  • Page 1 H81-GAMER...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ..................iv About this guide ..................iv Package contents ..................vi H81-GAMER specifications summary ............vi Chapter 1: Product introduction Before you proceed ..............1-1 Motherboard overview ..............1-1 Central Processing Unit (CPU) ........... 1-3 System memory ................1-7 Expansion slots ................

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: Conventions Used In This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Package Contents

    Hyper DIMM support is subject to the physical characteristics of individual CPUs. Memory Please refer to Memory QVL (Qualified Vendors List) for details. Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). *** Due to Intel chipset limitation, DDR3 1600 MHz and higher memory modules on XMP ®...

  • Page 7: Performance Optimization

    - 10K Black Metallic Capacitors - Stainless Steel Back I/O - ASUS DIGI+ VRM Performance Optimization - ASUS DIGI+ VRM: Digital Power Design for the CPU - ASUS EPU - ASUS GPU Boost - ASUS Fan Xpert 2 - USB 3.0 Boost...
  • Page 8 1 x Clear CMOS jumper 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, BIOS features F11 EZ Tuning Wizard, F6 Q-Fan Control, F3 My Favorites, Quick Note, Last...

  • Page 9: Chapter 1: Product Introduction

    Placement direction When installing the motherboard, place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image. 1.2.2 Screw holes Place six screws into the holes indicated by circles to secure the motherboard to the chassis. Do not overtighten the screws! Doing so can damage the motherboard. ASUS H81-GAMER...

  • Page 10: Motherboard Layout

    Place this side towards the rear of the chassis H81-GAMER 1.2.3 Motherboard layout 21.4cm(8.4in) KBMS CPU_FAN DIGI +VRM EATX12V CHA_FAN2 USB56 LGA1150 USB3_12 LAN_USB34 CHA_FAN1 AUDIO PCIEX1_1 H81-GAMER Intel I218V PCIEX16 BATTERY PCIEX1_2 Super 1083 PCIEX1_3 Intel ® PCI1 SUPREMEFX...

  • Page 11: Layout Contents

    1-19 [black]) 8. Standby Power LED (SB_PWR) 1-21 9. System panel connector (20-8 pin PANEL) 1-20 10. Clear RTC RAM (3-pin CLRTC) 1-11 11. USB 2.0 connectors (10-1 pin USB910, USB1112) 1-17 12. TPM connector (20-1 pin TPM) 13. Serial port connectors (10-1 pin COM) 1-15 14. Front panel audio connector (10-1 pin AAFP) 1-16 Central Processing Unit (CPU) This motherboard comes with a surface mount LGA1150 socket designed for the Intel ® and New 4th Generation Core™ i7 / Core™ i5 / Core™ i3, Pentium , Celeron processors. ® ® H81-GAMER H81-GAMER CPU socket LGA1150 ASUS H81-GAMER...

  • Page 12: Installing The Cpu

    Unplug all power cables before installing the CPU. • Ensure that you install the correct CPU designed for the LGA1150 socket only. DO NOT install a CPU designed for LGA1155 and LGA1156 sockets on the LGA1150 socket. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1150 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. 1.3.1 Installing the CPU Chapter 1: Product introduction...

  • Page 13: Cpu Heatsink And Fan Assembly Installation

    1.3.2 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. ASUS H81-GAMER...
  • Page 14 To install the CPU heatsink and fan assembly To uninstall the CPU heatsink and fan assembly Chapter 1: Product introduction...

  • Page 15: System Memory

    System memory 1.4.1 Overview This motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Module (DIMM) sockets. A DDR3 module is notched differently from a DDR or DDR2 module. DO NOT install a DDR or DDR2 memory module to the DDR3 slot. According to Intel CPU spec, DIMM voltage below 1.65 V is recommended to protect the ® CPU. H81-GAMER H81-GAMER 240-pin DDR3 DIMM sockets 1.4.2 Memory configurations You may install 1 GB, 2 GB, 4 GB, and 8 GB unbuffered non-ECC DDR3 DIMMs into the DIMM sockets. You can refer to the recommended memory population below. Combination DIMM_A1 DIMM_A2 DIMM_B1 DIMM_B2 Recommended SS: Single-sided memory DS: Double-sided memory ASUS H81-GAMER...
  • Page 16 Always install DIMMs with the same CAS latency. For optimal compatibility, we recommend that you install memory modules of the same version or date code (D/C) from the same vendor. Check with the retailer to get the correct memory modules. • Due to the memory address limitation on 32-bit Windows OS, when you install 4GB ® or more memory on the motherboard, the actual usable memory for the OS can be about 3GB or less. For effective use of memory, we recommend that you do any of the following: Use a maximum of 3 GB system memory if you are using a 32-bit Windows OS. ® I nstall a 64-bit Windows OS if you want to install 4GB or more on the ® motherboard. F or more details, refer to the Microsoft support site at http://support.microsoft. ® com/kb/929605/en-us. • This motherboard does not support DIMMs made up of 512 Mb (64 MB) chips or less. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs). • Visit the ASUS website at www.asus.com for the latest QVL. Chapter 1: Product introduction...

  • Page 17: Installing A Dimm

    Press the retaining clip outward to DIMM notch unlock a DIMM socket. Align a DIMM on the socket such that the notch on the DIMM matches the DIMM slot key on the socket. DIMM slot key A DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket in the wrong direction to avoid damaging the DIMM. Firmly insert the DIMM into the socket until the retaining clip clicks back in place and the DIMM is properly seated. 1.4.4 Removing a DIMM To remove a DIMM: Press the retaining clips outward to unlock the DIMM. Support the DIMM lightly with your fingers when pressing the retaining clip. The DIMM might get damaged when it flips out with extra force. Remove the DIMM from the socket. ASUS H81-GAMER...

  • Page 18: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. 1.5.1 Installing an expansion card To install an expansion card: Before installing the expansion card, read the documentation that came with it and make the necessary hardware settings for the card. Remove the system unit cover (if your motherboard is already installed in a chassis).

  • Page 19: Jumpers

    – – – – – – ASM USB3.0 Shared HD Audio – – – – – – Shared – Jumpers Clear RTC RAM (3-pin CLRTC) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. H81-GAMER CLRTC Normal Clear RTC (Default) H81-GAMER Clear RTC RAM ASUS H81-GAMER 1-11...

  • Page 20: Connectors

    To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5-10 seconds, then move the cap back to pins 1-2. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! • If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery. • You do not need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature. Shut down and reboot the system, then the BIOS automatically resets parameter settings to default values. Connectors 1.7.1 Rear panel connectors 4 5 6 7 PS/2 mouse port (green). This port is for a PS/2 mouse. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other VGA-compatible devices.
  • Page 21 • Refer to the audio configuration table for the function of the audio ports in 2.1, 4.1, 5.1 or 7.1-channel configuration. • For 8-channel speaker, you may refer to the 7.1-channel configuration. Audio 2.1, 4.1, 5.1, or 7.1-channel configuration Headset Port 4.1-channel 5.1-channel 7.1-channel 2.1-channel Light Blue Line In Line In Line In Side Speaker Out Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink Mic In Mic In Mic In Mic In Orange – – Center/Subwoofer Center/Subwoofer Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out ASUS H81-GAMER 1-13...

  • Page 22: Internal Connectors

    CPU and chassis fan connectors (4-pin CPU_FAN, CHA_FAN1, CHA_FAN2) Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. CPU_FAN CHA_FAN2 CHA FAN PWR CHA FAN IN CHA_FAN1 H81-GAMER H81-GAMER Fan connectors Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! The CPU_FAN connector supports a CPU fan of maximum 1 A (12 W) fan power. 1-14 Chapter 1: Product introduction...
  • Page 23 Serial port connector (10-1 pin COM) This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. PIN 1 H81-GAMER H81-GAMER Serial port (COM) connector EATX power connectors (24-pin EATXPWR, 8-pin EATX12V) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. EATX12V EATXPWR PIN 1 +3 Volts +12 Volts +5 Volts +5 Volts +12 Volts...
  • Page 24 Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC`97 audio standard. Connect one end of the front panel audio I/O module cable to this connector. AAFP H81-GAMER PIN 1 HD-audio-compliant Legacy AC’97 pin definition compliant definition H81-GAMER Front panel audio connector • We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. • If you want to connect a high-definition front panel audio module to this connector, set the Front Panel Type item in the BIOS setup to [HD]. If you want to connect an AC’97 front panel audio module to this connector, set the item to [AC97]. By default, this connector is set to [HD]. See section 2.6.7 Onboard Devices Configuration for details. 1-16 Chapter 1: Product introduction...

  • Page 25: Usb 3.0/Usb 2.0 Connector

    USB3+5V IntA_P1_SSRX- IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ IntA_P1_SSTX- IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ IntA_P1_D- IntA_P2_D- IntA_P1_D+ IntA_P2_D+ H81-GAMER USB3.0 Front panel connector The USB 3.0 module is purchased separately. USB 2.0 connectors (10-1 pin USB910, USB1112) These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specifications and supports up to 480Mbps connection speed. USB910 USB1112 H81-GAMER PIN 1 PIN 1 H81-GAMER USB2.0 connectors Never connect a 1394 cable to the USB connectors. Doing so will damage the...
  • Page 26 H81 Serial ATA 6.0Gb/s connector (7-pin SATA6G_1, SATA6G_2 [gray]) ® This connector connects to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0 Gb/s signal cables. SATA6G_1 RSATA_TXP1 RSATA_TXN1 H81-GAMER RSATA_RXN1 RSATA_RXP1 SATA6G_2 RSATA_TXP2 RSATA_TXN2 RSATA_RXN2 RSATA_RXP2 H81-GAMER Intel SATA 6.0Gb/s connectors ® When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to [AHCI]. See section PCH Storage Configurationfor details. 1-18 Chapter 1: Product introduction...
  • Page 27 Intel H81 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1, SATA3G_2 [black]) ® These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical drives via Serial ATA 3.0 Gb/s signal cables. SATA3G_1 RSATA_TXP1 RSATA_TXN1 H81-GAMER RSATA_RXN1 RSATA_RXP1 SATA3G_2 RSATA_TXP2 RSATA_TXN2 RSATA_RXN2 RSATA_RXP2 H81-GAMER Intel SATA 6.0Gb/s connectors ® When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to [AHCI]. See section PCH Storage Configuration for details. ASUS H81-GAMER 1-19...

  • Page 28: System Panel Connector

    System panel connector (20-8 pin PANEL) This connector supports several chassis-mounted functions. +PWR_LED- SPEAKER PANEL H81-GAMER PIN 1 +HDD_LED- PWR_SW RESET H81-GAMER System panel connector • System power LED (2-pin PWR_LED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HDD LED lights up or flashes when data is read from or written...

  • Page 29: Onboard Led

    The motherboard comes with a standby power LED that lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. H81-GAMER SB_PWR Standby Power Powered Off H81-GAMER Onboard LED ASUS H81-GAMER 1-21...

  • Page 30: Software Support

    Motherboard settings and hardware options vary. Refer to your OS documentation for detailed information. 1.9.2 Support DVD information The Support DVD that comes with the motherboard package contains the drivers, software applications, and utilities that you can install to avail all motherboard features. The contents of the Support DVD are subject to change at any time without notice. Visit the ASUS website at www.asus.com for updates. To run the Support DVD Place the Support DVD into the optical drive. If Autorun is enabled in your computer, the DVD automatically displays the lists of the unique features of your ASUS motherboard. Click the Drivers, Utilities, AHCI Driver, Manual, Contact, or Specials tabs to display their respective menus. The following screen is for reference only. Click an icon to display Support...

  • Page 31: Chapter 2: Bios Information

    DVD and a USB flash disk drive. Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility.

  • Page 32: Asus Ez Flash

    2.1.2 ASUS EZ Flash 2 The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS-based utility. Before you start using this utility, download the latest BIOS file from the ASUS website at www.asus.com. To update the BIOS using EZ Flash 2: Insert the USB flash disk that contains the latest BIOS file to the USB port.

  • Page 33: Asus Crashfree Bios 3 Utility

    2.1.3 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains the updated BIOS file.
  • Page 34 Boot your computer then press <F8> to launch the BIOS Boot Device Select menu. When the BIOS Boot Device Select Menu appears, insert the Support DVD into the optical drive then select the optical drive as the boot device. Please select boot device: ASUS DVD-E818A6T (4069MB) USB DISK 2.0 (3824MB) UEFI: (FAT) USB DISK 2.0 (3824MB)
  • Page 35 DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu for more information. ASUS H81-GAMER...

  • Page 36: Bios Setup Program

    The BIOS setup screens shown in this section are for reference only. Some screen displays may not be the same as what you see on your screen. Visit the ASUS website at www.asus.com to download the latest BIOS file for this •...
  • Page 37 Click to display boot devices Selects the boot device priority • The boot device options vary depending on the devices you installed to the system. • The Boot Menu(F8) button is available only when the boot device is installed to the system. ASUS H81-GAMER...

  • Page 38: Advanced Mode

    Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. Refer to the following sections for the detailed configurations. To access the EZ Mode, click EZ Mode or press F7. Configuration fields Quick Note (F9) Pop-up Menu Scroll bar Menu bar...

  • Page 39: Menu Items

    General help At the top right corner of the menu screen is a brief description of the selected item. Use <F12> key to capture the BIOS screen and save it to the removable storage device. ASUS H81-GAMER...

  • Page 40: Configuration Fields

    Configuration fields These fields show the values for the menu items. If an item is user-configurable, you can change the value of the field opposite the item. You cannot select an item that is not user-configurable. A configurable field is highlighted when selected. To change the value of a field, select it and press <Enter>...

  • Page 41: Main Menu

    RAM to clear the BIOS password. See section Jumpers for information on how to erase the RTC RAM. • The Administrator or User Password items on top of the screen show the default Not Installed. After you set a password, these items show Installed. ASUS H81-GAMER 2-11...

  • Page 42: Administrator Password

    Administrator Password If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. Otherwise, you might be able to see or change only selected fields in the BIOS setup program. To set an administrator password: Select the Administrator Password item and press <Enter>.

  • Page 43: Ai Tweaker Menu

    Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field values can cause the system to malfunction. The configuration options for this section vary depending on the CPU and DIMM model you installed on the motherboard. Scroll down to display the following items: ASUS H81-GAMER 2-13...
  • Page 44 Scroll down to display the following items: Target CPU Turbo-Mode Frequency : xxxxMHz Displays the target CPU Turbo-Mode frequency. Target DRAM Frequency : xxxxMHz Displays the target DRAM speed. Target Cache Frequency : xxxxMHz Displays the target Cache speed. Target DMI/PEG Frequency : xxxxMHz Displays the target DMI/PEG clock.
  • Page 45 Allows you to enable the GPU Boost to accelerate the integrated GPU for extreme graphics performance. Configuration options: [Keep Current Settings] [Enabled] 2.5.8 EPU Power Saving Mode [Disabled] Allows you to enable or disable the EPU power saving function. Configuration options: [Disabled] [Enabled] ASUS H81-GAMER 2-15...

  • Page 46: Dram Timing Control

    2.8.9 DRAM Timing Control The subitems in this menu allow you to set the DRAM timing control features. Use the <+> and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard and press the <Enter> key. Changing the values in this menu may cause the system to become unstable! If this happens, revert to the default settings.
  • Page 47 DRAM IO-L (CHA_R1D0) [Auto] Configuration options: [Auto] [1] - [15] DRAM IO-L (CHA_R1D1) [Auto] Configuration options: [Auto] [1] - [15] DRAM IO-L (CHB_R0D0) [Auto] Configuration options: [Auto] [1] - [15] DRAM IO-L (CHB_R0D1) [Auto] Configuration options: [Auto] [1] - [15] ASUS H81-GAMER 2-17...
  • Page 48 DRAM IO-L (CHB_R1D0) [Auto] Configuration options: [Auto] [1] - [15] DRAM IO-L (CHB_R1D1) [Auto] Configuration options: [Auto] [1] - [15] Third Timings tRDRD [Auto] Configuration options: [Auto] [1 DRAM Clock] – [7 DRAM Clock] tRDRD_dr [Auto] Configuration options: [Auto] [1 DRAM Clock] – [15 DRAM Clock] tRDRD_dd [Auto] Configuration options: [Auto] [1 DRAM Clock] –...
  • Page 49 Configuration options: [Enable Both DIMMS] [Disable DIMM0] [Disable DIMM1] [Disable Both DIMMS] Scrambler Setting [Optimized (ASUS)] Configuration options: [Optimized (ASUS)] [Default (MRC)] MCH Full Check [Auto] Allows you to enable, disable, or automatically set the MCH Full Check function. Configuration options: [Auto] [Enabled] [Disabled] Skew Control Adjust these items may enhance the DRAM overclocking capability and stability.
  • Page 50 2.5.10 DIGI+ VRM CPU Load-Line Calibration [Auto] Load-line is defined by Intel VRM specification and affects CPU voltage. The CPU working voltage will decrease proportionally to CPU loading. Higher value gets a higher voltagve and better overclocking performance, but increases the CPU and VRM thermal conditions. This item allows you to adjust the voltage range from the following percentages to boost the system performance.
  • Page 51 Allows you to set the frequency tuning mode. Configuration options: [Auto] [+] [-] CPU Internal Power Fault Control Thermal Feedback [Auto] When enabled, it allows CPU to take precautionary actions when the thermal of the external regulator exceeds the limit.Configuration options: [Auto] [Disabled] [Enabled] ASUS H81-GAMER 2-21...
  • Page 52 CPU Integrated VR Fault Management [Auto] Allows you to manage the CPU Integrated VR fault. Configuration options: [Auto] [Disabled] [Enabled] CPU Internal Power Configuration CPU Integrated VR Efficiency Management [Auto] Allows you to manage the CPU integrated VR efficiency. Configuration options: [Auto] [High Performance] [Balanced] Power Decay Mode [Auto] Enable to improve power saving on the Fully Integrated Voltage Regulator as the...
  • Page 53 CPU Cache Voltage Offset [Auto] This item appears only when you set the CPU Cache Voltage to [Offset Mode] and allows you to set the CPU cache voltage offset. The values range from 0.001V to 0.999V with a 0.001V interval. ASUS H81-GAMER 2-23...
  • Page 54 2.5.15 CPU Graphics Voltage [Auto] This item allows you to set the CPU graphics voltage. Increase the graphics voltage when increasing the iGPU frequency. Configuration options: [Auto] [Manual Mode] [Offset Mode] [Adaptive Mode] CPU Graphics Voltage Override [Auto] This item appears only when you set the CPU Graphics Voltage to [Manual Mode] and allows you to set the CPU graphics voltage override.
  • Page 55 The system may need better cooling system to work stably under high voltage settings. 2.5.24 DRAM CTRL REF Voltage [Auto] Allows you to set the DRAM CTRL REF Voltage. The values range from 0.39500x to 0.63000x with a 0.00500x interval. ASUS H81-GAMER 2-25...

  • Page 56: Advanced Menu

    2.5.25 DRAM DATA REF Voltage on CHA [Auto] Allows you to set the DRAM DATA REF Voltage on CHA. The values range from 0.39500x to 0.63000x with a 0.00500x interval 2.5.26 DRAM DATA REF Voltage on CHB [Auto] Allows you to set the DRAM DATA REF Voltage on CHB. The values range from 0.39500x to 0.63000x with a 0.00500x interval 2.5.27 CPU Spread Spectrum [Auto]...

  • Page 57: Cpu Configuration

    Boot performance mode [Max Non-Turbo Performance] This item allows you to select the boot performance mode. Configuration options: [Max Non- Turbo Performance] [Max battery] [Turbo Performance] CPU Power Management Configuration This item allows you to manage and configure the CPU’s power. ASUS H81-GAMER 2-27...
  • Page 58 Enhanced Intel SpeedStep Technology [Enabled] Allows you to enable or disable the Enhanced Intel SpeedStep Technology (EIST). ® [Disabled] The CPU runs at its default speed. [Enabled] The operating system controls the CPU speed. Turbo Mode [Enabled] Allows you to set the processor cores to run faster than the marked frequency in a specific condition.

  • Page 59: Pch Configuration

    Allows you to enable or disable the ISCT configuration. Configuration options: [Enabled] [Disabled] 2.6.3 PCH Storage Configuration While entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA Port items show Not Present if no SATA device is installed to the corresponding SATA port. ASUS H81-GAMER 2-29...

  • Page 60: System Agent Configuration

    SATA Mode Selection [AHCI] Allows you to set the SATA configuration. [Disabled] Disables the SATA function. [IDE] Set to [IDE] when you want to use the Serial ATA hard disk drives as Parallel ATA physical storage devices. [AHCI] Set to [AHCI] when you want the SATA hard disk drives to use the AHCI (Advanced Host Controller Interface).

  • Page 61: Dmi Configuration

    The USB devices can be used only for the BIOS setup program. [Auto] Allows the system to detect the presence of USB devices at startup. If detected, the USB controller legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled. ASUS H81-GAMER 2-31...

  • Page 62: Platform Misc Configuration

    Intel xHCI Mode [Smart Auto] ® [Auto] Keeps the last operation of xHCI controller in OS during bootup. [Smart Auto] Enables the operation of xHCI controller. [Enabled] Enables the function. [Disabled] Disables the function. EHCI Hand-off [Disabled] [Enabled] Enables the support for operating systems without an EHCI hand-off feature.

  • Page 63: Onboard Devices Configuration

    PEG ASPM Support [Disabled] This item allows you to select the ASPM state for energy-saving conditions, or use the ASUS optimized energy saving profile. Configuration options: [Disabled] [ASPM L0s] [L1] [L0sL1] [Auto] 2.6.7 Onboard Devices Configuration HD Audio Controller [Enabled] [Enabled] Enables the HD Audio Device.

  • Page 64: Serial Port Configuration

    Serial Port Configuration The sub-items in this menu allow you to set the serial port configuration. Serial Port [Enabled] Allows you to enable or disable the serial port (COM).Configuration options: [Enabled] [Disabled] Change Settings [IO=3F8h; IRQ=4] This item appears only when you set the Serial Port to [Enabled] and allows you to select the Serial Port base address.

  • Page 65: Network Stack Configuration

    Ipv6 PXE Support [Enabled] This item allows user to disable or enable the Ipv6 PXE Boot support. Configuration options: [Disabled] [Enabled] Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. ASUS H81-GAMER 2-35...
  • Page 66 Scroll down to display the following items: 2.7.1 Qfan Tuning Click this item to automatically detect the lowest speed and configure the minimum duty cycle for each fan. 2.7.2 CPU Temperature / MB Temperature [xxx°C/xxx°F] The onboard hardware monitor automatically detects and displays the CPU / mobtherboard temperature.
  • Page 67 2.7.6 Chassis Fan 1/ Chassis Fan 2 Q-Fan Control [DC Mode] [DC Mode] Enables the Chassis fan 1/2 Q-Fan control feature. [Disabled] Disables the Chassis fan 1/2 Q-Fan control feature. ASUS H81-GAMER 2-37...
  • Page 68 Chassis Fan 1 / Chassis Fan 2 Speed Low Limit [300 RPM] This item appears only when you enable the Chassis Fan1/2 Q-Fan Control feature and allows you to disable or set the chassis fan warning speed. Configuration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM] Chassis Fan 1 / Chassis Fan 2 Profile [Standard] This item appears only when you enable the Chassis Fan 1/2 Q-Fan Control feature and allows you to set the appropriate performance level of the chassis fan 1/2.

  • Page 69: Boot Menu

    All devices connected to SATA ports will be available during POST. This process will extend the POST time. [Hard Drive Only] Only hard drives connected to SATA ports will be detected during POST. Any hardware change will disable fast boot. ASUS H81-GAMER 2-39...
  • Page 70 [Boot Drive Only] Only boot drive connected to SATA ports will be detected during POST. Any hardware change will disable fast boot. USB Support [Partial Initialization] [Disabled] All USB devices will not be available until OS boot up for a fastest POST time.
  • Page 71 Option ROM Messages [Enabled] [Enabled] The option ROM messages will be shown during the POST (power-on self- test). [Disabled] Only the ASUS logo will be shown during the POST. 2.8.6 Interrupt 19 Capture [Disabled] [Enabled] Allows the option ROMs to trap Interrupt 19.

  • Page 72: Secure Boot

    Boot Device Control [UEFI and Legacy OPROM] Allows you to select the type of devices that you want to boot up. Configuration options: [UEFI and Legacy OPROM] [Legacy OPROM only] [UEFI only] Boot from Network Devices [Legacy OPROM first] Allows you to select the type of network devices that you want to launch. Configuration options: [Legacy OPROM first] [UEFI driver first] [Ignore] Boot from Storage Devices [Legacy OPROM first] Allows you to select the type of storage devices that you want to launch.
  • Page 73 Allows you to load the additional db from a storage device so that more images can be loaded securely. DBX Management The dbx (Revoked Signature database) lists the forbidden images of db items that are no longer trusted and cannot be loaded. ASUS H81-GAMER 2-43...

  • Page 74: Boot Option Priorities

    • To select the boot device during system startup, press <F8> when ASUS Logo appears. • To access Windows OS in Safe Mode, do any of the following: Press <F5>...

  • Page 75: Tool Menu

    <Enter> to display the submenu. 2.9.1 ASUS EZ Flash 2 Utility Allows you to run ASUS EZ Flash 2. Press <Enter> to launch the ASUS EZ Flash 2 screen. For more details, see section ASUS EZ Flash 2. 2.9.2 Setup Animator [Enabled] Enables or disables the Setup animator.

  • Page 76: Exit Menu

    2.10 Exit menu The Exit menu items allow you to load the optimal default values for the BIOS items, and save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit menu. Load Optimized Defaults This option allows you to load the default values for each of the parameters on the Setup menus.

  • Page 77: Appendices

    Cet appareil est conforme aux normes CNR exemptes de licence d’Industrie Canada. Le fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d’interférences et (2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement non souhaité de l’appareil. ASUS H81-GAMER...

  • Page 78: Canadian Department Of Communications Statement

    ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.

  • Page 79: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site http://usa.asus.com Technical Support Support fax +1-812-284-0883 General support +1-812-282-2787 Online support http://support.asus.com/techserv/techserv.aspx ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Deutschland +49-2102-959931 Web site http://www.asus.de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555...
  • Page 80 Appendices...
