Le Continental
Document n° 952-3 EN ~ 02/03/2000
Français
Oil fired stove
English
Model 174 07 53
Norsk
(ANSI/UL & CAN/CSA approved)
Technical manual
to be saved
by the user
for future reference
Description of the appliance
Installation instructions
Operating instructions
Spare parts
Les Fonderies Franco-Belges
59660 MERVILLE
Phone : 03.28.43.43.43
Warranty certificate
Fax : 03.28.43.43.99
RC Hazebrouck 445750565B
Subject to modifications

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Le Continental 174 07 53 and is the answer not in the manual?

Questions and answers

Summary of Contents for Franco Belges Le Continental 174 07 53

  • Page 1 Le Continental Document n° 952-3 EN ~ 02/03/2000 Français Oil fired stove English Model 174 07 53 Norsk (ANSI/UL & CAN/CSA approved) Technical manual to be saved by the user for future reference Description of the appliance Installation instructions Operating instructions Spare parts Les Fonderies Franco-Belges 59660 MERVILLE...

  • Page 2: Table Of Contents

    Continental Poêle à combustible liquide FRANCO BELGE congratulates you on your choice. FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products.

  • Page 3: Description Of The Unit

    Continental Poêle à combustible liquide 1. Description of the unit 1.1. Description Flued oil stove with vaporizing burner (Norm EN1) 1.2. Optional equipment ¤ Ground vat 1.3. Specifications Nominal Heat Output (NF D 35.001) . . . kW ..... . Btu/hr 26.000 Oil consumption at : - maximum speed .

  • Page 4: Operating Principle

    Continental Poêle à combustible liquide A de-scaling lever (# 1, fig.8) can be pushed and pulled 1.4. Operating principle in and out as well as turning slightly at the same time to keep the inlet pipe clear of carbon buildup. Furnace oil is fed to the burner floor (fig.

  • Page 5: Levelling

    Continental Poêle à combustible liquide 2.5. Pre-utilisation check Check, that the seals are in good condition, that the door closes correctly, that the glasses are not damaged. 2.6. Mounting the levelling feet Fit the 3 screws and the 3 caps supplied (on the burner) into each leg of the stove (fig.

  • Page 6: Oil Flow Adjustment

    Continental Poêle à combustible liquide 2.9. Oil flow adjustment The float regulator has been adjusted at the factory and should not need further adjustment. If the burner does not work correctly, check possible causes before readjusting the settings : - Chimney draught - Fresh air inlet - Oil supply.

  • Page 7: Operating Instructions

    Continental Poêle à combustible liquide 3. Operating instructions 3.1. Fuel Warning : Your stove is fitted with a specific float regulator for a specific oil. ¤ Fuel oil # 2 or fuel oil # 1 The fuel oil must be free from any dirt and water which could disturb the stove in operation.

  • Page 8: Trouble Shooting

    Continental Poêle à combustible liquide regulator filter opening in order to collect the oil • Use a soft clean cloth to wipe the front glass when the contained in the regulator, unit is running at a low burning rate. When the main - remove the filter cover plate located under the door is opened for cleaning, the flame will be disturb, regulator (# 4 of fig.

  • Page 9: Spare Parts

    Continental Poêle à combustible liquide 4. Spare parts When ordering spare parts, please indicate : model n°, Example : Oil fired stove 174 07 53 L, leg 300120 77 colour code, description of the part, code of the part. A = 174 07 53 L B = 174 07 53 Y C = 174 07 53 J N°...
  • Page 10 Continental Poêle à combustible liquide 188784 Refractory glass ..27x(112x20) ..A ..B ..C ..01 199304 Mirror glass (optional) .
  • Page 11 Continental Poêle à combustible liquide Fig. 9 Notice de référence Document n° 952-3 EN ~ 02/03/2000...
  • Page 12 § Warranty certificate § § Legal warranty technical manual supplied with the unit have been followed, - All operation and maintenance instructions have been Our products are guaranteed for twelve months against any followed. defect, flaw or imperfection. During this time, all parts judged This warranty does not cover defective by our Warranty control department may be repla- ced in our workshops.
