  • Page 2 ML C 9 CP M ODEL:C CHASSIS: SS1 Model No: CT-14AZ9A ersion 1.0...

  • Page 3: Table Of Contents

    CONTENTS Specifications ............…………………………. 4 X-Ray Radiation Precaution …………………………………………………… 5 Safety Precaution ………………………………………………………………. 5 Product Safety Notice …………………………………………………………. 5 Alignment Instructions ………………………………………………………….. 6 Schematic Diagram …………………………………………………………….. 11 Model No: CT-14AZ9A Version 1.0...

  • Page 4: Specifications

    : 14” = 450(W) x 410(D) x 378(H) mm Net Weight : 14” ( 10 kg) REMOTE CONTROL Transmitting System : Infra-red Power Supply : DC 3V (1.5Vx2) Design and specifications are subject to change without prior notice Model No: CT-14AZ9CP Version 1.0...

  • Page 5: X-Ray Radiation Precaution

    Before replacing any of these components, read the part list in this manual carefully. The use of substitute replacement parts, which do not have the same safety characteristics, as specified in the part list may create shock, fire, and X-Ray Radiation or other hazards. Model No: CT-14AZ9CP Version 1.0...

  • Page 6: Alignment Instruction

    Channel -24 Half Colour Bar pattern PAL BG Modulation Channel -56 Full Colour Bar pattern NTSC Modulation Set-up Alignment:- 38 Mhz IF Digital Multi- Scope 20Mhz Signal Gen meter Tuner C137 + C561+ T101 LA76810A-IC Model No: CT-14AZ9CP Version 1.0...
  • Page 7 10.7 Use remote Control Unit for all types of function check and ensure OK. 10.8 Check the words display condition. 10.9 Shock test and make sure the picture and sound are not distorted and shifted. Model No: CT-14AZ9CP Version 1.0...
  • Page 8 “factory” key to leave factory mode function. Use “factory mode” for TV ageing, 2 step is to align the White Balance in good condition. 3 step adjust the required electrical specification. (The function adjustment are 20 selection) Others function Model No: CT-14AZ9CP Version 1.0...
  • Page 9 Colour 0 - 63 SUB. SHARP Sharpness 0 - 31 SUB.TNT TINT Colour 0 - 63 OSD.CONT OSD Contrast 0 - 127 OSD. H.POSI OSD left/right 0 - 127 OSD.V.POSI OSD up/down 0 - 31 Model No: CT-14AZ9CP Version 1.0...
