- Page 1 High Definition Digital TV Tuner Set Top Box User Operation Guide Model: PHD-101 © Copyright 2005, PrimeDTV Technologies, Inc.
-
Page 2: Safety Precautions
Safety Precautions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICEING TO QUALIFIED SERVICE PERSONNEL. This lighting flash with arrowhead symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any inside part of this product. -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT SAFETY INCTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS INSTALLATION AND OPERATING GUIDE AND THOSE MARKED ON THE UNIT. RETAIN THIS GUIDE FOR FUTRE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. - Page 4 Important Safety Instructions 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two blades with one wider than the other.
-
Page 5: Table Of Contents
Front Panel ………………………………………………………….. Rear Panel …………………………………………………………… Remote Control ……………………………………………………… Installing Batteries ………………………………………………….. Connecting PHD-101 ………………………………………………. Antenna / RF Connections ………………………………………… Connecting PHD-101 to TV Set …………………………………… Connecting to Digital Ready TV …………………………………… Connecting to Conventional Analog TV ………………………….. - 4 -... - Page 6 Table of Contents CONTENTS - 5 -...
-
Page 7: Introduction
Cable clear QAM (64 and 256 QAM signals) from an external antenna/ cable RF source. PHD-101 is a perfect match for consumer's EDTV or HDTV monitors, or converts HDTV signals to analog signals for conventional TV displaying. The unit features Component (YPbPr HD/SD), RGB, DVI, S-Video and Composite (CVBS) video outputs. -
Page 8: Phd-101 Components
Introduction PHD-101 Components The following items are packed with your PHD-101 • Remote control with 2x AAA batteries • Audio / Video cables (Yellow-Red-White cables) • Component cables (Green-Blue-Red cables) • PHD-101 User Operation Guide You’ll also need the following items to get started: •... -
Page 9: Front Panel
ENTER button Part of OSD Menu control. Enter to select more menu functions. MENU button Bring up OSD Menu. CLEAR button Exit menu or clear current menu selection. Power LED Lights to indicate PHD-101 on or standby state. - 8 -... -
Page 10: Rear Panel
Rear Panel AIR/CABLE IN Connect Over-the-Air antenna or Digital Cable signal here. The Digital cable signal is only clear QAM signal, which local cable provider is passing through 8VSB on their system. VIDEO OUT Connect this jack to your conventional TV or VCR having composite video input. DTV OUT (Component, Y-Pb-Pr format) Connect these jacks to your TV digital component inputs. - Page 11 HDTV that can support 480p video output format. • 480i Use this setting for a conventional TV with composite video (CVBS) or S-Video inputs. AC POWER IN A wire to connect to AC power outlet to power PHD-101 unit. - 10 -...
-
Page 12: Remote Control
Press to show current channel's EPG (Electronic Program Guide) for 12 hours period of time. MENU Press to bring up OSD (On-Screen- Display) Menu to set up PHD-101 functions. ADD/DEL Press to add and delete current scanned channels. Channel (Up/Down) Press these keys to change channels. - Page 13 Remote Control POWER Press to turn PHD-101 power on or off. MUTE Mute TV audio. Press again to un-mute. CLEAR Clear current OSD display or exit the menus. GOBACK Press to return the previous select channel. Navigation Buttons Use Navigation buttons...
-
Page 14: Installing Batteries
Remote Control Installing Batteries Press and remove the battery cover on the back of remote control. Put 2 x AAA batteries into the compartment and put the battery cover back. - 13 -... -
Page 15: Connecting Phd-101
Connect to Cable signal source using a coaxial RF cable. Note: The PHD-101 can receive DTV signal in the event that a local cable provider is passing 8VSB through their system. This 8VSB signal can not be encrypted by Cable Company. And we call it Clear QAM signal from cable. -
Page 16: Connecting Phd-101 To Tv Set
“Antenna /RF Connections”. Connect video component cable (Y-Pb-Pr cable) from DTV OUT (Component) jack of PHD-101 to your digital ready TV component video connector inputs. Or, you can connect RGB video from DTV OUT (RGB) jack to your digital ready TV or RGB video monitor (for ex. -
Page 17: Connecting To Conventional Analog Tv
Connecting PHD-101 to TV Set Connecting to Conventional Analog TV Connect antenna cable to AIR/CABLE jack of PHD-101 unit. Refer to previous section “Antenna /RF Connections”. Connect video cable from MONITOR OUT VIDEO jack to the TV video (CVBS) input. - Page 18 MENU Operation - 17 -...
