Summary of Contents for Life PS0090
- Page 1 PowerEase 90W Power Supply ® Catalog Numbers PS0090, PS0091, PS0092 Publication Number MAN0009597 Revision B.0 Research Use Only. Not for use in diagnostic procedures.
- Page 2 MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. TO THE EXTENT ALLOWED BY LAW, IN NO EVENT SHALL LIFE TECHNOLOGIES AND/OR ITS AFFILIATE(S) BE LIABLE, WHETHER IN CONTRACT, TORT, WARRANTY, OR UNDER ANY STATUTE OR ON ANY OTHER BASIS FOR SPECIAL, INCIDENTAL, INDIRECT, PUNITIVE, MULTIPLE OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH OR ARISING FROM THIS DOCUMENT, INCLUDING BUT NOT LIMITED TO THE USE THEREOF.
-
Page 3: Table Of Contents
Contents Introduction ..................................4 Product contents ................................4 Contents ..................................4 Product description ............................... 4 Description of buttons and switches ........................... 6 Operational keys ................................6 Methods ....................................7 Getting started ................................7 Important guidelines ..............................7 Operation modes ................................8 Limiting parameter settings ............................ -
Page 4: Introduction
PowerEase ® 90W Power Supply 1 each Extra Fuse 1 each Type B Power Cord 1 each (PS0090) JIS 8303 Power Cord 1 each (PS0090) Type G Power Cord 1 each (PS0091, PS0092) ASTA Type CEE 7/7 Power Cord 1 each (PS0091, PS0092) - Page 5 Features of the • Constant Voltage or Current PowerEase ® • Capable of running multiple electrophoresis units Power Supply • LCD display with clear menu prompts for easy use • Four sets of output terminals • Capability to specify run durations PowerEase ®...
-
Page 6: Control Buttons
Description of buttons and switches Front view of Backlit LCD display Output jacks PowerEase ® Power Supply Control buttons Rear view of Power inlet PowerEase ® Power Supply Power switch Fuse compartment Operational keys PowerEase ® 90W Power Supply key pad Use the key to…... -
Page 7: Methods
Methods Getting started Install the Check the label located near the AC inlet to ensure that the unit is compatible with locally provided voltage. PowerEase ® Power Supply ® Place the PowerEase 90W Power Supply on a level laboratory bench. Keep the area around the power supply clear to ensure proper ventilation of the unit. -
Page 8: Operation Modes
Operation modes Introduction The PowerEase ® 90W Power Supply is a microprocessor-controlled power supply designed to meet most electrophoresis needs in a single, easy to use unit. The power supply offers two modes: Constant Voltage and Constant Current. Use the Constant Voltage or Constant Current Mode for applications that require only one specific voltage limit or current limit during the entire duration of electrophoresis. - Page 9 Voltage limiting For most electrophoresis methods resistance increases throughout the run. Limiting the voltage provides the following advantages: • Current and power decrease throughout the run, providing an improving margin of safety over time. • The same voltage setting can be used regardless of the number or thickness of gels being electrophoresed.
-
Page 10: General Safety
The PowerEase ® 90W Power Supply has been designed for use with electrophoresis cells with shielded banana plugs thus minimizing any potential shock hazard to the user. Life Technologies recommends against the use of unshielded banana plugs. To avoid electrical shock: 1. -
Page 11: Explanation Of Symbols And Warnings
Explanation of symbols and warnings Symbols and warnings Symbol English Français Caution, risk of electrical shock Attention, risque de choc électrique Caution, risk of danger Attention, risque de danger Consult the manual for further Consulter le manuel pour d’autres safety information. renseignements de sécurité. -
Page 12: Production Regulatory Compliance
Production regulatory compliance Federal This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide Communications reasonable protection against harmful interference when the equipment is operated in a Commission commercial environment. -
Page 13: Troubleshooting
Appendix B Troubleshooting Observation Possible cause Recommended action The LCD screen remains AC power cord is not connected Check AC power cord connections at both ends. blank and the fan does not Use the correct cord. run when the power is turned on The fuse has blown Replace the fuse... -
Page 14: Common Errors
Common errors Observation Possible cause No load The electrophoresis system is not connected to the power leads, check the power leads • The electrophoresis system has a short, the platinum wire is broken or the banana • connectors are damaged Buffer concentration too low •... -
Page 15: Appendix C
Appendix C Operational electrical parameters Ohm’s Law and Electrophoresis is the migration of a charged particle under the influence of an electrical field. The power supply output parameters voltage, current, and power are related by the Joule’s Law following two equations: Voltage (V) = Current (I) x Resistance (R);... -
Page 16: Product Specifications
Appendix D Product specifications Feature Specifications Input Power (switchable) 115 VAC, 50/60 Hz 230 VAC, 50/60 Hz Fuses One 2A/250V, one extra fuse is provided Output power in watts 90 watts Output voltage range 2~300 V Output current range 4~500 mA Timer ~99.99 hr/min Terminal pairs... -
Page 17: Repair And Maintenance
Appendix E Repair and maintenance Introduction The PowerEase ® 90W Power Supply requires no periodic maintenance program with the exception of an occasional dry wipe-down of the instrument. Encountering Check the troubleshooting section, see Appendix B problems Contact Technical Support, see Appendix F If the unit must be shipped back for repair, contact support for a Return Authorization Number and shipping instructions;... -
Page 18: Appendix F
Certificate of Analysis by product lot number, which is printed on the box. Limited product Life Technologies Corporation and/or its affiliate(s) warrant their products as set forth in the Life Technologies’ General Terms and Conditions of Sale found on Life Technologies’ warranty website at www.lifetechnologies.com/termsandconditions. - Page 20 For support visit lifetechnologies.com/support or email techsupport@lifetech.com lifetechnologies.com 06 May 2014...
