Summary of Contents for Golden Eagle Zenoah GZ25N
- Page 1 Golden Eagle Bike Engines P.O. Box 365 East Lansing, MI 48826 OWNER/OPERATOR MANUAL...
-
Page 2: Warnings In The Manual
Maintenance page 11 Storage Page 11 Troubleshooting guide Specifications 11.7 lbs (5.3kg) Dry weight with accessories Air-cooled 2-stroke gasoline Engine Type Zenoah GZ25N Model 1.6cu-in (25.4cc) Displacement 1.2Hp (0.9kW)at 7500/min (rpm) Max. output 3000–200/min (rpm) Idle speed Mixture(Gasoline 50 : Oil 1) - Page 3 For safe operation and maintenance, symbols are carved in relief on the machine. According to these indications, please be Never modify your engine/mount. We won’t careful not to take a mistake. warrant the machine, if you don’t observe the proper usage written in the manual. (a) The port to refuel the "MIX GASOLINE"...
-
Page 4: Handling Fuel
m a i n t e n a n c e c h e c k i n g repair work not described in this procedures. manual must be performed, contact a G.E.B.E. representative. 5. Under no circumstances should you ever take apart the product or alter it in any way. - Page 5 Fuel • Gasoline is very flammable. Avoid smoking or bringing any flame or sparks near fuel. Make sure to stop the engine and allow it cool before refueling the unit • The RedMax engines are lubricated by oil specially formulated for air- cooled 2-cycle gasoline engine use.
-
Page 6: Operation
Fuel _ HOW TO MIX FUEL 1. Measure out the quantities of gasoline and oil to be mixed. 2. Put some of the gasoline into a FOR YOUR ENGINE LIFE, AVOID; clean, approved fuel container. 1. FUEL WITH NO OIL(RAW 3. - Page 7 Operation • Avoid pulling the rope to its end or returning it by releasing the knob. Such actions can cause starter failures. • Move the choke lever to the OFF position and restart the engine (OP2) • Allow engine to warm up for several minutes.
-
Page 8: Maintenance Chart
Maintenance _ MAINTENANCE CHART Every Every Every Before System/Component Procedure Note hours hours hours after after after fuel leaks, fuel wipe out spillage fuel tank, air filter, replace, if inspect/clean fuel filter necessary GAP: clean and .025in(0.6~0.7mm) spark plug readjust plug replace, if necessary cylinder fins, intake... - Page 9 service to the machine. Contact with hot muffler may result in a personal injury. Maintenance _ AIR FILTER • The air filter, if clogged, will reduce the engine performance. Check and • clean the filter element in warm, Inspect periodically, the muffler for soapy water as required.
-
Page 10: Intake Air Cooling Vent
Maintenance • If waste gets stuck and causes _ INTAKE AIR COOLING VENT blockage around the intake air cooling vent or between the cylinder • Never touch the cylinder, muffler, fins, it may cause the engine to or spark plugs with your bare overheat, and that in turn may hands immediately after stopping cause mechanical failure. -
Page 11: Troubleshooting Guide
Storage Aged fuel is one of major causes of engine starting failure. Before storing the unit, empty the fuel tank and run the engine until it uses all the fuel left in the fuel line and the carburetor. Store the unit indoor taking necessary measures for rust prevention. Trouble Shooting Guide Case 1.
