XVision XP101VD User Manual

Xvision xp101vd nvs user's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XP101VD User's Manual
V1.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP101VD and is the answer not in the manual?

Questions and answers

Related Manuals for XVision XP101VD

Summary of Contents for XVision XP101VD

  • Page 1 XP101VD User’s Manual V1.1.0...

  • Page 2: Table Of Contents

    Table of Contents OVERVIEW ....................1 General Introduction........................1 Specification ..........................1 Feature............................2 FRONT PANEL/REAL PANEL/INSTALLATION ........5 Check Unpacked NVS ......................5 Front panel ..........................5 Rear Panel..........................6 2.3.1 NVS0404DH ........................6 2.3.2 NVS0104DH ........................7 Connection ..........................7 2.4.1 General Connection ......................7 2.4.2 Audio/Video Connection ....................8 2.4.3 Audio Talk Input Connection.....................8 2.4.4 Video Output Device and Connection ................8...
  • Page 3 3.2.2 Login ...........................10 Main Window..........................12 3.3.1 Decode Channel Information ..................14 3.3.2 Decode Channel Setup....................14 3.3.3 Add /Remove Front-end Device ..................15 3.3.4 File Playback and Time Playback ..................15 Decoder Configuration......................17 3.4.1 Tour Config ........................17 3.4.2 Decode Output ........................18 3.4.3 Video Output........................19 3.4.4 TV Adjust..........................20 3.4.5...
  • Page 4 4.3.1 Contact parameters ......................36 5. NETWORK KEYBOARD CONTROL DECODE EXPLANATION ....37 5.1 Connection .............................37 5.1.1 Keyboard setup after serial ports connected ..............37 5.1.2 Keyboard setup after network connected................37 5.2 Login method ..........................38 5.3 Picture switch..........................38 APPENDIX TOXIC OR HAZARDOUS MATERIALS OR ELEMENTS ...39...
  • Page 5 Welcome Thank you for purchasing our product! This user’s manual is designed to be a reference tool for the operation of your system. Here you can find information about this series NVS’s features and functions. Before installation and operation please read the following safeguards and warnings carefully!
  • Page 6 4. About Accessories Be sure to use all the accessories recommended by manufacturer. Contact your local retailer ASAP if something is damaged in the accessory package. This user’s manual applies to the XP101VD audio and video decode device (version 1.x.0) only.

  • Page 7: Overview

    1 Overview 1.1 General Introduction XP101VD series product is a network audio & video decode device designed and developed for the video network monitor system. It has elegant shape and strong data process capability. It has stable and sound network function and supports all popular encode modes.

  • Page 8: Feature

    The first TV supports 1/4/9/16 window split; the second/third/fourth TV supports 1/4/ window split Window Split NVS0104DH supports 1/4/9/16 window split XP101VD has four out put interface sets NVS0104DH has one output interface set. Output ( VGA，HDMI，TV are contained in each set)
  • Page 9 The key board can control the device via RS232 port. Transparent Transparent COM function/ Decode XP101VD max. supports 28 D1 decode output(2M Capability code-stream), there are 14 720P decode output (4M, the main cor for 8 channels, the minor cores for 2 channels each) and 7 1080...
  • Page 10 Language Option English Set proper DST time according to different regions’ setup. Auto maintenance Auto maintain device regularly. Domain service Upgrade Support various upgrade types such as U disk, network, and TFTP. Intelligent Operation Support copy function for the same setup. Provide decode device SDK.

  • Page 11: Front Panel/Real Panel/Installation

    (offline, IP conflict and etc.) When device is in TV working mode, indication For XP101VD, all the indication lights are effective light The other front panel is shown as in Figure 2-2.

  • Page 12: Rear Panel

    IR receiver When device is in TV working mode. indication For XP101VD, only the channel 1 to channel 4 indication lights are light effective The rest channels 5 to channel 16 indication lights are null right now. 2.3 Rear Panel 2.3.1 XP101VD...

  • Page 13: Nvs0104Dh

    Port Name Port Name Port Name Ground screw hole Audio output Video output port (BNC) port(BNC) Audio talk output Audio talk input VGA port port port HDMI port RS232 port Power plug port Network interface(10M/100M/1000Mself-adaptive Power switch Ethernet port) Relay input, relay output, duplex RS485 port 2.4 Connection 2.4.1 General Connection Please refer to the following figure for connection information.

  • Page 14: Audio/Video Connection

    It adopts BNC port. 2.4.4 Video Output Device and Connection XP101VD adopts four output sets. VG A, HDMI and BNC a set; BNC(1.0VP-P ，75Ω). Here we recommend the industry monitor to be the output device of the decoder. It has the following advantages: The industry monitor is suitable for long time surveillance.
  • Page 15 Use pick-up with better directing property. Reduce the volume of the sound box until there is no squeaking. Using more sound-absorbing materials in decoration to reduce voice echo and improve acoustics environment. Adjust the layout to reduce risk of the squeaking.

  • Page 16: Operation

    3 Operation 3.1 Boot Up and Shut Down Boot up Connect the NVS to the power and then press the power button in the front panel. You can see the power indication light becomes on and NVS boots up. The system is in multiple-window display mode by default. Shut down You can press power button in the front panel for three seconds to shut down the device.
  • Page 17 For example, if your NVS IP address is 192.168.1.100, then please input http:// 192.168.1.100 in IE address column. See Figure 3-1. Input IP address here. Figure 3-1 System pops up warning information to ask you whether install webrec.cab control or not. Please click yes button.

  • Page 18: Main Window

    There are eight sections: Section 1: Decode channel There are 28 decode channels in XP101VD. There are four TVs corresponding to four output sets. Click four icons on the upper left to choose. There are 16 channels in the first TV, please see Figure3-4. There are four channels in the second/third/fourth TV respectively, please see Figure3-5.
  • Page 19 There are four display modes, namely, single-split, 1/4/9/16 window split. Take the first TV for an example: there are 16 options for single-split: channel 1, Channel 2……channels 16; 4 options for four-window split: 1-4ch, 5-8 ch, 9-12 ch, 13-16 ch; 2 options for nine-window split: 1-9ch, 8-16ch;...

  • Page 20: Decode Channel Information

    Figure 3-5 3.3.1 Decode Channel Information Single click and choose any decode channel to connect real-time decode output. Please see figure 3-6 : 1. Front-end device IP address. 2. Front-end real-time monitor channel. 3. The real-monitor channel connection status between the decoder and the front-end. 4.

  • Page 21: Add /Remove Front-End Device

    Please select the output TV and position and then select the device channel in the device list. Double click channel name or drag the channel name to the destination position and then release, you can see system pops up a dialogue box to inform that your setup is valid.
  • Page 22 Figure 3-9 Please select record playback mode, and then select start time, end time and channel. Then please click search button, you can see the corresponding files in the list. Select the file first and then click playback button, you can view the video. The decode channel is shown as in figure3-10.

  • Page 23: Decoder Configuration

    When device is play backing in the decode channel, you can view the related information in current Web. Once you exit the Web and then log in again, or you log in the Web in another PC, you can not view that current decode channel is playback right now.

  • Page 24: Decode Output

    Set decoder output channels and tour channels: any output TV can tour at any channel of this device and execute 1/4/9 window tour. TV output: You can select decoder output TV. XP101VD is 1-4 Windows selection: Here you can select single-split, 1/4 or 1/9 window output mode.

  • Page 25: Video Output

    FPS: You can view the frame rate. Data Flow: You can view the network data flow current channel received. Decode flow: You can view the output video flow current channel decoded. Figure 3-14 3.4.3 Video Output The video output interface is shown as below. See Figure 3-15 Set the resolution of decoder, which is the resolution of the output TV.

  • Page 26: Tv Adjust

    3-17 The decode tour interface is shown as below. See Figure Parameters Video: Here you can select the decode channel. For XP101VD, the value ranges from 1 to 28. IP: The front-end device IP address. Port: The front device port value.

  • Page 27: Decode Strategy

    Modify: Double click an item in the list you can modify the device information. Click modify button to save current modification. Please note current information has not been saved in the device. Delete all: Click it to remove all device information in the list. It is to clear all decode tour setups.

  • Page 28: Configuration

    Channel number Channel 1-28 are available decoding buffer time Selectable range: 80~480 Figure 3-18 3.5 Configuration 3.5.1 System Information Version Information Here you can view device hardware feature and software version information. See Figure 3-19.

  • Page 29: System Configuration

    Figure 3-19 Here you can view system log. See Figure 3-20. Figure 3-20 Click backup button, the interface is shown as in Figure 3-21. Figure 3-21 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, alarm Type event, user management, log clear.
  • Page 30 Please click save button to save your current setup. General Setup Here you can set system time, DST, video format and etc. See Figure 3-22. Figure 3-22 Figure 3-23 Please refer to the following sheet for detailed information. Parameter Function Here is for you to modify system time.
  • Page 31 Video You can select video format such as PAL. You need to reboot the Standard device to activate current setup. Local Default number 8 Number RS232 The RS232 interface is shown as in Figure 3-24. Figure 3-24 Please refer to the following sheet for detailed information. Parameter Function RS232 COM...
  • Page 32 Network Network interface is shown as in Figure 3-25. Figure 3-25 Please refer to the following sheet for detailed information. Parameter Function Ethernet Please select the network card first. IP Address The IP address of this device, user can set the IP address according to his actual requirements.
  • Page 33 Figure 3-26 Please refer to the following sheet for time zone information. City /Region Name Time Zone London GMT+0 Berlin GMT+1 Cairo GMT+2 Moscow GMT+3 New Deli GMT+5 Bangkok GMT+7 Beijing (Hong Kong) GMT+8 Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T)
  • Page 34 Figure 3-27 Figure 3-28...
  • Page 35 Figure 3-29 Please refer to the following sheet for detailed information. Parameter Function Event It includes local alarm/network alarm. Type Local alarm: Device detects alarm from input port. Network: Device detects alarm from network. Alarm in Select corresponding alarm channel. Enable You need to draw a circle here so that system can detect the alarm signal.

  • Page 36: Advanced

    Parameter Function Save You can click save button after you complete setup for one channel, or you can complete the whole setups and then click save button. Refresh Click this button to get device latest configuration information. Default and Backup The default and copy interface is shown as below.

  • Page 37: Additional Function

    Figure 3-31 Auto Maintenance Here you can select auto reboot and auto delete old files interval from the dropdown list. See Figure 3-32 Please note system is in four-window display mode after it automatically rebooted. Figure 3-32 3.5.4 Additional Function Preferred DNS Here you can set server or local operator DNS address.

  • Page 38: Alarm

    Figure 3-33 3.6 Alarm There are three modes: external alarm/decoder alarm/DSP alarm. You can set alarm prompt mode. See Figure 3-34. Figure 3-34...

  • Page 39: About

    About Click about button, you can view the web information. See Figure 3-35. Figure 3-35 Log out Click log out button, you can go back to log in interface. See Figure 3-36 Figure 3-36...

  • Page 40: Alarm Input And Output

    Before device connection, please make sure: Alarm Input Please check the alarm type (Normal open/normal close) first. Then set the XP101VD network alarm type. Set NVS alarm type as NO (Normal Open) if it is ground alarm, otherwise set it as NC (Normal Close).

  • Page 41: Alarm Output Port

    Please refer to the following figure for more information. See Figure 4-2. Figure 4-2 Alarm Output Port 8-ch alarm output (normal open contact). The external alarm device needs the battery supported. To avoid overload to damage the device, please refer to the following sheet for relay specification information.

  • Page 42: Alarm Output Relay Specification

    Figure 4-4 Alarm Output Relay Specification 4.3.1 Contact parameters Contact Form 100mΩ（0.1A 6VDC） Contact Resistance Contact Material AgNi+Gilded Contact Rating 0.5A 125VAC/1A 30VDC ( Resistive) Max. switching voltage 125VAC/60VDC Max. switching current Max. switching power 62.5VA/30W Min. permissible loading 1mA 5V Mechanical durability 1x107times（300 times/min）...

  • Page 43: Network Keyboard Control Decode Explanation

    5. Network Keyboard Control Decode Explanation 5.1 Connection 5.1.1 Keyboard setup after serial ports connected The user must login decoder Web and choose “network keyboard “in serial port setup -＞RA232, then before connect the keyboard and the decoder. i.e.: system config. choose network keyboard in serial port function.

  • Page 44: Login Method

    Set the network keyboard IP first, please refer to the following Control IP: 192.168.090.111 instructions. Control Port: 3777 In the network keyboard, menu-> local config. -> Network Protocol: DVR--2 config. Then set IP address, sub net mask, gateway and port. ID number, device name, and device type are needed to be set.

  • Page 45: Appendix Toxic Or Hazardous Materials Or Elements

    Appendix Toxic or Hazardous Materials or Elements Component Name Toxic or Hazardous Materials or Elements Cr VI PBDE Sheet metal(box) ○ ○ ○ ○ ○ ○ Plastic Component ○ ○ ○ ○ ○ ○ (panel) Device Construction ○ ○ ○ ○...
