Summary of Contents for Telit Wireless Solutions Car Phone
- Page 1 Car Phone installation guide...
-
Page 2: Table Of Contents
Table of Content: Carphone kit ......................3 Installation Diagram ....................5 Carphone layout ...................... 6 Preplanned Accessory Positioning ................7 Plan Phone and Cradle Positions Plan the Microphone’s Position Plan the Speaker’s Position Installing the Cradle and Phone ................9 Where to Position (Reminder) Installing the Cradle and Phone Installing the Microphone... -
Page 3: Carphone Kit
1 Carphone kit... -
Page 5: Installation Diagram
2 Installation Diagram... -
Page 6: Carphone Layout
3 Carphone layout... -
Page 7: Preplanned Accessory Positioning
P replanned Accessory Positioning Positioning of all accessories must be planned in advance before installation begins. • Ensure that no wire braids go through locations where Phone accessories are to be installed. • Ensure that any parts of the handsfree Phone will not interfere with the vehicle or its accessories’... -
Page 8: Plan The Speaker's Position
• It is recommended to install the microphone inbetween car roof and windscreen glass and away from external sources of noise. • Install the microphone in a different direction than the speaker so as to avoid echo. P lan the Speaker’s Position ... -
Page 9: Installing The Cradle And Phone
I nstalling the Cradle and Phone (Reminder) W here to Position 1 0 B The best way to determine the Phone’s position to the customer’s full satisfaction is to locate it when the customer is beside you and obtain Note! his/her agreement. -
Page 10: Installing The Cradle And Phone
• Ensure the Phone would be protected from mechanical damage by the car’s accessories. I nstalling the Cradle and Phone 1 1 B 1. Disassemble the cradle into its two parts. 2. Install one of the cradle parts in the determined location in the car with 4 tin screws. -
Page 11: Installing The Microphone
I nstalling the Microphone 1 2 B The microphone is provided with a clip which makes it possible to install it inbetween the car roof and windscreen glass (Reminder) 5.3.1 W here to Locate the Microphone 1 8 B • Install the handsfree Phone’s microphone 30-40 cm away from where the driver speaks when he/she is in their normal driving position. - Page 12 5.3.2 I nstalling the Microphone 1 9 B 1. Using the clip, install the microphone inbetween the car roof and windscreen glass. 2. Direct the microphone cable along the roof, behind it, so as not to be seen. 3. Continue directing the microphone cable along the left beam on the driver side. 4.
-
Page 13: Installing The Speaker
I nstalling the Speaker 1 3 B (Reminder) 5.4.1 W here to Locate the Speaker 2 0 B The speaker and microphone (installed inbetween the car roof and windscreen glass above the driver) must face different directions. Note! If the speaker and microphone face each other, this will cause echo. Do not hide the speaker inside the dash board. -
Page 14: Installing The Electrical Connections
5.5 Installing the Electrical Connections The electrical cable is provided separately from the control cable. Before installation begins, connect the four leads (which include the 2A fuses) using a red or blue crimp sleeve as appropriate. Please note sharp edges or moving parts which may damage the wires. The value for the fuses provided with the kits must not be changed. -
Page 15: Installing The Voltage Cable
Installing the Voltage Cable The following chart covers the manner by which the voltage cable should be connected to the car’s electrical system. Wire Color Function Must be connected to Ensure To provide the 12V fixed voltage Ensure a 250V / 2A handsfree Phone with fuse is used Includes fuse case... -
Page 16: Installing The Antenna
I nstalling the Antenna 1 6 B 5.7.1 W here to Locate the Antenna 2 2 B • The preferred location for the antenna is on the right side of the windshield. • If a cell phone or other communication system is installed in the car, please locate the antenna as far away as possible from the other Phone’s antenna. - Page 17 5.7.2.2 I nstalling the Internal Adapter and Coaxial Cable 2 5 B 5. Carefully remove the clear plastic cover protecting the internal adapter. 6. Move the adapter, on the inside of the window, toward the antenna base (the external adapter), and direct the adapter so as to fully overlap the base. 7.
-
Page 18: Installing The Sim Card
I nstalling the SIM card 1 7 B See SIM card installation position: Insert the SIM card when the phone is off. Note! -
Page 19: Trouble Shooting
6 Trouble Shooting Symptom What to Check What to Do N o reception Check whether connector is correctly Replace connector 2 6 B connected to the cable – use an efficiency meter Check if internal and external antenna base Attach antenna base is correctly attached Check proper working order of antenna Replace antenna cable... -
Page 20: Appendix
A ppendix Finding IMEI code Type code *#06# Find locking code *5625#...
