Meicheng CMLUX-88S Operation Manual

8 by 8 hdmi v1.3 matrix

Advertisement

Quick Links

Meicheng
R
CMLUX-88S
8 by 8 HDMI V1.3 Matrix
Operation Manual
CMLUX-88S
http://www.meicheng.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMLUX-88S and is the answer not in the manual?

Questions and answers

Summary of Contents for Meicheng CMLUX-88S

  • Page 1 Meicheng CMLUX-88S 8 by 8 HDMI V1.3 Matrix Operation Manual CMLUX-88S http://www.meicheng.com.tw...
  • Page 2: Copyright Notice

    Meicheng assumes no responsibility for any inaccuracies that may be contained in this document. Meicheng also makes no commitment to update or to keep current the information contained in this document.
  • Page 3: Safety Precautions

    Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment:  Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
  • Page 4: Table Of Contents

    Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Remote Control .......…..……………..…..…..…... 8.1 IR Costom Code....…..……………..…..…..…. 8.2 Discrete IR codes for 8x8 HDMI matrix (IR3)..…..…..…... IR Pin Assignment ................
  • Page 5: Introduction

    1. Introduction The popularity of HDMI products over the years is now widely seen in today ’ s commercial and residential environments. People usually have several HDMI displays and sources in a single place. As multiple HDMI inputs and outputs increase, the need for a HDMI matrix that will inter-connect these HDMI devices is becoming more eminent.
  • Page 6: Features

    5. Features HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant  Supports digital video formats in Deep Color 10 bits and new lossless  compressed (Dolby TrueHD, Dolby Digital Plus and DTS HD Master Audio) digital audio The HDMI input is compensated, clock / phase adjusted and jitter ...
  • Page 7: Specifications

    6. Specifications Input Ports 8 x HDMI Output Ports 8 x HDMI IR Frequency 20~60KHz Power Supply 24VDC/6.25A (US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ± 10kV (air-gap discharge) ± 6kV (contact discharge) Dimensions (mm) 482(W) x385(D) x 176(H) Weight(g) 9500 Chassis Material...
  • Page 8: Operation Controls And Functions

    7. Operation Controls and Functions The following sections describe the hardware components of the unit. 7.1 Front Panel ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① LCM monitor: This monitor displays your setting information with each output and input selection. ②...
  • Page 9 ⑤ LOCK: Press this button to lock all functions and press it again to release the lock function. When LED illuminate in GREED, lock function is activate. If the LED is not illuminate, the key lock is released. ⑥ ENTER: Press this button after each and every selection to confirm the setting.
  • Page 10: Rear Panel

    7.2 Rear Panel ① ② ③ ④ ⑤ ⑥ ⑦ ① HDMI OUTPUT A~H: These slots are where you connect to the HDMI displays. ② SERVICE: This slot is where you connect with a D-Sub 9 pin male connector cable to your host side for firmware upgrading. ③...
  • Page 11: Remote Control

    8. Remote Control This remote control can be set with multiple format according to the dipswitch setting. There are total of four dipswitches with mainly two kinds of settings. When dipswitches are all set to ON/ ↑ the remote control is able to control all outputs and all inputs. For example, when output A wish to select input 5.
  • Page 12: Ir Pin Assignment

    9. IR Pin Assignment 9.1 IR Receiver ① IR signal ② Power 5V ③ Grounding ① ② ③ 10. RS-232 Protocols 10.1 Pin Assignment CMLUX-88S Remote Control Console Assignment Assignment Baud Rate: 19200bps Data bit: 8 bits Parity: None Flow Control: None...
  • Page 13: Commands

    10.2 Commands COMMAND ACTION POWER 00 Power Off (standby) POWER 01 Power On PORT 11 Output A select Input1 PORT 12 Output A select Input2 PORT 13 Output A select Input3 PORT 14 Output A select Input4 PORT 15 Output A select Input5 PORT 16 Output A select Input6 PORT 17...
  • Page 14 PORT 47 Output D select Input7 PORT 48 Output D select Input8 PORT 51 Output E select Input1 PORT 52 Output E select Input2 PORT 53 Output E select Input3 PORT 54 Output E select Input4 PORT 55 Output E select Input5 PORT 56 Output E select Input6 PORT 57...
  • Page 15: Connection And Installation

    11. Connection and Installation HD TV HD TV Blu-ray HD TV HD TV Blu-ray HD TV HD TV HD TV HD TV...
  • Page 16: Acronyms

    Acronyms Acronym Complete Term Digital Theater System Digital Visual Interface EDID Extedned Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television Liquid Crystal Monitor Universal Serial Bus UXGA Ultra Extended Graphics Array Video Graphics Array...
