Oscillator TSOP Thin Small Outline Package Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
MANUAL PRINT MODE LSU NOT READY DCU MODE DOWN SHIFT STOP ENTER IF YOU ENTER THE DCU MODE TURNTHEPOWER SWITCH ON WITH HOLDING THREEKEYS DOWN < Fig 1-1. ML-80 DCU > Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 151
FAN SPEED TEST SLEEP MODE PTL TEST NO PAPER or CASSETTE PAPER JAM “0” PAPER JAM “1” PAPER JAM “2” DUPLEX JAM “1” DUPLEX JAM “2” OUT BIN FULL LSU NOT READY Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 152
Lighten 3rd LED LSU Ready and LD On Lighten 1, 2nd LED SHIFT+STOP LSU Motor OFF Increment DCU Code No. (06, Pickup Clutch) SHIFT+DOWN Decrement DCU code No. (04, Dev) Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 153
Bright Light 2nd LED ON/OFF SHIFT + STOP Light OFF 3nd LED ON/OFF Increment DCU Code No. (00, Main Motor) SHIFT + DOWN Decrement DCU Code No. (16, Fan Speed TEST) Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
11. Do not touch the surface of the photo-sensitive drum as marks ro scratches may impair print quality. 12. Do not expose the drum unit to direct light for prolonged periods. 13. Use only standard papers, OHP films and approved envelopes. Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
LASER SÄTELYLLE ÄLÄ KATSO SÄTEESEEN. LSU caution label is located on the LSU top side CLASS 1 LASER PRODUCT LASER KLASSE 1 LUOKAN 1 LASERLAITE APPAREIL A LASER DE CLASSE 1 TO IEC 825 Samsung Electronics Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
Page 156
ELECTRONICS Samsung Electronics Co., Ltd. September. 2001 Printed in Korea VERSION NO. : 1.02 P/N. JC-0024A Download Service Manual And Resetter Printer at http://printer1.blogspot.com...
