- Page 1 Sidewinder High Definition IP Cameras SW720-H.264-HD Installation and Operation Manual Including: Optional X30 Optical Zoom (HD30) Optional Electric Brakes (ENG) Optional Nitrogen Pressurization (P) Optional Connector Interfaces (HV)(AMP) 120VAC and 24VAC Options REVISION 11-19-14...
-
Page 2: Table Of Contents
X20 ZOOM IMAGE SENSOR AND LENS................27 VIDEO ENCODING ........................28 CAMERA HOUSING MODULE ....................28 PAN AND TILT DRIVE ASSEMBLIES ................... 29 ELECTRICAL ..........................30 ENVIRONMENTAL ........................30 MECHANICAL ..........................31 REVISION HISTORY ........................31 SW720-H.264-HD WTI ~ Page 2 of 31... -
Page 3: Information
Wireless Technology, Inc. that may cause undesired operation. (WTI) It is not to be copied or disclosed in any manner without the consent of Wireless READ THIS MANUAL Technology, Inc. -
Page 4: Product Warranty And Repair
We appreciate your purchase of Wireless Technology, Inc. (WTI) security products. We take pride in the quality of our products and have manufactured each new WTI product to exacting quality standards. In normal use, it will provide you with years of satisfactory performance. -
Page 5: Repair Authorization
(RA) and provide the following information: 1.) Product Model & Serial Numbers 2.) Date of shipment, purchase order number, sales order number or WTI invoice number. 3.) Details of the defect or malfunction. If there is a dispute regarding the warranty or... -
Page 6: Safeguards
Also take precautions to avoid contact between the equipment and other electrical wires or power sources that may be present at the installation site. SW720-H.264-HD WTI ~ Page 6 of 31... -
Page 7: General Description
MS style male connector or a 16 Pin AMP connector. An optional side egress connector arrangement is also available. The Sidewinder SW720-H264-HD camera is capable of supporting an H.264 and a second H.264 or MJPEG compressed video stream simultaneously. Support is provided for unicasting and multicasting. -
Page 8: Models And Features
The following table provides a quick reference to the major features available in each camera model. MODEL SW720-H.264-HD SW720-H.264-HD-ENG SW720-H.264-HD30 SW720-H.264-HD30-ENG SW720P-H.264-HD SW720P-H.264-HD-ENG SW720P-H.264-HD30 SW720P-H.264-HD30-ENG SW720HV-H.264-HD SW720HV-H.264-HD-ENG SW720HV-H.264-HD30 SW720HV-H.264-HD30-ENG SW720AMP-H.264-HD SW720AMP-H.264-HD-ENG SW720AMP-H.264-HD30 SW720AMP-H.264-HD30-ENG SW720-24-H.264-HD SW720-24-H.264-HD30 SW720P-24-H.264-HD30 SW720-H.264-HD WTI ~ Page 8 of 31... -
Page 9: Installation
Please examine the equipment carefully when unpacking the shipping container. If any damage is noted please be sure to file a claim with the carrier. WTI is not responsible for any damage that occurs during shipping. Please verify that all of the contents are present and carefully check the packing material for any loose items before recycling it. -
Page 10: Dimensions And Mounting
DIMENSIONS AND MOUNTING MECHANICAL DIMENSIONS BOTTOM EGRESS SIDE EGRESS SW720-H.264-HD WTI ~ Page 10 of 31... -
Page 11: Mounting
MOUNTING The Sidewinder SW720-H264-HD camera should normally be mounted in an upright orientation, as shown above. The camera may also be mounted upside down if desired, but a cover of some sort should be placed over the bottom of the camera, extending out to... -
Page 12: Mounting Accessories
MOUNTING ACCESSORIES WTI manufactures several different mounts for the Sidewinder SW720A that allow the camera to be attached to pole tops, horizontal poles, vertical poles and walls. The Sidewinder SW720-H.264-HD camera is supplied with a 36 inch umbilical cable to allow the cable to be routed through the camera mount before the actual physical installation of the camera. - Page 13 SWWM1 + SWVPA – Wall Mount with Vertical Pole Adapter SW720-H.264-HD WTI ~ Page 13 of 31...
- Page 14 SWPTM1 – Pole Top Mount SW720-H.264-HD WTI ~ Page 14 of 31...
- Page 15 SWHPM1 – Horizontal Pole Mount SW720-H.264-HD WTI ~ Page 15 of 31...
- Page 16 15-4-1430 – 6”x6”x3/8” Square Mounting Plate SW720-H.264-HD WTI ~ Page 16 of 31...
- Page 17 15-4-913 – 6”Round Riser Mounting Base SW720-H.264-HD WTI ~ Page 17 of 31...
-
Page 18: Ms Signal Connections
RS-422 Data Shield CAT-5e Shield (Belden 1300A) RS-422 TX - Blue/White CAT-5e RS-422 TX + Blue CAT-5e AC Line Neutral (low) SJOOW White (18 AWG) 85-265 AC Line Input (high/hot) SJOOW Black (18 AWG) SW720-H.264-HD WTI ~ Page 18 of 31... -
Page 19: Amp Style Signal Connections
CAT-5 Blue Ethernet RX- CAT-5 Green AC Safety Ground Green 20 AWG Minimum 24 VAC - 2 Black 20 AWG Minimum Analog Video Output RG-59U Center RS-422/485 Rx+ CAT-5 Brown Ethernet RX+ CAT-5 Green/White SW720-H.264-HD WTI ~ Page 19 of 31... - Page 20 Ethernet RX+ CAT-5e Green/White Ethernet RX- CAT-5e Green 85-265 AC Line Hot SJOOW Black (18 AWG) AC Line Neutral SJOOW White (18 AWG) spare 115 VAC Safety Ground SJOOW Green (18 AWG) Spare SW720-H.264-HD WTI ~ Page 20 of 31...
-
Page 21: Signal Descriptions
A secondary hard wired RS-485 port is provided on the SW720-H264-SD camera for PTZ and other camera control functions. These signals can be conveniently accessed at the cabinet end of the customer installed control cable by using the WTI RJ-45 Serial Data Breakout Box. - Page 22 485 communications lines will require that the terminations on all cameras but one be turned off. SW720-H.264-HD WTI ~ Page 22 of 31...
- Page 23 RJ-45 connector are provided on the breakout box for passing through the Ethernet data, and a 5 Pin Phoenix style connector interface is provided for extracting the RS-485 signals from the Ethernet cable.. SW720-H.264-HD WTI ~ Page 23 of 31...
-
Page 24: Camera Ethernet Protocols And Ports
UDP Multicast WS-Discovery 3702 (group address 239.255.255.250) RTSP Server 8554 UDP not supported Multicast Video UDP Multicast Only if video stream 1 is set 18888/18889 RTP/RTCP (group address up for Multicast transport. A SW720-H.264-HD WTI ~ Page 24 of 31... - Page 25 The SW720-H264-SD camera supports COHU, Pelco D, WTI, NTCIP, Web/ONVIF and other protocols through the RS-485 data connections. The RS-485 serial port can be configured using the On Screen Menu system or by using the WTI Camera Control GUI program through the Ethernet connection.
-
Page 26: Surge Protection And Pressurization
SURGE PROTECTION AND PRESSURIZATION SURGE PROTECTION The SW720-H264-HD camera provides internal surge protection for all of the power, data and video signals. 1.) The AC line power connections are provided with 275 volt 135 Joule MOV surge arrestors rated for 6000 Amp pulses. A 3A SMT fuse is included in the primary circuit to prevent catastrophic printed circuit board damage in the case of gross AC line input overloads. -
Page 27: Specifications
Pixel Resolution 2144 horizontal x 1588 vertical (total) – 2096(H) x 1561(V) viewable Video Output Format HD: 1080P30 at full resolution Maximum Lens Aperture F1.6 at full wide angle – F3.5 at full telephoto SW720-H.264-HD WTI ~ Page 27 of 31... -
Page 28: Video Encoding
<250ms Network Protocol Layers RTP, RTSP, UDP, TCP, IP, HTTP, IGMPv2, ICMP, ARP as a minimum CAMERA HOUSING MODULE External Window Coating High temperature vacuum deposited hydrophilic coating to reduce window cleaning maintenance. SW720-H.264-HD WTI ~ Page 28 of 31... -
Page 29: Pan And Tilt Drive Assemblies
Sector Zones Up to 16 sector zones with user settable right and left pan limits may be programmed with one line of up to 20 characters of ID titling per zone. SW720-H.264-HD WTI ~ Page 29 of 31... -
Page 30: Electrical
EIA RS-485 signal levels and drive capabilities. Data Transient Protection Gas discharge tubes followed by 40A 300W transient voltage suppressors. Control Data Protocol Cohu, Pelco D, WTI, NTCIP, ONVIF and others Power interrupt immunity NEMA TS-2 paragraph 2.1.4. Power transient immunity NEMA TS-2 paragraph 2.1.6. -
Page 31: Mechanical
11/13 – Analog video and RS-485 signal wiring in MS umbilical connector wiring chart changed to standard, rather than optional. Mechanical dimensions drawing modified to show umbilical connector with standard 3 foot length, rather than AC Plug and RJ-45 Connector. SW720-H.264-HD WTI ~ Page 31 of 31...
